Electrolux Dito 603532 Manual de usuario

Item

Model

ProjectName

Dough Sheeters

603532

LMP500

The pastry roller allows all types of

lining pastry and dough, as well as

puff pastry work to be rolled out on

the premises. The current trend for

quality fresh pastry in restaurants

and catering kitchens means that

the pastry roller is once again

attracting attention. Combined with

the planetary mixer which is found

in all kitchens, provides the means

for ensuring that all types of pastry

can be produced.

FEATURES

V This pastry roller can be set up on a

table or fitted onto a mobile stand.

V The rolling direction may be inverted

by the movement of a joystick.

V The cylinders may be regulated for

sheets ranging from 0,1 to 34 mm in

thickness.

V Rollers: 60 mm Ø in chromium plated

steel. The accessibility of the parts in

contact with the pastry/dough makes

cleaning easier. The smooth surfaces

are white-paint finished.

V The upper and lower roller scrapers

may be easily removed for cleaning.

V The slides can be disassembled to

reduce the dimensions of the machine

and are teflon coated to facilitate the

sliding of the dough.

Specifications

MODEL

LMP5003

603532

LMP5001

603533

LMP50036

603534

External dimensions - mm

width 1000 1000 1000

depth 835 835 835

height 470 470 470

Power - kW

installed-electric 0.37 0.37 0.37

Net weight - kg. 70 70 70

Supply voltage 380...415 V, 3,

50/60

230...240 V, 1N,

208...240 V, 3,

Optional accessories

CODE DESCRIPTION

LMP5003

603532

LMP5001

603533

LMP50036

603534

653600 PEDAL TO CHANGE ROLLING

DIRECT.-SHEETERS ✓ ✓ ✓

653599 TROLLEY FOR DOUGH

SHEETERS-LMP500 ✓ ✓ ✓

V Each safety grating is hinged on the

structure and is equipped with a safety

micro-switch which helps to avoid injury.

When the gratings raise over a particular

level, the motor stops.

V Remote foot pedal to change rolling

direction (available as accessory).

V Flour container fixed on the top of the

machine.

V General electrical protection by fuses.

V Motor protected by a circuit breaker.

Emergency stop button, with lock and

manual re-start, ensures that the rolling

cylinders stop immediately.

AIB010

www.dito-electrolux.com

Dough Sheeters

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.

Installation drawings

XXX

I - Electrical connection 380...415 V, 3,

50/60

230...240 V, 1N,

208...240 V, 3, 60

MODEL

LMP5003

603532

LMP5001

603533

LMP50036

603534

603532, 603534, 603533

1000

300

500

835

470
