Electrolux 38TCIO Manual de usuario

user manual

Induction wok

38TCIO

We were thinking of you

when we made this product

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class

product from Electrolux, which hopefully

will provide you with lots of pleasure in

the future. The Electrolux ambition is to

offer a wide variety of quality products

that make your life more comfortable.

You will find some examples on the cov-

er in this manual. Please take a few min-

utes to study this manual so that you

can take advantage of the benefits of

your new machine. We promise that it

will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

4electrolux contents

Contents

Safety instructions 5

Description of the Appliance 7

Operating the appliance 10

Tips for cooking with the wok 15

Cleaning and Care 19

What to do if … 21

Disposal 23

Installation Instructions 24

Installation general 25

Installation proud of the work surface26

Built-in installation 29

Service 34

he following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

3General information and tips

2Environmental information

safety instructions electrolux 5

Safety instructions

Please comply with these instruc-

tions. If you do not, any damage re-

sulting is not covered by the

warranty.

This appliance conforms with the

following EU Directives:

–73/23/EEC dated 19.02.1973 Low

Voltage Directive

–89/336/EEC dated 03.05.1989 EMC

Directive inclusive of Amending Di-

rective 92/31/EEC

–93/68/EEC dated 22.07.1993 CE

Marking Directive

Correct use

•This appliance should be used only

for normal domestic cooking and fry-

ing of food.

•The appliance must not be used as a

work surface or as a storage surface.

•Additions or modifications to the ap-

pliance are not permitted.

•Do not place or store flammable liq-

uids, highly inflammable materials or

fusible objects (e.g. plastic film, plas-

tic, aluminium) on or near the appli-

ance.

Children’s safety

•Small children must be kept away

from the appliance.

•Only let bigger children work on the

appliance under supervision.

•To avoid small children and pets un-

intentionally switching the appliance

on, we recommend activation of the

child safety device.

General safety

•The appliance may only be installed

and connected by trained, registered

service engineers.

•Built-in appliances may only be used

after they have built in to suitable

built-in units and work surfaces that

meet standards.

•In the event of faults with the appli-

ance or damage to the glass ceramic

(cracks, scratches or splits), the ap-

pliance must be switched off and

disconnected from the electrical

supply, to prevent the possibility of

an electric shock.

•Repairs to the appliance must only

be carried out by trained registered

service engineers.

Safety during use

•Overheated fats and oils can ignite

very quickly. When cooking with fat

or oil (e.g. chips) do not leave the ap-

pliance unattended.

•Risk of burns! Fat or oil added to a

pan which has already been heated

ignites very quickly and can spit.

•There is the risk of burns from the

appliance if used carelessly.

•Remove stickers and film from the

glass ceramic.

•Cables from electrical appliances

must not touch the hot surface of the

appliance or hot cookware.

•Switch cooking zone off after every

use.

6electrolux safety instructions

•Users with implanted pacemakers

should keep their upper body at least

30 cm from induction cooking zones

that are switched on.

•Risk of burns! Do not place objects

made of metal, such as knives, forks,

spoons and saucepan lids on the

cooking surface, as they can get hot.

•Risk of fire! Do not place any paper,

cardboard, cloth, etc. between glass

ceramic niche and wok pan.

Safety when cleaning

•For cleaning, the appliance must be

switched off and cooled down.

•For safety reasons, the cleaning of

the appliance with steam jet or high-

pressure cleaning equipment is not

permitted.

How to avoid damage to the appli-

ance

•The glass ceramic can be damaged

by objects falling onto it.

•The edge of the glass ceramic can

be damaged by being knocked by

the cookware.

•Objects that melt and things that boil

over can burn onto the glass ceramic

and should be removed straighta-

way.

•Do not use cooking zone with empty

cookware or without cookware.

•The ventilation gap of 5mm between

the worktop and front of the unit un-

derneath it must not be covered.

description of the appliance electrolux 7

Description of the Appliance

Cooking surface layout

Control panel layout

300 mm

Wok niche 2300W

with power function

3200W

Control panel

Child lock pilot

light

Heat setting

indicator

Heat setting

indicator

Child lock

Heat setting 6 /

power function

Heat setting selec-

tion

Timer indica-

tor

Timer selection

On/Off pilot

light

On/Off

Timer

8electrolux description of the appliance

Touch Control sensor fields

The appliance is operated using Touch

Control sensor fields. Functions are

controlled by touching sensor fields.

Touch the sensor fields from above,

without covering other sensor fields.

Displays

Sensor field Function

On / Off To switch the appliance on and off

Increase settings To increase heat settings

Reduce settings To reduce heat settings

Timer Timer selection

Increase settings To increase Timer time

Reduce settings To reduce Timer time

Child lock Locking control panel for children

Power Switching the power function on and off

Heat setting 6 Set heat setting 6 immediately

Display Description

¾Cooking zone is switched off

uKeep warm setting Keep warm setting is set

¿- ÇHeat settings Heat setting is set

eFault Malfunction has occurred

fPan detection Cookware is unsuitable or too small or

no cookware has been placed on the

cooking zone

hResidual heat Cooking zone is still hot

lChild safety device Child safety device is engaged

pPower Power function is switched on

_Safety cut-out Safety cut-out has been activated

description of the appliance electrolux 9

Residual heat indicator

Warning! Risk of burns from residu-

al heat. After being switched off, the

cooking zones need some time to

cool down. Look at the residual heat

indicator h.

Residual heat can be used for melt-

ing and keeping food warm.

Accessories

Wok pan (supplied as standard)

•390 mm, 6 litres

•With handle and helper handle

•WOK P 6.0 stainless steel

Wok pan domed lid (special acces-

sory)

•390 mm

•WOK DG 39 stainless steel

Tempura rack (special accessory)

•390 mm, half surface

•WOK A 39 stainless steel

10 electrolux operating the appliance

Operating the appliance

Only use a wok pan that is suited to

this appliance.

Switching the appliance on and off

After switching on, within approx.

10 seconds a heat setting or a func-

tion must be set, otherwise the ap-

pliance automatically switches

itself off.

Setting the heat setting

Control panel Display Pilot light

To switch on touch for 2 seconds ¾/ hlights up

To switch off touch for 2 seconds h/ none goes out

Control panel Indicator

To increase Touch uto Ç

To decrease Touch Çto ¾

To switch off Touch and at the same time ¾
