Electrolux 253.60722012 Manual

P08F0077.eps P08D0689.wmf P08C1204.eps R08S0541.wmf

REPAIR

PARTS

LIST

253.60722012

For Parts or Service:

Call

1-800-4-MY-HOME®

(1-800-469-4663)

Or Visit

www.sears.com

UPRIGHT FREEZER

In all orders or correspondence, avoid delays and misunderstandings

by always giving the complete model number shown on the left side of

the access panel.

All repair parts listed are available for immediate purchase or special

order when you visit your nearest Sears Parts & Repair Center, or the

Service Department at most Sears stores. To order parts by phone, call

the toll-free number listed to the left or visit sears.com.

When requesting service or ordering parts, always provide the following

information:

• Product Type • Part Number

• Model Number • Part Description

Sears Brands Management Corporation, Hoffman Estates, IL 60179

Publication number 5995612172

253.60722012

04/12 2

DOOR

CAUTION: Use the Kenmore part number to order part, not the illustration number.

253.60722012

# Functional Parts 3 04/12

* Non-Illustrated Parts

CAUTION: Use the Kenmore part number to order part, not the illustration number.

POS. NO PART NO. DESCRIPTION

1 216522359 Gasket-door, white

9 216527813 Panel-inner door

11 297316514 Panel-outer door, white

12A 216885200 Nameplate

13 297257000 Door Stop, chrome, RH

18 297272500 Handle-door, white

21A 297197500 Screw, door stop mtg, FH38-16X.750, P Twin

22 216970800 Bearing, hinge w/o'ring, top

22A 297006800 Bearing-hinge, btm, w/o'ring

26 216524201 Gasket, secondary

27 5304472186 Clip, panel mtg

28 216951600 Rack-door, (5)

37 218771201 Trim-handle, 1.34", white

58 297347800 Screw, #10-32 X .375

64 216403700 Plug-button, hole filler, door base

73 218396700 Block-handle mtg, dovetail

74 215503201 Screw, cr pan hd, 10-16 x 0.500

93 5304460605 Screw, ph truss head, 8-18AB x 0.500

93A 297347900 Screw, #10-32 X .500

253.60722012

04/12 4

CABINET

132

71A 21

93B

42A

22A

P08C1204

10A

93A

169

41 28

170

253.60722012

# Functional Parts 5 04/12

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

3 216503100 Screen-drain

5 # 216325600 Fan Blade

6 297200600 Breaker Kit w/corners, no lock slot

9 297200100 Breaker Kit w/corners, 32", top and bottom

10 # 297334500 Heater-Drain Pan

10A 297177400 Bracket, (2), drain pan

13 # 297250000 Motor, fan, 115 V

14 216822900 Switch, light/lamp, ramp

15 216846400 Light Bulb/Lamp

16 297139501 Socket, light/lamp, 25 W

18 216707200 Knob, temp control

19 216204902 Gasket-evap cover

20 216967200 Cover, temp control

21 # 216807801 Control-temperature

22 216823500 Clamp, cap tube, cold control

22A 5303916855 Tube, sensor sleeve, plastic, clear

24 5304460604 Screw, type A, 10-24 x 3/8

25 297099250 Cover-evaporator

26 216503300 Ramp, door closer

28 297283900 Hinge-bottom, stepped pin

29 216313501 Hose-drain

31 297165800 Pan-drain

32 5308005500 Drain

34 216816200 Shield-light

35 216273000 Clip, wire retainer

37 297273900 Trim-cabinet corner, white, (2)

38 297283800 Hinge-upper

40 297164400 Cover-hinge

41 297236250 Screw, hex head, 1/4-20x5/8, hinge

42 216458400 Shelf, 14.50x27.88, (3)

42A 297119501 Shelf, 12.50x27.88, white

* 216502400 Grommet-shelf mtg

47 216661601 Baffle-plate

49 216937700 Trivet

50 216394050 Bracket, fan motor mount

* 216327800 Clip, wire

63 216396900 Screw, leveling foot, plastic, adjustable

63* 297164650 Bracket, LH leg levelor

63* 297164651 Bracket, RH leg levelor

71A 297146820 Screw, 8-18AB x.470 QX

72 297036900 Grille/Kickplate, 32", white

80 06594601 Bracket, control

93 216858001 Screw, 8-18x.50 AB, #10

93A 297174300 Screw, self pierce, #8, 18x.63

93B 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA

132 5304460601 Screw, 6-20AB x 3/8

169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)

170 297280400 Valve, breather

* 5995612172 Repair Parts List

* 297088200 Owners Guide

* 297001704 Insulation, 24", drain tube

* 216946200 Service Data Sheet

253.60722012

04/12 6

SYSTEM

253.60722012

# Functional Parts 7 04/12

* Non-Illustrated Parts

SYSTEM

POS. NO PART NO. DESCRIPTION

1 # 5300083897 Condenser

2 5308000110 Strap-evap/heater, aluminum, (2)

4 # 216938601 Filter - Dryer

5 # 297244600 Harness-main

5* 216695300 Relay

14 297216102 Defrost Heater

14A# 297222901 Heater

15 # 216997300 Evaporator

15A 297231800 Heat Exchanger

18 297078701 Insulator-evap, styrofoam, RH

19 297078801 Insulator-evap, styrofoam, LH

20 216731001 Thermostat, defrost

23 # 297318010 Timer, defrost, 115V, tab

27 216337701 Screw, HWH, 10-24 x 0.500, Swage

29 # 216966300 Compressor, w/o electricals

30 216954200 Controller, compressor, 5 speed

32 216954300 Clip, controller

35 297368500 Bolt, compressor

43B 297315800 Clip, wire

55 297286801 Run Capacitor, 10MF

86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA

100# 297169904 Cord-power

130 297244700 Support, evaporator mtg

* 216683900 Thermostat, Service part

* 297102800 Spacer-tube

* 216502500 Sleeve, suction line

* 240555002 Screw-#8-32 X 3/8

* 297174300 Screw, self pierce, #8, 18x.63
