TW SL5 E EN TUMBLE DRYER USER MANUAL 2

DE WÄSCHETROCKNER BENUTZERINFORMATION 29

CONTENTS

1. SAFETY INFORMATION...................................................................................... 3

2. SAFETY INSTRUCTIONS.....................................................................................5

3. PRODUCT DESCRIPTION................................................................................... 7

4. ACCESSORIES....................................................................................................8

5. CONTROL PANEL...............................................................................................9

6. PROGRAMME TABLE....................................................................................... 10

7. OPTIONS...........................................................................................................13

8. STEAM FUNCTION............................................................................................14

9. BEFORE FIRST USE..........................................................................................16

10. DAILY USE...................................................................................................... 16

11. HINTS AND TIPS............................................................................................. 19

12. CARE AND CLEANING....................................................................................19

13. TROUBLESHOOTING......................................................................................23

14. TECHNICAL DATA...........................................................................................25

15. INSTALLATION................................................................................................26

16. GUARANTEE ..................................................................................................27

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

- Read the supplied instructions.

1.1 Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Children of less than 3 years should be kept away

unless continuously supervised.

•Keep all packaging away from children.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•If the appliance has a child safety device, we

recommend you activate it.

•Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•If the tumble dryer is put on top of a washing machine,

use the stacking kit. The stacking kit, available from

your authorized vendor, can be used only with the

appliance specified in the instructions, supplied with the

ENGLISH 3

accessory. Read it carefully before installation (Refer to

the Installation leaflet).

•The appliance can be installed as freestanding or below

the kitchen counter with correct space (Refer to the

Installation leaflet).

•Do not install the appliance behind a lockable door, a

sliding door or a door with a hinge on the opposite side,

where the appliance door can not be fully opened.

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

•Connect the mains plug to the mains socket only at the

end of the installation. Make sure that there is access to

the mains plug after the installation.

•Ensure you have good ventilation in the installation room

to avoid the back flow of gases into the room from

appliances burning other fuels, including open fires.

•Exhaust air must not be discharged into a flue which is

used for exhausting fumes from appliances burning gas

or other fuels. (if applicable)

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Obey the maximum load volume of 9kg (refer to the

“Programme chart” chapter).

•Do not use the appliance if industrial chemicals have

been used for cleaning.

•Wipe away lint that has accumulated around the

appliance.

•Do not run the appliance without a filter. Clean the lint

filter before or after each use.

•Do not dry unwashed items in the tumble dryer.

•Items that have been soiled with substances such as

cooking oil, acetone, alcohol, petrol, kerosene, spot

removers, turpentine, waxes and wax removers should

be washed in hot water with an extra amount of

detergent before being dried in the tumble dryer.

www.electrolux.com4

•Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes

or pillows fitted with foam rubber pads should not be

dried in the tumble dryer.

•Fabric softeners, or similar products, should be used as

specified by the fabric softener instructions.

•Remove all objects from pockets such as lighters and

matches.

•Never stop a tumble dryer before the end of the drying

cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

•The final part of a tumble dryer cycle occurs without

heat (cool down cycle) to ensure that the items are left

at a temperature that ensures that the items will not be

damaged.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Do not install or use the appliance

where the temperature is less than 5°C

or higher than 35°C.

• Make sure that the floor where you

install the appliance is flat, stable, heat

resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Always move the appliance vertically.

• The rear surface of the appliance must

be put against the wall.

• When the appliance is put in its

permanent position, check if it is fully

level with the aid of a spirit level. If it is

not, adjust the feet until it is.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• Do not touch the mains cable or the

mains plug with wet hands.

• Only for UK and Ireland. The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use a 13 amp ASTA (BS

1362) fuse.

• This appliance complies with the E.E.C.

Directives.

ENGLISH 5

2.3 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• Use this appliance in a household only.

• Do not dry the damaged items which

contain padding or fillings.

• Only dry fabrics which are applicable to

dry in the tumble dryer. Follow the

instructions on the fabric label.

• If you have washed your laundry with a

stain remover start an extra rinse cycle

before you start the dryer.

• Do not drink or prepare food with the

condensed water/distilled water. It can

cause health problems to people and

pets.

• Do not sit or stand on the open door.

• Do not dry dripping wet clothes in the

tumble dryer.

WARNING!

Only fill the water reservoir for

steam treatment with distilled

water. Do not use tap water

or any additives! It can cause

damage to the appliance.

• The condensed water from this

appliance’s condensed water container

can also be used, if it is filtered first

(e.g. with a coffee filter).

• Only operate the steam programmes

with distilled water!

• Once the drying cycle or steam

programme has been interrupted, the

laundry and drum may be hot. Risk of

burns! Take care when removing the

laundry.

• Be careful when interrupting the steam

programme: Do not open the machine

door during the steam phase. Hot

steam may result in burns. The display

shows a message to indicate the

steam phase.

2.4 Internal light

WARNING!

Risk of injury.

• Visible LED radiation, do not look

directly into the beam.

• The type of light bulb or halogen lamp

used for this appliance is only for

household appliances. Do not use it for

house lighting.

• To replace the internal light, contact

the Authorised Service Centre.

2.5 Care and cleaning

WARNING!

Risk of injury or damage to

the appliance.

• Do not use water spray and steam to

clean the appliance.

• Clean the appliance with a moist soft

cloth. Only use neutral detergents. Do

not use abrasive products, abrasive

cleaning pads, solvents or metal

objects.

2.6 Compressor

WARNING!

Risk of damage to the

appliance.

• The compressor and its system in the

tumble dryer is filled with the special

agent which is free from fluoro-chloro-

hydrocarbons. This system must stay

tight. The damage of the system can

cause a leakage.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

www.electrolux.com6

3. PRODUCT DESCRIPTION

1 2

1Water container

2Control panel

3Internal light

4Appliance door

5Filter

6The button to open the heat

exchanger door

7Airflow slots

8Adjustable feet

9Heat exchanger door

10 Heat exchanger cover

11 The knob to lock the heat exchanger

cover

12 Rating plate

13 Water re-circulation filter

The load door can be

installed by the user in the

opposite side. It can help to

easily put and remove the

laundry or if there is a limit to

install the appliance (see

separate leaflet).

ENGLISH 7

4. ACCESSORIES

4.1 Stacking kit

Accessory name: SKP11, STA8, STA9

Available from your authorized vendor.

Stacking kit can be used only with the

washing machines specified in the leaflet.

See the leaflet attached.

Read carefully the instructions supplied

with the accessory.

4.2 Draining kit

Accessory name: DK11.

It is available from your authorized vendor

(can be attached to some types of the

tumble dryers)

The accessory for through draining of the

condensed water into a basin, siphon,

gully, etc. After the installation, the water

container is drained automatically. The

water container must stay in the

appliance.

The installed hose must be on the height

from minimum of 50 cm to maximum of 1

m from floor level. The hose cannot be in

loop. Decrease the length of the hose if

necessary.

Read carefully the instructions supplied

with the accessory.

4.3 Pedestal with the drawer

Accessory name: PDSTP10.

It is available from your authorized vendor.

To put the appliance higher at the level

what helps to easy load and remove the

laundry.

The drawer can be used for laundry

storage e.g. : towels, cleaning products

and more.

Read carefully the instructions supplied

with the accessory.

www.electrolux.com8

5. CONTROL PANEL

1 2 3

467 5

1Programme dial

2Display

3Steam Load (Dampf) button

4Start/Pause button

5Options buttons

6Programme indicators

7On/Off (Ein/Aus) button with the Auto

Off function

5.1 Display

Symbol on the display Symbol description

, , extra laundry dryness: default, moderate, maximum

, - anti-crease phase duration: default, interval (30min.

- 120min.)

- - -

laundry was spun at: 800 — 1800 rpm

default

buzzer on

child lock on

ENGLISH 9

Symbol on the display Symbol description

time dry option on

indicator: fill the water container for steam system

indicator: clean the steam system filter

indicator: drain the water container

indicator: clean filter

indicator: do the check of the heat exchanger

indicator: drying phase

indicator: steam action phase

indicator: cooling phase

indicator: crease guard phase

delay start option on

cycle time indication

-time programme selection (10min.-2h)

-delay start selection (30min.-20h)

6. PROGRAMME TABLE

Programmes Load 1) Properties / Fabric mark

COTTON (BAUMWOLLE)

Extra Dry (Extratrocken) 9 kg Drying level: extra dry. /

Cupboard Dry +

(Schranktrocken+) 9 kg Drying level: cupboard dry +. /

Cupboard Dry (Schrank-

trocken) 2) 3) 9 kg Drying level: cupboard dry. /

Iron Dry (Bügeltrocken) 2) 9 kg Drying level: applicable for iron. /

Bed Linen (Bettwäsche) 3 kg

To dry bed linen such as: single

and double sheet, pillowcase,

bedspread. /

www.electrolux.com10

Otros manuales para TW SL5 E

Tabla de contenidos

Idiomas:

Otros manuales de Secadora de Electrolux

Electrolux

Electrolux WT40 Manual de usuario

Electrolux

Electrolux EW6C428W Manual de usuario

Electrolux

Electrolux EWMED65H Manual de usuario

Electrolux

Electrolux TWL4E300 Manual de usuario

Electrolux

Electrolux DC6-14 Manual de usuario

Electrolux

Electrolux EDH913R9WB Manual de usuario

Electrolux

Electrolux ZANUSSI ZDC 5350 W Manual de usuario

Electrolux

Electrolux EDH903BEWN Manual de usuario

Electrolux

Electrolux SAGQ7000FS0 Manual de usuario

Electrolux

Electrolux EWMED65HIW - 27" Perfect Steam Electric... Manual de usuario

Electrolux

Electrolux Dito 601837 Manual de usuario

Electrolux

Electrolux ELFE4222AW Manual de usuario

Electrolux

Electrolux Tumble dryer Manual de usuario

Electrolux

Electrolux EDE 36150W Manual de usuario

Electrolux

Electrolux EIMED60LSS Manual de usuario

Electrolux

Electrolux SWISSLINE TW SL5M 100 Manual de usuario

Electrolux

Electrolux EIMED55IIW - 27" Electric Dryer Manual de servicio

Electrolux

Electrolux SAHARA Manual de usuario

Electrolux

Electrolux FEQ332E Manual de usuario

Electrolux

Electrolux EDC804CEWA Manual de usuario

Electrolux

Electrolux EDE 37100W Manual de usuario

Electrolux

Electrolux EDH3684PDW Manual de usuario

Electrolux

Electrolux T4290 Manual del propietario

Electrolux

Electrolux EDC 77550W Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario

Frigidaire

Frigidaire CAQE7077KW0 Manual del propietario

Bosch

Bosch WTX8HKM9SN Manual de usuario
