Operating manual

T4290, T4530, T4650

Selecta Control

487 05 44 31.00

Tumble dryer

Safety instructions

This machine is only intended for drying water-washed garments.

Clothes that have been cleaned with chemicals/flammable liquids, must NOT

be dried in the machine.

Remove clothes from the tumble dryer as soon as they are dry. This prevents

them from becoming creased, and reduces the risk of spontaneous ignition.

The machine must not be used for drying foam rubber or foam-like materials.

The machine must not be used for drying floor mops*.

The machine must not be used by minors.

The machine must not be hosed down with water.

Adequate ventilation has to be provided to avoid the back flow of gases into

the room from appliances burning other fuels, including open fires.

Mechanical, electrical and gas installations must only be carried out by

authorised personnel.

If the machine has a fault, this must be reported as soon as possible to the

person in charge. This is important for your own safety and for the safety of

others.

Gas dryers only:

The machine is not to be installed in rooms containing clean-

ing machines with perchloroethylene, TRICHLOROETHYLENE or

CHLOROFLUOROCONTAINING HYDROCARBONS as cleaning agents.

What to do if you smell gas:

Do not try to light any appliance.

Do not touch any electrical switch; do not use any phone in your building.

Evacuate the room, building or area.

Contact the laundry manager.

* Applies only to floor mops containing polypropylene.

Emergency stop (T4530/4650)

If the machine for some reason

has to be stopped – press emer-

gency stop button.

When the necessary measures

have been taken, pull out the emer-

gency stop button. (The emergency

stop button is an option outside EU

and EEA).

Contents 5

Contents:

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Operating panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Instructions for use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Programs AHL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Tumble dryer with manual operation - AHL. . . . . . . . . . . . . . . . . . . .11

Programs OPL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Tumble dryer with manual operation - OPL. . . . . . . . . . . . . . . . . . . .13

Programs - coin operated laundries . . . . . . . . . . . . . . . . . . . . . . . . .14

Tumble dryer with payment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

The manufacturer reserves the right to modify design and

material specifications without notice.

Textiles as silk and wool must not be overdried

to avoid the risk of creasing.

Glossary 7

Glossary

Auto Stop

The tumble dryer stops automatically when the clothes are dry.

AHL (Apartment House Laundry)

Example: Communal laundries / Housing block laundries.

OPL (On Premises Laundry)

Example: Institutional laundries.

RMC (Residual Moisture Control)

The tumble dryer has residual moisture control.

Operating panel

OPL - Tumble dryer with manual operation

AHL - Tumble dryer with manual operation

Coin-operated laundries

487 22 93 40.00

SELECTA CONTROL

487 22 93 41_00

7 22

SELECTA CONTROL

487 09 10 00.00

487 09 10 01.00

SELECTA CONTROL

487 22 93 41_00

487 09 11 01.00

Operating panel 9

Buttons and symbols

P button

Program selection button.

Not active on pay machines.

With RMC: Push button during

operation, display shows: the

residual moisture in the clothes.

Cool-down time

Setting of cool-down time.

OPL laundries only.

Heat

When lamp is lit the heat is on.

Time button

Setting of drying time.

Not active on pay machines.

Program status

“d xx” = Time controlled drying - xx indicates the time.

“c xx” = Time controlled cool-down - xx indicates the time.

“c - -” = Temperature controlled cool-down.

“ 00” = Standby. The dryer runs an anti-crease program for 120

minutes or until the door is opened.

Start/stop button

Start: Push button.

Stop: Push button or open

door.

Reversing

Reversing on/off.

OPL laundries only.

Selected temperature

Lamp is lit at selected tempe-

rature.

Temperature button

Temperature selection button.

Push button during operation,

display shows: the outlet tem-

perature.

Filter

When lamp is lit filter door / fil-

ter drawer is open.

Instructions for use

Programs P 01 - P 02

Program Process Textiles

P 01 Extra dry Denim

P 02 Ready to put away 100% cotton / poly cotton mixture / terry

Programs P 01 - P 03 on dryers with RMC

Program Process Textiles

P 01 Extra dry Denim

P 02 Ready to put away 100% cotton / poly cotton mixture / terry

P 03 Ironing dry 15% moisture All textiles

Temperatures

High Non-iron/normal wash Cotton and mixed fabrics

Medium Non-iron/normal wash Cotton and mixed fabrics

Low Fine wash/mild wash Delicate fabrics

No heat Airing bedspreads, duvets and bedclothes

Load

Full loads are recommended in order to achieve the best result.

Full load is indicated in kilos of dry textile.

Dryer type 4290 = 13,5 kg

Dryer type 4530 = 27 kg

Dryer type 4650 = 35 kg

Programs AHL
