Electrolux EDS7051 Manual de usuario

EDS7051

................................................... ........................................................

2 www.electrolux.com

The final part of a tumble dryer cycle occurs without

heat (cooling cycle) to ensure that the items are left

at the temperature that ensures that the items will

not be damaged.

DRYER SAFETY

FIRE HAZARDS

Contents

Important Safety Instructions

Conditions of Use

Important Safety Instructions

Installation Instructions

Dryer Safety

Fire Hazards

Cleaning the Lint Filter

Drying Guide

Page 2

Page 3

Use

The Control Panel

Operating Sequence

Page 6

Page 7

Page 4

Conditions of Use ...............................................

.......................................

..................................

................................................................

......................

....................................................

...................................................

...................................

...................................................

Page 2

Hints Page 10

.........................................

Care And Cleaning Page 9

Troubleshooting & Accessories Page 11

This appliance is intended to be used in household and similar applications such as:

- Farm Houses.

- By clients in serviced apartments, holiday apartments and other residential type environments.

It must not be used for purposes other than those for which it was designed.

See the serial number sticker

located on the bottom of the

door opening for voltage

information.

ENGLISH

EDS70517

Nozzle

Rating Plate

Lint Filter

The lint filter is located at

the front of your dryer at

the bottom of the door

opening.

www.electrolux.com

Removable

Exhaust

Grille

Control Panel

Door

Door Safety Switch

Button

Door Handle

Exhaust Grille

Front Feet

Mains Cable

Air Inlet Duct

Outlet Cover

Water Inlet Hose

Worktop

Back Feet

ENGLISH

Water Connection

Water tap must be installed within 110 cm of your

dryer’s water inlet and the tap must be 3/4 inch BSP

thread for laundry hose connection. Water pressure

must be between 200kpa to 800kpa.

Use the hose supplied with the dryer. DO NOT USE

OLD HOSES.

To connect the water inlet to dryer:

Turn off water supply

to washer.

Remove inlet hose from water supply.

Check rubber seal,

replace if worn.

Check rubber

seal

Turn on the water tap and check for leaks at all

connection.

Turn on water supply for a short time to run some

water into a bucket or container to clear any

contaminants in the line.

Connect the Y-Connector to the water tap.

Connect the inlet hose for the washer and the dryer

to the Y-Connector and tighten them.

Water Tap

To Washing

Machine

water tap

www.electrolux.com

When a new program is selected while the dryer is

already running, the drying process will continue

using the settings from the new program.

continue

from

unload

The dryer

6 58 104 3 7 19

This button allows you to select 2 options.

Iron Aid:

This option should only be used to reduce

wrinkles for clothes which are clean and dry.

When this option is selected, all other

programs will be suppressed.

This option will help in reducing wrinkles on your

clean and dry clothes by using a combination of

moisture and warm air function. Maximum load

should not exceed 1 kg when this option is

selected. This option cannot be combined with any

other programs.

ENGLISH

To activate this option press and hold the “Option”

and “Delay” buttons simultaneously until a long

beep is heard.

To deactivate press and hold the same buttons

until a short beep is heard.

Press door

safety switch

button.

For drying delicates and

synthetics at lower heat for

maximum care of the fabrics.

The Delicate setting will cause

the heater to cycle on for

shorter time than the Normal

setting.

To obtain the best drying results with small loads

it is recommended to use Extra Dry program.

www.electrolux.com

WARNING: Never stop a tumble dryer before

the end of the drying cycle unless all items

are quickly removed and spread out so that

the heat is dissipated.

both

ENGLISH

If your water is very hard or contains traces of lime

deposit, the water inlet filter may become clogged.

It is therefore a good idea to clean it from time to time.

Remove the water inlet

hose from the water tap.

Remove the inlet hose behind the appliance.

Clean the filter in the inlet

hose with a stiff brush.

To clean the water inlet filters:

1. Close the water tap.

Care And Cleaning

You must DISCONNECT the appliance from

the electricity supply, before you can carry out

any cleaning or maintenance work.

Clean the appliance only with soap and warm water.

Fully dry all the surfaces.

Do not use alcohol, solvents or chemical

products.

Cleaning The Water Inlet Filter

External Cleaning

Warning!

Caution!

Clean the filter in the valve with a stiff brush or a

towel.

Re-install the inlet hose. Make sure that the

couplings are tight to prevent leakages.

7. Open the water tap.

www.electrolux.com
