Electrolux EDC2086GDW Manual de usuario
EDC2086GDW
EN Tumble Dryer User Manual
CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. CONDITIONS OF USE.......................................................................................5
3. SAFETY INSTRUCTIONS..................................................................................5
4. PRODUCT DESCRIPTION................................................................................ 7
5. CONTROL PANEL............................................................................................. 7
6. PROGRAMME TABLE....................................................................................... 8
7. OPTIONS..........................................................................................................10
8. SETTINGS........................................................................................................11
9. BEFORE FIRST USE....................................................................................... 12
10. DAILY USE..................................................................................................... 12
11. HINTS AND TIPS........................................................................................... 13
12. CARE AND CLEANING..................................................................................14
13. TROUBLESHOOTING....................................................................................16
14. TECHNICAL DATA.........................................................................................17
15. WARRANTY .................................................................................................. 18
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
- Caution, risk of fire!
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Children of less than 3 years should be kept away
unless continuously supervised.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•If the appliance has a child safety device, we
recommend you activate it.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•If the tumble dryer is put on top of a washing machine,
use the stacking kit. The stacking kit, available from
your authorized vendor, can be used only with the
ENGLISH 3
appliance specified in the instructions, supplied with
the accessory. Read it carefully before installation
(Refer to the Installation leaflet).
•The appliance can be installed as freestanding or
below the kitchen counter with correct space (Refer to
the Installation leaflet).
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite
side, where the appliance door can not be fully
opened.
•The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
•Connect the mains plug to the mains socket only at
the end of the installation. Make sure that there is
access to the mains plug after the installation.
•Ensure you have good ventilation in the installation
room to avoid the back flow of gases into the room
from appliances burning other fuels, including open
fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from appliances burning
gas or other fuels. (if applicable)
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
•Obey the maximum load volume of 8kg (refer to the
“Programme chart” chapter).
•Do not use the appliance if industrial chemicals have
been used for cleaning.
•Wipe away lint that has accumulated around the
appliance.
•Do not run the appliance without a filter. Clean the lint
filter before or after each use.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as
cooking oil, acetone, alcohol, petrol, kerosene, spot
removers, turpentine, waxes and wax removers
www.electrolux.com4
should be washed in hot water with an extra amount of
detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes
or pillows fitted with foam rubber pads should not be
dried in the tumble dryer.
•Fabric softeners, or similar products, should be used
as specified by the fabric softener instructions.
•Remove all objects from pockets such as lighters and
matches.
•Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
•The final part of a tumble dryer cycle occurs without
heat (cool down cycle) to ensure that the items are left
at a temperature that ensures that the items will not be
damaged.
•Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
2. CONDITIONS OF USE
This appliance is intended to be used in
household and similar applications such
as:
• Farm houses
• By clients in serviced apartments,
holiday apartments and other
residential type environments.
3. SAFETY INSTRUCTIONS
3.1 Installation
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not install or use the appliance
where the temperature is less than
5°C or higher than 35°C.
• Make sure that the floor where you
install the appliance is flat, stable,
heat resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Always move the appliance vertically.
• The rear surface of the appliance
must be put against the wall.
• When the appliance is put in its
permanent position, check if it is fully
level with the aid of a spirit level. If it is
not, adjust the feet until it is.
3.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
ENGLISH 5
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• Only for UK and Ireland. The
appliance has a 13 amp mains plug. If
it is necessary to change the fuse in
the mains plug, use a 13 amp ASTA
(BS 1362) fuse.
• This appliance complies with the
E.E.C. Directives.
3.3 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Do not dry the damaged items which
contain padding or fillings.
• Only dry fabrics which are applicable
to dry in the tumble dryer. Follow the
instructions on the fabric label.
• If you have washed your laundry with
a stain remover start an extra rinse
cycle before you start the dryer.
• Do not drink or prepare food with the
condensed water/distilled water. It can
cause health problems to people and
pets.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
tumble dryer.
• Oil-affected items can ignite
spontaneously, especially when
exposed to heat sources such as in a
tumble dryer. The items become
warm, causing an oxidation reaction
in the oil. Oxidation creates heat. If
the heat cannot escape, the items can
become hot enough to catch fire.
Piling, stacking or storing oil-affected
items can prevent heat from escaping
and create a fire hazard.
• If it is unavoidable that fabrics that
contain vegetable or cooking oil or
have been contaminated by hair care
products be placed in a tumble dryer
they should first be washed in hot
water with extra detergent -this will
reduce, but not eliminate, the hazard.
3.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
3.5 Compressor
WARNING!
Risk of damage to the
appliance.
• The compressor and its system in the
tumble dryer is filled with the special
agent which is free from fluoro-chloro-
hydrocarbons. This system must stay
tight. The damage of the system can
cause a leakage.
3.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
www.electrolux.com6
4. PRODUCT DESCRIPTION
1 2
6
3
4
5
8
9
10
11
7
1Water container
2Control panel
3Appliance door
4Primary Filter
5Button for condenser door
6Airflow slots
7Adjustable feet
8Condenser door
9Condenser cover
10 Locks for condenser lid
11 Rating plate
The load door can be
installed by the user in the
opposite side. It can help to
easily put and remove the
laundry or if there is a limit to
install the appliance (see
separate leaflet).
5. CONTROL PANEL
1 2
7
3
6
5
4
8
1Programme knob
2Display
3 Time touchpad
4 Delay touchpad
5 Delicate touchpad
6 Wool Load touchpad
7 Start/Pause touchpad
8On/Off button
ENGLISH 7
Touch the touchpads with
your finger in the area with
the symbol or name of the
option. Do not wear gloves
when you operate with the
control panel. Make sure
that the control panel is
always clean and dry.
5.1 Indicators
Indicators Description
Drying phase
Cooling phase
Crease guard phase
Condenser
Water container
Filter
Delay start
Child lock
Acoustic signals
Programme duration
- Time Drying duration
- Delay start duration
6. PROGRAMME TABLE
Programmes Type of load Load (max.)1) /
Fabric mark
Cotton
Extra Dry Drying level: extra dry. 8kg/
Strong Dry2) Drying level: strong dry. 8kg/
Cupboard Dry Drying level: cupboard dry. 8kg/
www.electrolux.com8
Programmes Type of load Load (max.)1) /
Fabric mark
Iron Dry Drying level: applicable for iron. 8kg/
Synthetic
Extra Dry Drying level: extra dry. 3,5kg/
Cupboard Dry Drying level: cupboard dry. 3,5kg/
Iron Dry Drying level: applicable for iron. 3,5kg/
Easy Iron
Easy care fabrics for which a minimum of
ironing is necessary. The drying results
can be different from one type of fabric to
the other. Shake the items before you
put them in the appliance. When the pro‐
gramme is completed, Immediately re‐
move the items and put them on a hang‐
er.
1kg (or 5 shirts)/
Duvets To dry one or two duvet and pillows (with
feather, down or synthetic fillings). 3kg/
Delicates Delicate fabrics. 2kg/
Wool3)
Wool fabrics. Gentle drying washable
woollens. Remove immediately the items
when the programme is completed.
1kg
For drying sports shoes only with Drying
Rack (available as additional accessory
from www.electrolux.com.au/shop)
1 pair of sport
shoes
Refresh Refreshing a textiles that were in stor‐
age. 1kg
Time Drying
With this programme you can use the op‐
tion Time and set the programme dura‐
tion. 8kg/
ENGLISH 9
Programmes Type of load Load (max.)1) /
Fabric mark
Quick To dry cotton and synthetic fabrics, uses
low temperature. 2kg/
1) The maximum weight refers to dry items.
2) For test institutes only: Standard program for tests are specified in the AS/NZS 2442.2
document.
3) The wool drying cycle of this machine has been approved by The Woolmark Company
for the drying of machine washable wool products provided that the products are washed
and dried according to the instructions on the garment label and those issued by the manu‐
facturer of this machine. M1221. In UK, Eire, Hong Kong and India the Woolmark symbol is
a certification trademark.
7. OPTIONS
7.1 Time
This option is applicable to the Time
Drying programme and to the Wool
programme (only with the Drying Rack)..
We recommend that you set
a short duration for small
quantities of laundry or for
only one item.
•Time Drying programme: You can
set the programme duration, from a
minimum of 10 minutes to a maximum
of 2 hours. The setting of the duration
is related to the quantity of laundry in
the appliance.
•Wool programme: You can set the
programme duration, from a minimum
of 30 minutes to a maximum of 4
hours. The setting of the duration is
related to the quantity of laundry in
the appliance.
7.2 Wool Load
This option is applicable only to the Wool
programme. To get laundry more dried
press the Wool Load touchpad again
and again to increase the programme
duration.
7.3 Delicate
With this option you can set a delicate
drying programme that has a low
temperature. Use this option with a
fabrics that have the symbol on the
fabric label (e.g. acrylic, viscose).
7.4 Options table
Programmes1)
Cotton
Extra Dry ■
Strong Dry ■
Cupboard Dry ■
Iron Dry ■
www.electrolux.com10
Tabla de contenidos
Otros manuales de Secadora de Electrolux
Electrolux
Electrolux FGR641FS2 Manual de usuario
Electrolux
Electrolux EDH3684PDW Manual de usuario
Electrolux
Electrolux Electric Dryer Manual de usuario
Electrolux
Electrolux EDE 36150W Manual de usuario
Electrolux
Electrolux EDS7051 Manual de usuario
Electrolux
Electrolux EIGD55H - Gas Dryer With 8.0 cu. Ft.... Manual de usuario
Electrolux
Electrolux EID200QSW00 Manual de funcionamiento
Electrolux
Electrolux EWMED70J SS Manual de usuario
Electrolux
Electrolux EDC 505 E Guía rápida
Electrolux
Electrolux EDE 425 M Guía rápida
Electrolux
Electrolux EKDR14XAKW0 Manual de usuario
Electrolux
Electrolux EDC804Q5WB Manual de usuario
Electrolux
Electrolux TK SL5 E Manual de usuario
Electrolux
Electrolux TWL3E500 Manual de usuario
Electrolux
Electrolux EDC 504M Manual de usuario
Electrolux
Electrolux EIED55HIW - 8.0 cu. Ft. Electric Dryer Guía de inicio rápido
Electrolux
Electrolux EW8H2966IR Manual de usuario
Electrolux
Electrolux EDC 5310 Manual de usuario
Electrolux
Electrolux EW8H258S Manual de usuario
Electrolux
Electrolux EDE 425 M Guía rápida
Manuales populares de Secadora de otras marcas
BOMANN
BOMANN WT 5019 Manual de usuario
Alliance Laundry Systems
Alliance Laundry Systems TMB795C Manual de usuario
Asko
Asko T793C Manual de usuario
Kenmore
Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
Frigidaire
Frigidaire CAQE7077KW0 Manual del propietario
Bosch
Bosch WTX8HKM9SN Manual de usuario
