Electrolux 864500 Manual de usuario

Electrolux Dishwashing

Air Drying Tunnel for WTM

The Electrolux Dishwashing range is produced for customers with the highest conceivable

demands in efficiency, economy and ergonomics dishwashing operation. The product

range comprises glasswashers, undercounter dishwashers, hood type dishwashers, rack

type dishwashers, flight type dishwashers and pot and pan washers. The Air-Drying

Tunnels complete the rack type dishwashing range.

864500

EASY TO INSTALL

• It is designed to be placed on

any Electrolux modular (WTM)

rack type dishwasher.



EASY TO USE

• The air drying tunnel is available

in two versions: 900mm for

machines faster than 165

rack/hour and 600mm suited for

machines slower than 165

rack/hour.

• The feeding system from the

dishwasher and the curve will

automatically move the racks

through the Air-Drying Tunnel.

• The drying zone removes every

trace of water from the crockery,

through a high powered fan that

extracts dry air from outside,

providing dry plates at a low

temperature.

• The automatic start/stop

function switches off the machine

when not in use, to save energy.

• Electronically controlled to

optimize the drying results.

EASY TO CLEAN

• The hygienic design provides

easy cleaning through a door that

gives full accessibility to the

interior of the tunnel.



EASY TO MAINTAIN

• 304 AISI stainless steel front,

side and top panels.



EASY ON THE ENVIRONMENT

• Developed and produced in an

ISO 9001 and ISO 14001 certified

factory.

• CFC free packaging.

Electrolux Dishwashing

Air Drying Tunnel for WTM

Internet: http://www.electrolux.com/foodservice

IEBG0102010-06-09Subject to change without notice

Steam consumption peak - Kg/h 22 22

relative dynamic pressure bar - min/max 1.5, 3 1.5, 3

Steam supply

electric 9.4 9.4 8.5 8.5 1.1 1.1

Power - kW

height 1922 1922 1771 1771 1922 1922

depth 884 884 884 884 884 884

width 900 900 600 600 900 900

External dimensions - mm

Feeding direction from Right to Left from Left to Right from Right to Left from Left to Right from Right to Left from Left to Right

Power supply Electric Electric Electric Electric Steam & Electric Steam & Electric

TECHNICAL DATA

ADTLERMD

864500

ADTLELMD

864501

ADTERMD

864510

ADTELMD

864511

ADTLSRMD

864514

ADTLSLMD

864515

Electrolux Dishwashing

Air Drying Tunnel for WTM

Internet: http://www.electrolux.com/foodservice

IEBG0102010-06-09Subject to change without notice

EI - Electrical connection 400 V, 3N, 50/60 400 V, 3N, 50/60

D - Water drain G 1 1/2" G 1 1/2"

LEGEND

ADTLERMD

864500

ADTLELMD

864501

864500, 864501

Electrolux Dishwashing

Air Drying Tunnel for WTM

Internet: http://www.electrolux.com/foodservice

IEBG0102010-06-09Subject to change without notice

EI - Electrical connection 400 V, 3N, 50/60 400 V, 3N, 50/60

D - Water drain G 1 1/2" G 1 1/2"

LEGEND

ADTERMD

864510

ADTELMD

864511

864510, 864511

Electrolux Dishwashing

Air Drying Tunnel for WTM

Internet: http://www.electrolux.com/foodservice

IEBG0102010-06-09Subject to change without notice

EI - Electrical connection 400 V, 3N, 50

D - Water drain G 1 1/2"

LEGEND

ADTLSRMD

864514

Electrolux Dishwashing

Air Drying Tunnel for WTM

Internet: http://www.electrolux.com/foodservice

IEBG0102010-06-09Subject to change without notice

EI - Electrical connection 400 V, 3N, 50

D - Water drain G 1 1/2"

LEGEND

ADTLSLMD

864515
