Electrolux Dishwashing

Glasswashers WT2

The Electrolux Dishwashing range is produced for customers with the highest conceivable demands for good

efficiency, economy and ergonomics for dishwashing operation. The product range comprises glasswashers,

undercounter dishwashers, hood type dishwashers, rack type dishwashers, flight type dishwashers and pot

and pan washers. The glasswasher range consists of models with different charging holes, in order to handle

glasses up to 290 mm height.

402030

EASY TO INSTALL AND MAINTAIN

• Most models are equipped with

a drain pump to facilitate the

installation.

• Rinse booster pump available to

be installed on site or included in

some specific models.

• Simple service from the front.

EASY TO CLEAN

• The glasswashers have smooth

surfaces and a fully pressed wash

tank with rounded corners to

facilitate cleaning.

• All the internal elements (arms

and filter) are easily extractable.

• 304 AISI stainless steel front and

side panels, load bearing frame,

wash tank, tank filter and wash

and rinse arms.

EASY TO USE

• Built-in rinse water heater to

increase the temperature of the

final rinse water.

• Built-in rinse aid dispenser for

perfect rinsing results.

• Simple control panel.

• Two cycles (120 and 300

seconds); the longer cycle allows

the washing of crockery with a

higher degree of soil.

• An extra program for cold rinsing

of beer glasses.

CONSTRUCTION FEATURES

• Double skinned construction.

• Wash/rinse arms and nozzles in

stainless steel.

• Completely closed on the

reverse by a cover plate.

• All models finished in top quality

materials to aid durability.

EASY ON THE ENVIRONMENT

• 98% recyclable by weight.

• CFC free packaging.

• Low noise level.

• Developed and produced in ISO

9001 and ISO 14001 certified

factory.

Electrolux Dishwashing

Glasswashers WT2

Internet: http://www.electrolux.com/foodservice

IAB0102011-05-16Subject to change without notice

Net weight - kg. 37 37 37 37 37 37 37 37 37 37 37

total power 3.3 3.3 4.8 3.3 3.3 3.3 3.3 4.8 3.3 3.3 3.3

drain pump 0.034 0.034 0.034 0.034 0.034 0.034 0.034 0.034 0.034

Power - kW

Boiler elements - kW 3 3 4.5 3 3 3 3 4.5 3 3 3

Boiler capacity - lt. 5 5 5 5 5 5 5 5 5 5 5

water consumption - lt./cycle 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3 2.3

temperature during rinse - °C 80-90 80-90 80-90 80-90 80-90 80-90 80-90 80-90 80-90 80-90 80-90

duration - sec. 16 16 16 16 16 16 16 16 16 16 16

Hot rinse cycle

water consumption - lt./cycle 2 2 2 2 2 2 2 2 2 2 2

temperature - °C 10 10 10 10 10 10 10 10 10 10 10

duration - sec. 10 10 10 10 10 10 10 10 10 10 10

Cold rinse cycle

electrical elements - kW 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8

power pump - kW 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3

tank capacity - lt. 6 6 6 6 6 6 6 6 6 6 6

temperature -°C 55-65 55-65 55-65 55-65 55-65 55-65 55-65 55-65 55-65 55-65 55-65

Washing cycle

height 290 290 290 290 290 290 290 290 290 290 290

depth 400 400 400 400 400 400 400 400 400 400 400

width 400 400 400 400 400 400 400 400 400 400 400

Cell dimensions - mm

height 715 715 715 715 715 715 715 715 715 715 715

depth 565 565 565 565 565 565 565 565 565 565 565

width 460 460 460 460 460 460 460 460 460 460 460

External dimensions - mm

Basket capacity/h 30 30 30 30 30 30 30 30 30 30 30

Duration cycles - sec. 120/300 120/300 120/300 120/300 120/300 120/300 120/300 120/300 120/300 120/300 120/300

N° of cycles 2 2 2 2 2 2 2 2 2 2 2

Detergent dispenser ● ● ● ● ●

Rinse Booster Pump ● ● ●

Drain pump ● ● ● ● ● ● ● ● ●

Water softener ● ● ● ● ● ● ●

Cold rinse ● ● ● ● ● ● ● ● ● ● ●

hardness - °d 4-8 >8 4-8 >8 >8 >8 >8 4-8 4-8 >8 >8

hardness - °f 7-14 >14 7-14 >14 >14 >14 >14 7-14 7-14 >14 >14

temperature - °C 10 10 10 10 10 10 10 10 10 10 10

pressure min. , max. - bar 2, 3 2, 3 2, 3 2, 3 2, 3 2, 3 2, 3 2, 3 2, 3 2 2

Water supply

TECHNICAL DATA

WT2

402061

WT2N

402035

WT2N4

402047

WT2TOP

402044

WT2TOP60

402015

WT2WSDP

402030

WT2WSDPD

402032

WT2DPD3

402067

WT2DPDI

402016

WT2WSDPDI

402017

WT2TOPDI

402019

Electrolux Dishwashing

Glasswashers WT2

Internet: http://www.electrolux.com/foodservice

IAB0102011-05-16Subject to change without notice

YELLOW CUTLERY CONTAINER 864242 864242 864242 864242 864242 864242 864242 864242 864242 864242 864242

ROUND BASKET KIT WITH SQUARE FRAME 867057 867057 867057 867057 867057 867057 867057 867057 867057 867057 867057

RINSE BOOSTER PUMP-SING.TANK

PRESSURE DW

864051 864051 864051 864051 864051 864051 864051

KIT TO MEASURE TOTAL/PART.WATER

HARDNESS

864050 864050 864050 864050 864050 864050 864050 864050 864050 864050 864050

KIT 4 PLASTIC BOXES FOR

CUTLERY-YELLOW

865574 865574 865574 865574 865574 865574

INSERT FOR"FLUTE"GLASSES 867058 867058 867058 867058 867058 867058 867058 867058 867058 867058 867058

INSERT FOR 7 PLATES DIAM. 240 MM 867062 867062 867062 867062 867062 867062 867062 867062 867062 867062 867062

INSERT FOR 14 SAUCERS 867060 867060 867060 867060 867060 867060 867060 867060 867060 867060 867060

INCLINED INSERT FOR CUPS 867061 867061 867061 867061 867061 867061 867061 867061 867061 867061 867061

FILTER FOR TOTAL DEMINERALIZATION 864015 864015 864015 864015 864015 864015

FILTER FOR PARTIAL DEMINERALIZATION 864017 864017 864017 864017 864017 864017

COVER GRID FOR SMALL/LIGHT ITEMS IN

RACK

867016 867016 867016 867016 867016 867016 867016 867016 867016 867016 867016

BASKET FOR GLASSES-395X395X200 MM 867054 867054 867054 867054 867054 867054 867054 867054 867054 867054 867054

BASKET FOR GLASSES-395X395X100 MM 867053 867053 867053 867053 867053 867053

BASKET FOR

GLASSES+SAUCERS/CUTLERY INS.

867055 867055 867055 867055 867055 867055 867055 867055 867055 867055 867055

BASKET FOR 16/8 PLATES DIAM.190/240

867052 867052 867052 867052 867052 867052 867052 867052 867052 867052 867052

BASKET F.GLASSES-ANGLED

BASE-395X395X200

867056 867056 867056 867056 867056 867056 867056 867056 867056 867056 867056

ACCESSORIES

BASKET FOR GLASSES-395X395X200 MM 1 1 1 1 1 1 1 1

BASKET F.GLASSES-ANGLED

BASE-395X395X200

1 1 1

INCLUDED ACCESSORIES

WT2

402061

WT2N

402035

WT2N4

402047

WT2TOP

402044

WT2TOP60

402015

WT2WSDP

402030

WT2WSDPD

402032

WT2DPD3

402067

WT2DPDI

402016

WT2WSDPDI

402017

WT2TOPDI

402019

Electrolux Dishwashing

Glasswashers WT2

Internet: http://www.electrolux.com/foodservice

IAB0102011-05-16Subject to change without notice

EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50

D - Water drain 22mm 22mm

CWI - Cold water inlet G 3/4" G 3/4"

LEGEND

WT2

402061

WT2N

402035

402061, 402035

Electrolux Dishwashing

Glasswashers WT2

Internet: http://www.electrolux.com/foodservice

IAB0102011-05-16Subject to change without notice

EI - Electrical connection 400 V, 3N, 50 230 V, 1N, 50 230 V, 1N, 50

D - Water drain 27mm 27mm 27mm

CWI - Cold water inlet G 3/4" G 3/4" G 3/4"

LEGEND

WT2N4

402047

WT2TOP

402044

WT2WSDP

402030

402047, 402030, 402044

Electrolux Dishwashing

Glasswashers WT2

Internet: http://www.electrolux.com/foodservice

IAB0102011-05-16Subject to change without notice

EI - Electrical connection 230 V, 1N, 60 230 V, 1N, 50 400 V, 3N, 50 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

D - Water drain 27mm 27mm 27mm 22mm 27mm 27mm

CWI - Cold water inlet G 3/4" G 3/4" G 3/4" G 3/4" G 3/4" G 3/4"

LEGEND

WT2TOP60

402015

WT2WSDPD

402032

WT2DPD3

402067

WT2DPDI

402016

WT2WSDPDI

402017

WT2TOPDI

402019

402015, 402019, 402017, 402016, 402067, 402032
