GA60LVCN EN DISHWASHER USER MANUAL 2

DE GESCHIRRSPÜLER BENUTZERINFORMATION 21

CONTENTS

1. SAFETY INFORMATION...................................................................................... 3

2. SAFETY INSTRUCTIONS.....................................................................................4

3. PRODUCT DESCRIPTION................................................................................... 5

4. CONTROL PANEL...............................................................................................6

5. PROGRAMMES...................................................................................................6

6. SETTINGS........................................................................................................... 8

7. OPTIONS...........................................................................................................11

8. BEFORE FIRST USE..........................................................................................11

9. DAILY USE........................................................................................................ 12

10. HINTS AND TIPS............................................................................................. 14

11. CARE AND CLEANING....................................................................................15

12. TROUBLESHOOTING......................................................................................17

13. TECHNICAL INFORMATION............................................................................18

14. GARANTIE, GARANZIA, GUARANTEE ............................................................18

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

1.1 General Safety

•This appliance is intended to be used in household and

similar applications such as:

–farm houses; staff kitchen areas in shops, offices and

other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and maximum)

must be between 0.5 (0.05) / 8 (0.8) bar (Mpa)

•Obey the maximum number of 13 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

•Do not use water spray and steam to clean the

appliance.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

1.2 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

ENGLISH 3

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Cleaning and user maintenance shall not be made by

children without supervision.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Obey the installation instruction

supplied with the appliance.

• Make sure that the appliance is

installed below and adjacent to safe

structures.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the mains cable need to be

replaced, this must be carried out by

our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the E.E.C.

Directives.

• Only for UK and Ireland. The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use a 13 amp ASTA (BS

1362) fuse.

2.3 Water connection

• Make sure not to cause damage to the

water hoses.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

• The water inlet hose has a safety valve

and a sheath with an inner mains

cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately disconnect the mains plug

www.electrolux.com4

from the mains socket. Contact the

Authorised Service Centre to replace

the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are dangerous.

Obey the safety instructions on the

detergent packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent on

the dishes.

• The appliance can release hot steam if

you open the door while a programme

operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

9 8

11 10

1Top spray arm

2Upper spray arm

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Cutlery basket

11 Lower basket

12 Upper basket

3.1 Beam-on-Floor

The Beam-on-Floor is a light that shows

on the kitchen floor below the appliance

door.

ENGLISH 5

• When the programme starts, a red light

comes on and stays on for all the

duration of the programme.

• When the programme is completed, a

green light comes on.

• When the appliance has a malfunction,

the red light flashes.

The Beam-on-Floor goes off

when the appliance is

deactivated.

4. CONTROL PANEL

1 2 83 4 5 6 7 9

1On/off button

2Display

3Delay button

4Program button

5MyFavourite button

6TimeSaver button

7Multitab button

8Reset button

9Indicators

4.1 Indicators

Indicator Description

End indicator.

Salt indicator. It is always off while the programme operates.

Rinse aid indicator. It is always off while the programme operates.

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme phases Options

ECO 1)

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• TimeSaver

AUTO 2)

• All

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash from 45 °C to

70 °C

• Rinses

• Dry

www.electrolux.com6

Programme Degree of soil

Type of load

Programme phases Options

70° Pro 3)

• Heavy soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• TimeSaver

45° Gläser

• Normal or light

soil

• Delicate crock-

ery and glass-

ware

• Wash 45 °C

• Rinses

• Dry

30 Minuten 4)

• Fresh soil

• Crockery and

cutlery

• Wash 60 °C

• Rinses

Extra SILENT 5)

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

1) With this programme you have the most efficient use of water and energy consumption for

crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto-

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) This programme has a high temperature rinsing phase for better hygiene results. During the

rinsing phase, the temperature stays at 70 °C for at least 10 minutes.

4) With this programme you can wash a load with fresh soil. It gives good washing results in a

short time.

5) This is the most silent programme. The pump works at a very low speed to decrease the

level of noise. Because of the low speed, the programme duration is long.

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

ECO

10.2 0.932 225

AUTO

7 - 14 0.6 - 1.4 40 - 150

70° Pro

12.5 - 14.5 1.4 - 1.6 154 - 164

45° Gläser

12 - 14 0.7 - 0.9 75 - 85

30 Minuten

10 0.9 30

ENGLISH 7

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

Extra SILENT

9 - 10 1.0 - 1.2 219 - 229

1) The pressure and the temperature of the water, the variations of the mains supply, the op-

tions and the quantity of dishes can change the values.

5.2 Information for test institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of the

acoustic signal for end of programme.

• The deactivation of the rinse aid

dispenser when you want to use the

Multitab option without rinse aid.

• The level of rinse aid according to the

required dosage.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the display shows the

programme number P1.

When you activate the appliance, usually it

is in programme selection mode.

However, if this does not happen, you can

set the programme selection mode in the

following way:

Press and hold Reset until the appliance

is in programme selection mode.

6.2 The water softener

The water softener removes minerals from

the water supply, which would have a

detrimental effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water in

your area. It is important to set the right

level of the water softener to assure good

washing results.

Water hardness

German de-

grees (°dH)

French de-

grees (°fH)

mmol/l Clarke de-

grees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

www.electrolux.com8

German de-

grees (°dH)

French de-

grees (°fH)

mmol/l Clarke de-

grees

Water softener

level

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , and start

to flash and the display is blank.

2. Press .

• The indicators , and go

off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press again and again to change

the setting.

4. Press the on/off button to confirm the

setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

You can set the released quantity of rinse

aid between level 1 (minimum quantity)

and level 6 (maximum quantity). Level 0

will deactivate the rinse aid dispenser and

no rinse aid will be released.

Factory setting: level 4.

How to set the rinse aid level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , and start

to flash and the display is blank.

2. Press .

• The indicators , and go

off.

•The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 4.

– The levels of rinse aid are from

0A to 6A.

– Level 0 = no rinse aid is

released.

3. Press again and again to change

the setting.

4. Press the on/off button to confirm the

setting.

ENGLISH 9

6.4 Use of rinse aid and multi-

tablets

When you activate the option Multitab, the

rinse aid dispenser continues to release

rinse aid. However you can deactivate the

rinse aid dispenser. In this case the drying

results may not be satisfactory.

With the rinse aid dispenser deactivated,

the rinse aid indicator is always off.

How to deactivate the rinse aid

dispenser

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , and start

to flash and the display is blank.

2. Press .

• The indicators , and go

off.

• The indicator continues to flash.

• The display shows the current

setting: = rinse aid dispenser

activated.

3. Press to change the setting. =

rinse aid dispenser deactivated.

The rinse aid indicator goes off.

4. Press the on/off button to confirm the

setting.

6.5 MyFavourite

With this option you can set and save the

programme that you use more frequently.

You can only save 1 programme. A new

setting cancels the previous one.

How to save the MyFavourite

programme

1. Set the programme that you want to

save

You can also set applicable options

together with the programme.

2. Press and hold until the related

indicator comes on with fixed light.

How to set the MyFavourite

programme

Press .

• The indicators that are related to

the MyFavourite programme and

options come on.

• The display shows the number and

the duration of the programme.

6.6 Acoustic signals

Acoustic signals sound when a

malfunction of the appliance occurs. It is

not possible to deactivate these acoustic

signals.

There is also an acoustic signal that

sounds when the programme is

completed. By default this acoustic signal

is deactivated but it is possible to activate

it.

How to activate the acoustic

signal for the end of programme

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , and start

to flash and the display is blank.

2. Press

• The indicators , and go

off.

• The indicator continues to

flash.

• The display shows the current

setting: = Acoustic signal off.

3. Press to change the setting.

= Acoustic signal on.

4. Press the on/off button to confirm the

setting.

www.electrolux.com10

Otros manuales para GA60LVCN

Tabla de contenidos

Idiomas:

Otros manuales de Lavavajillas de Electrolux

Electrolux

Electrolux 154743801 Guía del usuario

Electrolux

Electrolux ESF 6120 Manual de usuario

Electrolux

Electrolux ESF 647 Manual de usuario

Electrolux

Electrolux 587.14131101 Manual de usuario

Electrolux

Electrolux GLDB957JB Manual de usuario

Electrolux

Electrolux ESF8635ROW Manual de usuario

Electrolux

Electrolux ESL5321LO Manual de usuario

Electrolux

Electrolux GS 24 CH Manual de usuario

Electrolux

Electrolux WT65E Manual de usuario

Electrolux

Electrolux KECA7305L Manual de usuario

Electrolux

Electrolux ESF 6128 Manual de usuario

Electrolux

Electrolux ASF66830 Manual de usuario

Electrolux

Electrolux GA60SLICSP Manual de usuario

Electrolux

Electrolux Green&Clean EUCAI60 Manual de usuario

Electrolux

Electrolux ESF 64075 Manual de usuario

Electrolux

Electrolux EDW5505EPS - ICON - Dishwasher Manual de usuario

Electrolux

Electrolux ESF 63020 Manual de usuario

Electrolux

Electrolux Zanussi DA 4441 Manual de usuario

Electrolux

Electrolux FAVORIT 35010 I Manual de usuario

Electrolux

Electrolux 9JEDQU Manual de usuario

Electrolux

Electrolux TRICITY BENDIX BDW 55 Manual de usuario

Electrolux

Electrolux FAVORIT 65411 VI Manual de usuario

Electrolux

Electrolux 534100 Manual de usuario

Electrolux

Electrolux ESL4500LO Manual de usuario

Manuales populares de Lavavajillas de otras marcas

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
