GA60GLVS EN DISHWASHER USER MANUAL 2

DE GESCHIRRSPÜLER BENUTZERINFORMATION 26

CONTENTS

1. SAFETY INFORMATION...................................................................................... 3

2. SAFETY INSTRUCTIONS.....................................................................................4

3. PRODUCT DESCRIPTION................................................................................... 6

4. CONTROL PANEL...............................................................................................7

5. PROGRAMMES...................................................................................................7

6. SETTINGS........................................................................................................... 9

7. OPTIONS...........................................................................................................13

8. BEFORE FIRST USE..........................................................................................14

9. DAILY USE........................................................................................................ 15

10. HINTS AND TIPS............................................................................................. 17

11. CARE AND CLEANING....................................................................................18

12. TROUBLESHOOTING......................................................................................20

13. TECHNICAL INFORMATION............................................................................24

14. GUARANTEE ..................................................................................................24

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible for any injuries or damages that are the result

of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning the use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•This appliance is intended to be used in household and

similar applications such as:

–farm houses; staff kitchen areas in shops, offices and

other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and maximum)

must be between 0.5 (0.05) / 8 (0.8) bar (MPa)

•Obey the maximum number of 15 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

ENGLISH 3

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam to

clean the appliance.

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Follow the installation instruction

supplied with the appliance.

• Make sure that the appliance is

installed below and adjacent to safe

structures.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the mains cable need to be

replaced, this must be carried out by

our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the E.E.C.

Directives.

• Only for UK and Ireland. The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use fuse: 13 amp ASTA

(BS 1362).

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

www.electrolux.com4

• Without electrical power, the water

protection system is not active. In this

case there is a risk of flooding.

• The water inlet hose has a safety valve

and a sheath with an inner mains

cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately close the water tap and

disconnect the mains plug from the

mains socket. Contact the Authorised

Service Centre to replace the water

inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are dangerous.

Obey the safety instructions on the

detergent packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent on

the dishes.

• The appliance can release hot steam if

you open the door while a programme

operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Internal light

WARNING!

Risk of injury.

• This appliance has an internal lamp

that comes on when you open the

door and goes off when the door is

closed.

• The lamp in this appliance is not

suitable for household room

illumination.

• To replace the lamp, contact the

Service.

2.6 Service

• Contact the Authorised Service Centre

to repair the appliance. We

recommend only the use of original

spare parts.

• When you contact the Authorised

Service Centre, ensure that you have

the following information that is

available on the rating plate.

Model :

PNC :

Serial Number :

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

10 9 67

1Top spray arm

2Upper spray arm

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Lower basket

11 Upper basket

12 Cutlery drawer

3.1 TimeBeam

The TimeBeam is a display that is shown

on the floor below the appliance door.

• When the programme starts, the

programme duration comes on.

• When the programme is completed,

0:00 and CLEAN come on.

• When the delay start starts, the

countdown duration and DELAY come

on.

• When the appliance has a malfunction,

an alarm code appears.

www.electrolux.com6

When AirDry is activated

during the drying phase, the

projection on the floor may

not be completely visible. To

check the remaining time of

the running programme, look

at the control panel display.

4. CONTROL PANEL

123456789

1On/off button

2Display

3Delay button

4Program button

5MyFavourite button

6TimeSaver button

7XtraDry button

8ExtraHygiene button

9Indicators

4.1 Indicators

Indicator Description

Rinse aid indicator. It is always off while the programme operates.

Salt indicator. It is always off while the programme operates.

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme pha-

ses

Options

ECO 1)

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• ExtraHygiene

• TimeSaver

• XtraDry

AutoSense 2)

• All

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash from 45 °C

to 70 °C

• Rinses

• Dry

• ExtraHygiene

• XtraDry

ENGLISH 7

Programme Degree of soil

Type of load

Programme pha-

ses

Options

Pro

• Heavy soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• TimeSaver

• XtraDry

Quick 30 Min. 3)

• Fresh soil

• Crockery and

cutlery

• Wash 60 °C

• Rinses

• ExtraHygiene

• XtraDry

Gläser

• Normal or light

soil

• Delicate crockery

and glassware

• Wash 45 °C

• Rinses

• Dry

• XtraDry

ExtraSilent 4)

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• XtraDry

Vorspülen 5)

• All • Prewash

1) With this programme you have the most efficient use of water and energy consumption for

crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto-

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) With this programme you can wash a load with fresh soil. It gives good washing results in a

short time.

4) This is the most silent programme. The pump works at a very low speed to decrease the

level of noise. Because of the low speed, the programme duration is long.

5) With this programme you can quickly rinse dishes to prevent remains of food to bond on

dishes and odours to form in the appliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

ECO

11 0.857 225

AutoSense

7 - 14 0.6 - 1.6 40 - 154

Pro

12.5 - 14.5 1.4 - 1.7 160 - 170

Quick 30 Min.

10 0.9 30

www.electrolux.com8

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

Gläser

12 - 14 0.7 - 0.9 84 - 94

ExtraSilent

9 - 10 1.1 - 1.3 219 - 229

Vorspülen

4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the op-

tions and the quantity of dishes can change the values.

5.2 Information for test institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of the

acoustic signal for end of programme.

• The selection of the colour for

TimeBeam.

• The activation or deactivation of the

rinse aid empty notification.

• The level of rinse aid according to the

required dosage.

• The activation or the deactivation of

AirDry.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the display shows the

programme number P1.

When you activate the appliance, usually it

is in programme selection mode.

However, if this does not happen, you can

set the programme selection mode in the

following way:

Press and hold simultaneously and

until the appliance is in programme

selection mode.

6.2 The water softener

The water softener removes minerals from

the water supply, which would have a

detrimental effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water in

your area. It is important to set the right

level of the water softener to assure good

washing results.

ENGLISH 9

Water hardness

German de-

grees (°dH)

French de-

grees (°fH)

mmol/l Clarke de-

grees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

Whether you use a standard detergent

or multi-tabs (with or without salt), set

the proper water hardness level to

keep the salt refill indicator active.

Multi-tabs containing salt are

not effective enough to soften

hard water.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , , ,

and start to flash and the display is

blank.

2. Press .

•The indicators , , , and

go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press again and again to change

the setting.

4. Press the on/off button to confirm the

setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

You can set the released quantity of rinse

aid between level 1 (minimum quantity)

and level 6 (maximum quantity). Level 0

will deactivate the rinse aid dispenser and

no rinse aid will be released.

Factory setting: level 4.

How to set the rinse aid level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , , , ,

and start to flash and the display is

blank.

www.electrolux.com10

Otros manuales para GA60GLVS

Tabla de contenidos

Idiomas:

Otros manuales de Lavavajillas de Electrolux

Electrolux

Electrolux ESF5559LOX Manual de usuario

Electrolux

Electrolux ESF6210LOK Manual de usuario

Electrolux

Electrolux ESF 6610ROW Manual de usuario

Electrolux

Electrolux 5000 Series Manual de usuario

Electrolux

Electrolux GA60LI221 Manual de usuario

Electrolux

Electrolux FAVORIT 44010 VIL Manual de usuario

Electrolux

Electrolux ESL5350LO Manual de usuario

Electrolux

Electrolux EIDW6405HT - Fully Integrated Dishwasher Manual de usuario

Electrolux

Electrolux FAVORIT 88080 i Manual de usuario

Electrolux

Electrolux 534108 Manual de usuario

Electrolux

Electrolux ESL 6115 Manual de usuario

Electrolux

Electrolux EUC1WS Manual de usuario

Electrolux

Electrolux EIDW5705PB0A Manual de usuario

Electrolux

Electrolux GA60PLVC Manual de usuario

Electrolux

Electrolux ESF 47015 Manual de usuario

Electrolux

Electrolux EIDW1805KS Guía del usuario

Electrolux

Electrolux GA930IFWE Manual de usuario

Electrolux

Electrolux 534074 Manual de usuario

Electrolux

Electrolux EI24ID81SS0A Manual de usuario

Electrolux

Electrolux ESF 2200 DW Manual de usuario

Electrolux

Electrolux ESS47410SX Manual de usuario

Electrolux

Electrolux ESF4510LOX Manual de usuario

Electrolux

Electrolux EEM69300IX Manual de usuario

Electrolux

Electrolux GS60AV Manual de usuario

Manuales populares de Lavavajillas de otras marcas

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
