ESL4500LO EN DISHWASHER USER MANUAL

CONTENTS

1. SAFETY INFORMATION...................................................................................... 2

2. SAFETY INSTRUCTIONS.....................................................................................4

3. PRODUCT DESCRIPTION................................................................................... 5

4. CONTROL PANEL............................................................................................... 6

5. PROGRAMMES...................................................................................................6

6. SETTINGS........................................................................................................... 8

7. OPTIONS...........................................................................................................10

8. BEFORE FIRST USE..........................................................................................11

9. DAILY USE........................................................................................................ 12

10. HINTS AND TIPS............................................................................................. 14

11. CARE AND CLEANING....................................................................................15

12. TROUBLESHOOTING......................................................................................17

13. TECHNICAL INFORMATION............................................................................ 18

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be

safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following

data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

www.electrolux.com2

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

1.1 General Safety

•This appliance is intended to be used in household and

similar applications such as:

–farm houses; staff kitchen areas in shops, offices and

other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and maximum)

must be between 0.5 (0.05) / 8 (0.8) bar (Mpa)

•Obey the maximum number of 9 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before maintenance, deactivate the appliance and

disconnect the mains plug from the mains socket.

•Do not use water spray and steam to clean the

appliance.

•The ventilation openings in the base (if applicable) must

not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

1.2 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

ENGLISH 3

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Keep all detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Cleaning and user maintenance shall not be made by

children without supervision.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Obey the installation instruction

supplied with the appliance.

• Make sure that the appliance is

installed below and adjacent to safe

structures.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

mains plug and to the mains cable.

Should the mains cable need to be

replaced, this must be carried out by

our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the E.E.C.

Directives.

• Only for UK and Ireland. The appliance

has a 13 amp mains plug. If it is

necessary to change the fuse in the

mains plug, use fuse: 13 amp ASTA

(BS 1362).

2.3 Water connection

• Make sure not to cause damage to the

water hoses.

• Before you connect the appliance to

new pipes or pipes not used for a long

time, let the water flow until it is clean.

• The first time you use the appliance,

make sure that there is no leakage.

• The water inlet hose has a safety valve

and a sheath with an inner mains

cable.

WARNING!

Dangerous voltage.

• The water inlet hose has an external

transparent sheath. If the hose is

www.electrolux.com4

damaged, the water in the hose

becomes dark.

• If the water inlet hose is damaged,

immediately disconnect the mains plug

from the mains socket. Contact the

Authorised Service Centre to replace

the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are dangerous.

Obey the safety instructions on the

detergent packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent on

the dishes.

• The appliance can release hot steam if

you open the door while a programme

operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Service

• Contact the Authorised Service Centre

to repair the appliance. We

recommend only the use of original

spare parts.

• When you contact the Authorised

Service Centre, ensure that you have

the following information that is

available on the rating plate.

Model :

PNC :

Serial Number :

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

9 8

10 56

1Upper spray arm

2Lower spray arm

3Filters

4Rating plate

5Salt container

6Air vent

ENGLISH 5

7Rinse aid dispenser

8Detergent dispenser

9Cutlery basket

10 Lower basket

11 Upper basket

3.1 Beam-on-Floor

The Beam-on-Floor is a light that shows

on the kitchen floor below the appliance

door.

• When the programme starts, a red light

comes on and stays on for all the

duration of the programme.

• When the programme is completed, a

green light comes on.

• When the programme is completed,

the red light goes off.

• When the appliance has a malfunction,

the red light flashes.

The Beam-on-Floor goes off

when the appliance is

deactivated.

4. CONTROL PANEL

182 3 4 5 6 7 9

1On/off button

2Display

3Delay button

4Program button

5MyFavourite button

6Multitab button

7EnergySaver button

8Reset button

9Indicators

4.1 Indicators

Indicator Description

Salt indicator. It is always off while the programme operates.

Rinse aid indicator. It is always off while the programme operates.

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme phases Options

• Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• EnergySaver

• Multitab

www.electrolux.com6

Programme Degree of soil

Type of load

Programme phases Options

• All

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash from 45 °C to

70 °C

• Rinses

• Dry

• EnergySaver

• Multitab

P3 • Heavy soil

• Crockery, cut-

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• EnergySaver

• Multitab

• Fresh soil

• Crockery and

cutlery

• Wash 60 °C or 65 °C

• Rinses

• Multitab

• All • Prewash

1) With this programme you have the most efficient use of water and energy consumption for

crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto-

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) With this programme you can wash a load with fresh soil. It gives good washing results in a

short time.

4) With this programme you can quickly rinse dishes to prevent remains of food to bond on

dishes and odours to form in the appliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

P1 9.5 0.789 225

P2 6 - 11 0.5 - 1.2 40 - 140

P3 11 - 13 1.0 - 1.2 130 - 150

P4 8 0.8 30

P5 4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the op-

tions and the quantity of dishes can change the values.

ENGLISH 7

5.2 Information for test institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of the

acoustic signal for end of programme.

• The deactivation of the rinse aid

dispenser when you want to use the

Multitab option without rinse aid.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the display shows the

programme number P1.

When you activate the appliance, usually it

is in programme selection mode.

However, if this does not happen, you can

set the programme selection mode in the

following way:

Press and hold Reset until the appliance

is in programme selection mode.

6.2 The water softener

The water softener removes minerals from

the water supply, which would have a

detrimental effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water in

your area. It is important to set the right

level of the water softener to assure good

washing results.

Water hardness

German de-

grees (°dH)

French de-

grees (°fH)

mmol/l Clarke de-

grees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

www.electrolux.com8

German de-

grees (°dH)

French de-

grees (°fH)

mmol/l Clarke de-

grees

Water softener

level

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start to

flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press again and again to change

the setting.

4. Press the on/off button to confirm the

setting.

6.3 The rinse aid dispenser

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

Use of rinse aid and multi-tablets

When you activate the option Multitab, the

rinse aid dispenser continues to release

rinse aid. However you can deactivate the

rinse aid dispenser. In this case the drying

results may not be satisfactory.

With the rinse aid dispenser deactivated,

the rinse aid indicator is always off.

How to deactivate the rinse aid

dispenser

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start to

flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting.

– = rinse aid dispenser

activated.

– = rinse aid dispenser

deactivated.

3. Press to change the setting.

4. Press the on/off button to confirm the

setting.

6.4 Acoustic signals

Acoustic signals sound when a

malfunction of the appliance occurs. It is

not possible to deactivate these acoustic

signals.

There is also an acoustic signal that

sounds when the programme is

completed. By default this acoustic signal

is deactivated but it is possible to activate

it.

ENGLISH 9

How to activate the acoustic

signal for the end of programme

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously and until

the indicators , and start to

flash and the display is blank.

2. Press .

• The indicators and go off.

• The indicator continues to

flash.

• The display shows the current

setting:

– = Acoustic signal off.

– = Acoustic signal on.

3. Press to change the setting.

4. Press the on/off button to confirm the

setting.

7. OPTIONS

Desired options must be

activated every time before

you start a programme.

It is not possible to activate or

deactivate options while a

programme is running.

Not all options are compatible

with each other. If you have

selected non compatible

options, the appliance will

automatically deactivate one

or more of them. Only the

indicators of the options still

active will stay on.

7.1 Multitab

Activate this option when you use multi-

tablets that integrate the salt, rinse aid and

detergent functions. They can also contain

other cleaning or rinsing agents.

This option deactivates the release of salt.

The salt indicator does not come on.

With the use of this option the programme

duration is prolonged to increase the

cleaning and drying results with the use of

multi-tablets.

Multitab is not a permanent option and

must be selected at every cycle.

How to activate Multitab

Press .

The related indicator comes on.

7.2 MyFavourite

With this option you can set and save the

programme that you use more frequently.

You can only save 1 programme. A new

setting cancels the previous one.

How to save the MyFavourite

programme

1. Set the programme that you want to

save

You can also set applicable options

together with the programme.

2. Press and hold until the related

indicator comes on with fixed light.

How to set the MyFavourite

programme

Press .

• The indicators that are related to

the MyFavourite programme and

options come on.

• The display shows the number and

the duration of the programme.

7.3 EnergySaver

This option decreases the temperature of

the last rinsing phase and consequently

also the energy consumption

(approximately -25%).

Dishes can still be wet once the

programme is completed.

The duration of the programme will be

shorter.

www.electrolux.com10

Otros manuales para ESL4500LO

Tabla de contenidos

Otros manuales de Lavavajillas de Electrolux

Electrolux

Electrolux ESF 4160 Manual de usuario

Electrolux

Electrolux ESI66050 Manual de usuario

Electrolux

Electrolux EEC87400W Manual de usuario

Electrolux

Electrolux EEQ42200L Manual de usuario

Electrolux

Electrolux F50674 Manual de usuario

Electrolux

Electrolux FAVORIT 35010 I Manual de usuario

Electrolux

Electrolux EUCAIWL Manual de usuario

Electrolux

Electrolux ESZ89300UW Manual de usuario

Electrolux

Electrolux U26220 Manual de usuario

Electrolux

Electrolux GA60PLVC Manual de usuario

Electrolux

Electrolux ESM48320UX Manual de usuario

Electrolux

Electrolux GA55SLV220 Manual de usuario

Electrolux

Electrolux FAVORIT 50872 Manual de usuario

Electrolux

Electrolux ESL8530RO Manual de usuario

Electrolux

Electrolux ESL 7220RO Manual de usuario

Electrolux

Electrolux 727042 Manual de usuario

Electrolux

Electrolux EI24ID35Q Manual de usuario

Electrolux

Electrolux EX601SC Manual de usuario

Electrolux

Electrolux ESI 6230 Manual de operación

Electrolux

Electrolux EDW7505HPS - Semi-Integrated Dishwasher With 5 Wash... Manual de usuario

Electrolux

Electrolux GA55SLV Manual de usuario

Electrolux

Electrolux ESF6720ROW Manual de usuario

Electrolux

Electrolux ESM48310SX Manual de usuario

Electrolux

Electrolux GA60KV Manual de usuario

Manuales populares de Lavavajillas de otras marcas

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
