1. INTRODUCTION

1.1 General

The new DUO50 DCI is a high efﬁciency inverter technology outddor unit,

since it’s a lego concept unit, it can be matched to several types of inverter indoors, such

as:

wall mounted, cassette , ﬂoor/ceiling units, with a capacity range of 2.5 – 3.5 Kw for each

single indoor unit.

1.2 Main Features

• DC Inverter

• R410A

• High COP (A class energy rating)

• Lego Concept

• Pre-Charged

• Dry contact inputs:

o STBY – when shorted, will force all indoors to STBY.

o Night – when shorted, will force outdoor fan to low speed (in cool mode only)

• Dry contact output – Alarm. Will be closed system is faulty.

• Base heater connection.

• Cooling operation at outdoor temperature down to -100C.

• Heating operation at outdoor temperature down to -150C.

• 10 LED’s, shows both indoor and outdoor diagnostics.

• Variable Speed DC Inverter outdoor fan.

• M2L diagnostics softwear cable Port ( for PC).

• Low noise level

1.3 Tubing Connections

Flare type interconnecting tubing to be produced on site.

For further details please refer to APPENDIX A on this manual, and to the relevant indoor

service Manual,

1.4 Inbox Documentation

Each indoor unit is supplied with its own installation and operation manuals.

CONTENT

1-2

INTRODUCTION

SM DUODCI 1-E.1 GB

1.5 Matching Table

1.5.1 R410A

OUTDOOR UNITS

INDOOR UNITS

MODEL REFRIGER. WNG25 WNG35 K25 K35 PXD25 PXD35 LS35

DUO50 DCI

R410A √√√

R410A √√√√

CONTENT

2-1

PRODUCT DATA SHEET

SM DUODCI 1-E.1 GB

2. PRODUCT DATA SHEET

2.1 Outdoor Unit DUO 50 DCI Speciﬁcations.

Model DUO-50 DCI R410A

Function Cooling Heating

Capacity(1) Kcal/hr 4300(1030~5570) 5330(820~6670)

Btu/hr 17050(4090~22100) 21140(3240~26430)

W 5000(1200~6480) 6200(950~7750)

Total Input(1) W 1470(420~2160) 1670(375~2050)

E.E.R (Cooling) / C.O.P (Heating)(1) W/W 3.4 3.71

Running Current A 6.7 7.7

Starting Current A 10.5

Inrush Current A 35

Power Supply V/Ph/Hz 230V/ 1PH / 50Hz

OUTDOOR UNIT

Refrigerant control Electronic expansion valve

Compressor type Scroll DC Inverter

Model Panasonic 5CS130XCC03

Starter type ---

Protection device Outdoor SW control

Heat exchanger Hydrophilic ﬂat ﬁn ,Grooved tube coil

Fan (drive) x No. Propeller x 1

Airﬂow m3/hr 2160

Motor output W 40

Defrost method Reverse cycle

Noise level Pressure(4)

dB(A) 52 53

Power 62 63

Dimensions W*D*H mm 795*290*610

Weight kg 43

Packing

dimensions W*D*H mm 945 * 395 * 655

Unit stacking units 3

TUBING

Refrigerant R410A

Charge(7.5m connection tube) kg 1500

Fresh Air NO

Tube size liquid mm 6.35

O.D. suction mm 9.53

Connection

method between

the indoor and

outdoor units

indoor & outdoor Flared

height difference

between indoor units Max.5m

height difference

between indoor &

outdoor

Max.10m

tubing length Standard 7.5m

Max.25m for one unit and 30m for total

additional charge No need

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-2

PRODUCT DATA SHEET

SM DUODCI 1-E.1 GB

2.2 Indoor Units Data

2.2.1 WNG 25 DCI Speciﬁcations

Model Indoor Unit / Type WNG 25 DCI / Wall Mounted

Installation Method FLARE

Fan Motor Output W 20

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Crossﬂow *1

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 530/570 430/460 330/350

Sound Power Level(3)

Cooling / Heating L - H dB (A) 39-50 / 39-51

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 26-38 / 26-39

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 810 285 202

Weight kg 11

Package Dimensions W/H/D mm 885 360 285

Stacking Height Units 7

Heating Elements kW N/A

Moisture Removal L/hr 1

2.2.2 WNG 35 DCI Speciﬁcations

Model Indoor Unit / Type WNG 35 DCI / Wall Mounted

Installation Method FLARE

Fan Motor Output W 20

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Crossﬂow *1

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 550/580 450/480 350/370

Sound Power Level(3)

Cooling / Heating L - H dB (A) 39-52 / 39-52

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 26-39 / 26-40

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 810 285 202

Weight kg 11

Package Dimensions W/H/D mm 885 360 285

Stacking Height Units 7

Heating Elements kW N/A

Moisture Removal L/hr 1.5

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-3

PRODUCT DATA SHEET

SM DUODCI 1-E.1 GB

2.2.3 K 25 DCI Speciﬁcations

Model Indoor Unit / Type K 25 DCI / Cassette

Installation Method FLARE

Fan Motor Output W 36

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Centifugal *1

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 530/600 500/530 435/450

Sound Power Level(3)

Cooling / Heating L - H dB (A) 42-48 / 42-47

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 32-38 / 32-37

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 571 287 571

Weight kg 22.7

Package Dimensions W/H/D mm 685 415 685

Stacking Height Units 5

Heating Elements kW N/A

Moisture Removal L/hr 1

2.2.4 K 35 DCI Speciﬁcations

Model Indoor Unit / Type K 35 DCI / Cassette

Installation Method FLARE

Fan Motor Output W 36

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Centifugal *1

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 580/620 510/560 435/450

Sound Power Level(3)

Cooling / Heating L - H dB (A) 42-49 / 42-48

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 32-38 / 32-38

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 571 287 571

Weight kg 24.4

Package Dimensions W/H/D mm 685 415 685

Stacking Height Units 5

Heating Elements kW N/A

Moisture Removal L/hr 1.5

NOTE:

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-4

PRODUCT DATA SHEET

SM DUODCI 1-E.1 GB

2.2.5 PXD 25 DCI Speciﬁcations

Model Indoor Unit / Type PXD 25 DCI / Cassette

Installation Method FLARE

Fan Motor Output W 36

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Centifugal *2

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 400 350 300

Sound Power Level(3)

Cooling / Heating L - H dB (A) 47-50

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 35-39

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 820 630 190

Weight kg 21

Package Dimensions W/H/D mm 890 710 280

Stacking Height Units 7

Heating Elements kW N/A

Moisture Removal L/hr 1

2.2.6 PXD 35 DCI Speciﬁcations

Model Indoor Unit / Type PXD 35 DCI / Cassette

Installation Method FLARE

Fan Motor Output W 36

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Centifugal *2

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 450 400 300

Sound Power Level(3)

Cooling / Heating L - H dB (A) 51-56

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 45-38

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 820 630 190

Weight kg 22

Package Dimensions W/H/D mm 890 710 280

Stacking Height Units 7

Heating Elements kW N/A

Moisture Removal L/hr 1.9

NOTE:

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

2-5

PRODUCT DATA SHEET

SM DUODCI 1-E.1 GB

2.2.7 LS 35 DCI Speciﬁcations

Model Indoor Unit / Type LS 35 DCI / Cassette

Installation Method FLARE

Fan Motor Output W 36

Power Supply V/Ph/Hz 220-240 / 1/ 50

INDOOR

Fan Type & Quantity Centifugal *2

Airﬂow(2)

Cooling / Heating H/M/L m3/hr 830 700 530

Sound Power Level(3)

Cooling / Heating L - H dB (A) 52-59

Sound Pressure Level (4)

Cooling / Heating L - H dB (A) 35-42

Condensate Drain Tube I.D. mm 16

Dimensions W/H/D mm 860 245 680

Weight kg 30.0

Package Dimensions W/H/D mm 1055 305 728

Stacking Height Units 6

Heating Elements kW N/A

Moisture Removal L/hr 1.3

NOTE:

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

CONTENT

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Electra

Electra

Electra Alpha 7 Manual de usuario

Electra

Electra IOD 7 Manual de usuario

Electra

Electra DELTA 25 Manual de usuario

Electra

Electra LEX 25 DCI Manual de usuario

Electra

Electra KN-27SH Manual de reparación

Electra

Electra DCI Light Commercial Series Manual de usuario

Electra

Electra PXD 9 RC Manual de usuario

Electra

Electra Alpha 7 Manual de usuario

Electra

Electra Delta 17 DF Manual de usuario

Electra

Electra DUO 9+9 ST Manual de usuario

Electra

Electra PXD912 Manual de usuario

Electra

Electra JKD DCI Series Manual de usuario

Electra

Electra LS DCI Series Manual de usuario

Electra

Electra WF 230 Manual

Electra

Electra TRIO 72 DCI Manual de usuario

Electra

Electra ELSI-JKD009-N11 Manual de usuario

Electra

Electra WNG 7 Manual de usuario

Electra

Electra LEX 7 Manual de usuario

Electra

Electra ELSI-JKD009-N11 Manual de usuario

Electra

Electra DELTA 22 Manual de usuario

Electra

Electra WNG 50 DCI Manual de usuario

Electra

Electra WNG 9 DCI INV Manual de usuario

Electra

Electra CN 25 DCI Manual de usuario

Electra

Electra ELSI-JYD009-H11 Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
