Note:
Firmware for your subwoofer can be downloaded from
www.elac.com under the troubleshooting and firmware
section.
USB drive must be compatible with USB 2.0 with a 512
byte hardware sector size.
1. Unzip the downloaded firmware file and place the “FIRMWARE_UPDATE_FILE.BL2” file in
the root directory of a FAT32 formatted USB flash drive. exFAT, NTFS and other file sys-
tems are not compatible.
2. Power o the subwoofer, wait 5 seconds and plug the USB flash drive into the USB port
on the rear of the subwoofer.
3. Power on the Subwoofer. The firmware update will automatically begin.
4. The firmware update will be complete when the LED on the rear of the subwoofer stops
flashing.
5. Power Cycle the subwoofer. The firmware update is now complete.
6. You can check the firmware version of the subwoofer in the Sub Control 3.0 app on the
about page.
R
1. Press and hold down RESET button for minimum of 10 seconds
2. LED starts to blink (flash). LED blinking parameters: LED is on for 100 ms (milliseconds) then LED is o
for 100 ms.
3. Release the RESET button before 15 seconds elapses in order to force the sub to perform Factory
Reset
4. If the RESET button is hold down for more than 15 seconds Factory Reset is cancelled.
Note:
RESET erases all data and restores subwoofer firm-
ware and parameters to the original factory settings.
Firmware upgrade may be necessary post RESET.
VOLUME
SERVICE
12V
TRIGGER
RIGHT
LFE
LEFT
LINE IN
ETHERNET
SPEAKER LEVEL
LEFT
Reference Subwoofer Series Model : RS700-SB
1938 N. Batavia St. Suite K
Orange, CA 92865
Fraunhoferstraße 16
24118 Kiel
Deutschland
www.elac.com
CONTAINS FCC ID: A8TBM70ABCDEFGH
CONTAINS IC ID: 12246A-BM70BLES1F2
CONTAINS FCC ID: NKR-SWA12
CANTAINS IC: 4441A-SWA12
CAN ICES-3(B)/NMB-3(B)
THIS DEVICES COMPLIES WITH PART 15 OF THE FCC RULES
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
1 THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE
2 THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATIONS
POWER
Desinged by Elac
Made in China
SERIAL NUMBER
T6.3A L 250V
100-120
220-240 VAC
50/60Hz 6.3A
WIRELESS
PAIR/RESET
VOLUME
SERVICE
12V
TRIGGER
RIGHT
LFE
LEFT
LINE IN
ETHERNET
SPEAKER LEVEL
INPUTS
LEFT
RIGHT
Reference Subwoofer Series Model : RS700-SB
1938 N. Batavia St. Suite K
Orange, CA 92865
Fraunhoferstraße 16
24118 Kiel
Deutschland
www.elac.com
CONTAINS FCC ID: A8TBM70ABCDEFGH
CONTAINS IC ID: 12246A-BM70BLES1F2
CONTAINS FCC ID: NKR-SWA12
CANTAINS IC: 4441A-SWA12
CAN ICES-3(B)/NMB-3(B)
THIS DEVICES COMPLIES WITH PART 15 OF THE FCC RULES
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
1 THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE
2 THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATIONS
POWER
Desinged by Elac
Made in China
SERIAL NUMBER
T6.3A L 250V
100-120
220-240 VAC
50/60Hz 6.3A
WIRELESS
PAIR/RESET
