Edision HDMI Modulator Xtend Manual de usuario
User’s Guide
HDMI Modulator to DVB-T/MPEG4 +HDMI LOOP & IR Control
2
CONTENTS
►INTRODUCTION .......................................... 3
►FEATURES ................................................... 4
►TECHNICAL SPECIFICATIONS................... 4
►RF SPECIFICATIONS .................................. 5
►
IR CONTROL SYSTEM EDI-RX SPECIFICATIONS
... 5
►CONNECTIΟΝ & OPERATION ................6 -7
►PACKAGE INCLUDES.................................. 8
►MAIN MENU ................................................. 9
►
CONFIGURATION EXTRACTION (CFG)
....... 10
►CONFIGURATION IMPORT (CFG) ............ 11
►FAST PRE-CONFIG FUNCTION /
50 ID’S SELECTABLE................................. 12
►TROUBLESHOOTING.........................13 - 14
►INSTALLATION EXAMPLE ........................ 15
The CE certificate of the product is available on our webpage, by visiting this link:
https://www.edision.gr/en/support
3
►INTRODUCTION
Digital FULL HIGH DEFINITION single channel modulator, with EMBEDDED IR REMOTE
CONTROL system over coaxial, plus HDMI LOOP for HDMI signal connection to a TV set. HDMI
signal input from any HDMI source (Terrestrial & Satellite TV receivers, Cameras, DVD’s, DVR’s,
etc) can be converted up to FULL HIGH DEFINITION 1080p, Digital Terrestrial DVB-T signal output,
in VHF/UHF band, plus the HDMI source can be also connected to a TV set, using the HDMI LOOP
OUT of the modulator. The embedded IR-over-Coax system IR EDI-Rx of the modulator, offers the
ability to control the connected HDMI source, from the TV point, through the existing coaxial cable
connection.
4
►TECHNICAL SPECIFICATIONS
Processor
Memory
HDMI Input/Output
USB Type
Power Consumption
Video Encoder
Aspect Ratio
Resolution
Audio encoder
200MHZ 32Bits RISC
DDRII 16bit 512Mbits (Embedded) & NOR Flash 32Mbit
HDMI v1.4a
USB 2.0 HOST, Fat32 support
10W max, 100-240V AC to DC adapter 5V 2A
MPEG1, MPEG2 MP@HL, MPEG4 SP@L3 to
ASP@L5, MPEG4 AVC [email protected], [email protected]
16:9 wide screen, 4:3 letter box, 4:3 pan scan
up to 1080p@30FPS
MPEGI L1/2, MPEGII LII, AAC LC, HE-AAC v1/v2 (2-CH)
►FEATURES
• INPUT signal: HD IN
• OUTPUT signal: Digital Terrestrial DVB-T MPEG4
• IR control over coaxial, through the embedded
EDI-Rx system.
• On board HDMI LOOP for source HDMI
signal connection to TV.
• On-board RF LOOP (IN)
• High Video Resolution up to 1080p
• Frequency Range VHF (CH. 5-12)
& UHF (CH. 21-69)
• MER more than 35dB
• Adjustable RF Output Level / Default 90dbμV
• Fast Pre-Cong Function / 50 ID’s Selectable
• Backup Cong File by USB
• Software Upgrade by USB
• Ports - Connections: HD IN, HD OUT, RF IN,
RF OUT, IR OUT, USB, DC 5V, GROUND
• 4-digit LED Display
• Front panel buttons: Button Lock, Menu/OK, Left /
Right menu selection, Up/Down menu selection.
• Low Power Consumption
5
►RF SPECIFICATIONS
Frequency Range
Impendance
RF IN
FEC
Guard Interval
Constellation
RF Output level
Bandwidth
FFT
Reed Solomon
Symbol Rate
MER
IR OUT
VHF (CH. 5-12) & UHF (CH. 21-69)
50Ω
RF signal mix through
1/2, 2/3, 3/4, 5/6, 7/8
1/4, 1/8, 1/16, 1/32
QPSK, 16QAM, 64QAM
~90dBuV Adjustable from 0 to -14dB 0 to +6d
7MHZ, 8MHZ
2K, 8K
202, 188, T=8
Up to 31.668 MBPS
>35dB at Maximum RF output level
Stereo Jack 3,5mm (Jack to IR EDI-Tx)
►IR CONTROL SYSTEM EDI-RX SPECIFICATIONS
Modulation Type
Frequency bandwidth
RF IN Input
RF OUT Output
IR Receiver OUT
DC OUT
IR Signal LED
ASK
VHF III (174-230 MHZ) & UHF (470-862 MHZ)
1x Female IEC-type
1x Male IEC-type
Stereo Jack 3,5mm (Jack to IR EDI-Rx)
5V/500mA (DC to USB cable)
IR status indication
6
►CONNECTIΟΝ & OPERATION
1. Connect an HDMI Cable from HDMI source device to the HDMI Modulator Xtend HD in
2. For viewing the content from the HDMI source connected to the HDMI Modulator Xtend to another HDMI
device (TV set), connect an HDMI cable from the HD OUT (6) of the HDMI Modulator Xtend, to the HDMI IN of
the TV
3. Connect an RF coaxial Cable from RF OUT to the RF Network or to an ANT IN of an MPEG4 TV.
4. As an option, the HDMI Modulator Xtend RF IN (1) can be used as a connection-mixing of the existing coaxial
network or as a connection-mixing of a network of modulators.
5. For controlling from a second TV point, connect the RF OUT(2) of the HDMI Modulator Xtend to the RF IN (A)
of the IR EDI-Rx and then from the RF OUT (D) of the EDI-Rx, to the ANT IN of the TV.
6. From the IR OUT(3) of the HDMI Modulator Xtend, connect the Jack to IR Tx cable and place it in front of the
HDMI source to be controlled via IR. Then connect the Jack to IR Rx (B) from the IR Control System EDI-Rx in
front of the second TV’s IR reception point, so as to control it via IR.
7. In case there are more than one HDMI Modulator Xtend in the same installation, please choose different ID for
each one modulator (from the 50 pre-installed into the device). For each additional IR control point, you need
one IR Control System EDI-Rx.
8. Connect the ground point (8) of the HDMI Modulator Xtend to a proper grounding point.
9. Connect the power supply DC5V from the PSU to the HDMI Modulator Xtend DC power input (7).
DC 5V/2A
RF IN
IR OUT
HD IN HD OUT
RF OUT
1 2 3 4 5 6 7 8
ΑB C D
Jack to IR Tx
cable
Jack to IR Rx
cable
7
10. Connect the power supply DC5V input of the IR Control System EDI-Rx (C) to a USB port of a TV/STB,
using the cable USB-to-DC.
11. Proceed to channel scan on your TV or STB.
8
►
PACKAGE INCLUDES
First TV equipment:
1. HDMI Modulator Xtend
2. Jack to IR Tx cable
3.
5V/2.0A EU/UK universal Power Supply Unit
Second TV equipment:
4. IR Control System EDI-Rx
5. Jack to IR Rx cable
6. USB to DC (5V) cable
General:
7. User Manual EN/DE/GR
ON/OFF
ON/OFF status of the HDMI Modulator
Xtend device
KEY LOCK
Press the key lock and when the green led lights up the keypad is locked. Press once again to
unlock
HD IN SIGNAL
Connect the HDMI cable to the HD IN and when the green light turns on, the signal is active
HD OUT SIGNAL
Connect the HDMI cable to the HD OUT and when the green light turns on, the signal is active
9
CH: Shows the current RF
channel output. Use the keys
Up & Down to select the desired
RF channel output.
ID: Shows the current ID. Use
the keys Up & Down to set the
desired ID.
RF: Shows the RF output level.
Use the keys Up & Down to
adjust to the desired RF level.
LCN: Shows the current LCN
type. Use the keys Up & Down
to set the desired LCN type.
FACT: Factory defaults. Press
key UP to restore factory
defaults.
CFG: Conguration extract.
Press key UP to extract the
current conguration to the USB
storage device.
SOFT: Shows the SW version.
Use the key UP to display the
current SW version.
►MAIN MENU
To enter the main menu options, press once the Menu/OK key and use the Left or Right
keys to navigate within the main menu.
To save the selected conguration press once the MENU/OK key and conrm
with YES or NO by pressing the LEFT and RIGHT keys and press MENU/OK
key once again. The conguration is being saved, please do not power off!
10
►CONFIGURATION EXTRACTION (CFG)
For an advanced conguration of the HDMI modulator Xtend, you must extract the conguration le
to a USB drive, modify it and import it again in the HDMI modulator Xtend. To extract the conguration
le named jedi_cong.txt*, you must connect a USB drive** to the USB slot, enter the Main Menu,
select CFG and press key UP to extract the le to the USB drive.
When the message SUCC appears, the process has been successfully
completed.
*IMPORTANT: Τhe conguration le jedi_cong.txt should not be renamed!
**IMPORTANT: Use only FAT32 partitions! In any other case, the message FAIL
will indicate that the process has not been completed.
Conguration le details (jedi_cong.txt)
<attribute>value<attribute> Description: Allowed values
<constellation>2<\constellation> Constellation: 0 QPSK, 1 16QAM, 2 64QAM
<channel>43<\channel> RF channel: 05 to 12 & 21 to 69
<bandwidth>8000<\bandwidth> Channel Bandwidth: 7000 or 8000 KHz
<FEC>2<\FEC> FEC: 0 , 1 , 2 , 3 , 4
<FFT>1<\FFT> FFT: 0 2Κ, 1 8Κ
<GI>0<\GI> Guard Interval: 0 , 1 , 2 , 3
<Name>TV-1<\Name> Channel Name: Max 12 characters
<RF_Level>0<\RF_Level> RF Level: 6,4,2,0,-2,-4,-6,-8,-10,-12,-14
<LCN_Type>1<\LCN_Type> LCN Type: 0 ITC, 1 Italy
