Wireless Adaptor Application Guide

Before Star up

Before applying Edimax Access Point as your Wireless

Adaptor for wired devices, please check the following items:

1. You need to have a wireless router connected

2. You need to have a PC (or notebook) for setting

3. You need a RJ-45 cable to connect the Access Point with your wired

device.

4. Make sure that the IP address for the connected router is 192.168.2.1.

(Edimax Router use 192.168.2.1 as default settings)

5. Change the Router’s SSID. (We changed the Router’s SSID to

“Edimax1” for the application guide)

Step by Step settings

Step 1:

Connect your PC (notebook) with Edimax Access Points by using a

RJ-45 cable. (Use 192.168.2.1 as default IP address)

Step by Step settings

Step 2: Connected to Edimax Access Points and select System Utility

Step by Step settings

Step 3:

Change the IP

address to

192.168.2.2

Step by Step settings

Step 4:

1. Select Basic Setting

2. Select “Station Infrastructures”

3. Select Site

Survey

Step by Step settings

Step 5 (Part 1 of 2):

Select the router which connects to the internet

Step by Step settings

Check if the selected router is

correct then click “Apply”

Step 5 (Part 2 of 2):

Step by Step settings

Step 6: Connect the Access Point with the device as following

diagram

1. Edimax 802.11n Access Point could be your best choice to extend

the signal coverage and quality for your XBOX360 or PS3 gaming

consoles. Let you enjoy the online gaming without suffering bad

wireless signals.

2. Edimax 802.11n Access Point could let your wired devices such as

Media adaptors or NAS become wireless device.

3. No program installation needed. No long distance cable wiring

required. It is easy and it is reliable.

Benefits
