EDIFIER X200 Manual de usuario

X200

Made in China

Edifier Enterprises Canada Inc.

User's Manual

Multimedia Speaker

Overview

1

Welcome !

Very thanks for choosing Edifier multimedia speaker,it can

provide good sound for multimedia computer and home theater.

Before operating the system, please read this manual thoroughly

and retain it for future reference.

1 Sub Woofer 2 Volume Control

3 Bass Adjusting Switch

5Speaker Out 6 Satellite Speakers

7 Power Switch 8 User's Manual

9

4 Line In Port

Audio connecting cord

Overview

Operating

2

Operating

1

2

3 Playing the audio device

CONNECTING

Connect the satellite speakers to the output RCA on the

back panel of the Sub-woofer. Please note to match the color,

red to red and white to white.

Connect the subwoofer to theAudio device.

Using Audio connecting cord , connect the Line-input port

of the subwoofer to Line-out of the Audio Device (Such as the

computer, Discman, etc).

Plug the AC power plug into the wall outlet and turn on the

power switch, Now your speaker system is ready for Use.

Adjusting the volume control and Bass adjusting switch, then

you can enjoy the music.

Total Power Output : RMS 4W x 2 + 10W(THD=10%)

Input Impedance: 10K Ohm

Input Sensitive: 520 mV

Bass Unit: 5" Aluminum coil, 4 Ohm

Tweeter Unit: " Paper coil, 4 Ohm

Dimension(Subwoofer): 200(W) x 192(H) x 220(D)mm

Dimension(Satellite): 88(W) x 142(H) x 100(D)mm

Gross Weight: About 3.7 Kg

2 3/4

SPECIFICATIONS

Notice

Edifier assumes noresponsibility for anyerrors that mayappear

in this manual.Information contained hereinis subject tochange

without notice.

Notice

Edifier and Edifier logo are owned by Edifier Enterprises Canada Inc.

and may be registered. And other brand names and trademarks are

the property of their owners.

WARNING

Toreduce the risk of electric shock ,Do not expose this apparatus

to rain or moisture.

Copyright 2005

All Rights Reserved.

Manual Edition 1.2,Jun. 2005

Printed in CHINA
