EDIFIER MP300 Manual de usuario

Manuel de L'utilisateur

User's Manual

1 English

English

WARNING

Humidity ---- Do not use the speakers near water, and do not immerse them in any liquid or

pour any liquid on them.

Polarized Plug ---- Do not defeat the safety purpose of the polarized plug. A polarized plug

has two blades with one wider than the other. The wider blade is provided for your safety. If

the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet. Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the appliance.

Heat---- Place the speakers away from all heat sources, such as heat registers, stoves, and

direct sunlight.

Ventilation ---- Do not block the openings in the speaker cabinets, and never push objects

into speaker vents or slots because of fire or electric shock hazards, and provide sufficient

space around the speakers for proper ventilation.

Location ---- Place the speakers in a stable location so that it will not fall causing damage

to the speakers or bodily harm.

Cleaning --- Unplug the speakers from the computer and from the electrical outlet before

cleaning them with a damp cloth.

Non-Use Period ---- The Power cord of the appliance should be unplugged from the outlet

when left unused for a long period of time.

Lightning Storm ---- For added protection during lightning storms, unplug the speakers from

the electrical outlet and turn off the computer.

Servicing ---- Servicing is required when the appliance has been damaged in any way, such

as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen

into the appliance, the appliance has been exposed to rain or moisture, and does not

operate normally, or has been dropped. Refer all servicing to qualified service personnel only.

LED Indicator

Subwoofer Subwoofer Port

AC Power Pack

(The actual products may differ

with the figure in appearance)

Right Satellite Speaker

DC Jack Line-In Socket

Speaker Out

Subwoofer Stand

Volume -

Button

Left Satellite Speaker

ILLUSTRATIONS:

LINE INSPEAKERDC 12V

English

INTRODUCTION OF BACK PANEL

LINE INSPEAKER

6English

PLAYING THE AUDIO DEVICE

Please refer to

illustration below:

NOTE: A slight tap on the Volume UP (+) or DOWN (-) will launch the system. And to

set it into Standby Mode, please press down the Volume UP (+) and DOWN (-) buttons

together, and hold down either of them will wake up the system again. When system is

activated, please refer to the following part:

Please adjust the volume by pressing UP (+) or DOWN (-) button on the left control

satellite to a comfortable level for listening. Please note that when the system is in

standby mode, the LED Indicator on the subwoofer will flicker with a pulsing effect.

Right Satellite Speaker

Volume -

Button

7English

TROUBLE SHOOTING GUIDE

No Sound from Any Speakers?

Is there Power to your System?

Ensure that your subwoofer is plugged securely into a working AC wall outlet and that the blue power

indicator LED is ON.

Are your Volume Controls adjusted correctly?

Ensure your computer's internal volume settings are set to mid-level, and the Volume of the Controller

Satellite (Left) is adjusted correctly.

Is the Mute on your System set to Auto-Protect Mute or to ON?

Mute on is ON when both the + and - Volume buttons are depressed, and OFF when they are both

depressed again. Please check the blue status LED on the subwoofer. A non-pulsing effect indicates

the Mute is in Off mode.

Are your Cables properly connected?

Check all the connections are secure.

Are you receiving an Audio Signal?

Please try connecting your speakers to an alternate audio source, such as another portable CD player

or Discman to determine that your speakers are working.

Sound from only part of your system?

Please ensure the "S" plug connecting the satellites, is firmly inserted into the socket assembly on the

subwoofer mounting base. Try substituting the audio connection to another source, e.g. a Discman,

portable radio etc. If the system now works, the original source is at fault.

When playing CD from computer, only one Speaker has sound

Mostly this phenomenon tends to occur with a new computer - only one satellite works when playing an

audio CD, but all work correctly when running a WAV file or playing a Game. The reason for this is the

CD-ROM is not matched with the Soundcard, or one signal channel maybe shorted to a ground wire.

Also please refer to the CD-ROM user manual to adjust the jumpers.

8English

TROUBLE SHOOTING GUIDE

Speakers exhibit excessive noise

Edifier speakers are of a very low noise circuit design. Some source equipment may have a poor signal

to noise ratio. Therefore, please unplug the input audio cable, and check if the noise is from the CD/DVD

player or the Computer Soundcard etc.

Magnetically Shielded Speakers

Edifier system subwoofers and satellite speakers are all of a magnetically shielded design. You can

place the speakers near a TV or monitor. However, it is wise to allow a 0.2-1 m distance between the

speakers and monitor to avoid possible magnetic field interference.

Listening Tips:

All high quality speaker systems benefit from a running-in period on normal music sources.

Sit in a comfortable position at the computer desktop. Take time to test the listening

environment by using music CDs with wide frequency content and spacious left-to-right

imaging. The loudspeaker driver used in the subwoofer will change its characteristics

subtly over the first two weeks of use as the suspension of the cone will loosen up slightly,

producing a trace more warmth to the overall sound texture.

Adjust the speaker placement for the most realistic imaging and tonal balance by

listening to several different musical selections and game or computer sound effects.

For optimum acoustic performance, we recommend that you place your satellite

speakers at least 6-8" from rear walls to reduce unwanted reflections that can muddy

your sound. Bass frequencies may be enhanced or exaggerated by placing your

subwoofer close to a wall or corner. Please feel free to experiment with the system's

location to obtain the most pleasing effects.

Edifier couples incredible technology with an amplified subwoofer to generate smooth

deep bass, crystal clear highs, and enough power to ensure that your personal listening

experience allows you to hear what you have been missing!

TO OPTIMIZE THE SOUND QUALITY FROM YOUR SYSTEM:
