EDIFIER TWS200 Plus Manual de usuario
True Wireless Stereo Earbuds
TWS200 Plus
www.edifier.com
EN · Product description and accessories
Charging cable Storage bag
Pairing button
Note: Images are for illustrative purposes only and may differ from the
actual product.
Charging case
● Charge the earbuds
Warning: The rechargeable batteries that provide power for this product must be
disposed properly for recycling. Do not dispose of batteries in fire to prevent an explosion.
■ User guide
•You may hear a warning tone when at low
battery level, please place the earbuds in
the case for charging.
● Charge the charging case
Input: 5V 35mA(earbuds)
5V 1A(charging case)
•
If power indicator flashes six times rapidly
when the case is opened, it indicates the
case has a low battery capacity, please
charge it in time.
•
Power indicator steady lit = charging
Power indicator off = fully charged
● Battery level indicator on the
charging case
•
When the charging case is opened/closed,
the power indicator will show the case’s
battery level;
if flashes three times slowly: full battery level;
if flashes twice slowly: medium battery level;
if flashes once slowly: low battery level;
if flashes six times rapidly: battery level is less
than 10%
•Power indicator (next to the charging port)
R
L
● Pairing
● Power on when the
case is opened.
● Power o when the
case is closed.
White light is lit for 1 second
•
Bluetooth pairing: red and
white lights flash rapidly
•
Place the earbuds in the case, and
double click the pairing button to
enter Bluetooth pairing.
● Functional operation
Search for and connect to "EDIFIER TWS200 Plus", after pairing is successful, the
white light of the charging case will flash twice per 5 seconds.
•
TWS pairing: white light flashes
rapidly
When successful, white light is
lit for 1 second and then the red
and whilte lights flash rapidly.
•
When not connected with any Bluetooth
device, place the earbuds in the case, and
press and hold the pairing button for
around 10 seconds and release until the
white light flashes rapidly, so as to enter
TWS pairing mode and clear pairing records.
Pause/play:
double click the left or right
earbud
Previous track:
triple click the left earbud
Next track:
triple click the right earbud
Accept/end a call:
double click the left or right
earbud
EDIFIER TWS200 Plus
Note: Images are for illustrative purposes only and may differ from the actual product.
Whenchargingthe charging case, the indicator is o.
•
Please ensure the charging case is correctly connected with power source.
No sound
•
Check if the earbuds are operating.
•
Check if the earbuds volume are at an appropriate level.
•
Check if the earbuds are correctly connected with mobile phone.
•
Check if the earbuds are operating within a normal working range.
The call quality of the earbuds are not good.
•
Check if mobile phone is in an area with strong signal.
•
Please ensure the earbuds are within effective distance (10m) and no
obstacle between the earbuds and mobile phone.
When playing music, cannot control pause/play/previous track/next
track via the earbuds.
•
Please ensure the paired device support
AVRCP (Audio Video Remote
Control Profile) profile.
■ FAQs
•Do not use a fast charger to charge the product to avoid affecting service
live of the battery.
•If not used for long periods of time, please charge the product with
lithium battery every three months.
•Keep the product away from humid places to avoid affecting internal
circuit. Do not use the product during intense exercise or with much
sweat to prevent sweat from dropping into the product to make
damage.
•Do not put the product in places exposed to sun or with high
temperature. High temperature will shorten service life of electronic
components, damage battery and make plastic components deformed.
•Do not put the product in cold places to avoid damaging internal
circuit board.
•Do not dismantle the product. Non-professional personnel may
damage the product.
•Do not drop, strongly vibrate, strike the product with hard object to
avoid damaging internal circuit.
•Do not use drastic chemicals or cleaner to clean the product.
•Do not use sharp objects to scratch product surface to avoid
damaging shell and affecting facade.
■ Maintenance
Model: EDF200018
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
2020 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade,
information contained herein may be subject to change from time
to time without prior notice.
Products of EDIFIER will be customized for different applications.
Pictures and illustrations shown on this manual may be slightly
different from actual product. If any difference is found, the actual
product prevails.
FR · Description du produit et accessoires
Câble de charge Étui de rangement
Étui-chargeur
Bouton de couplage
Remarque: Les images utilisées servent de référence uniquement, et peuvent
ne pas correspondre au produit.
● Charger les écouteurs
Avertissement: La batterie rechargeable qui alimente ce produit doit être éliminée
de façon appropriée pour le recyclage. Ne pas jeter une batterie au feu sous risque
d'explosion.
■ Instructions d’utilisation
•Lorsque vous entendez une notification
sonore de niveau faible de la batterie, placez
les écouteurs dans le boîtier pour les charger.
● Charger le boîtier de charge
Entrée: 5V 35mA(écouteur)
5V 1A(étui-chargeur)
•
Si le voyant rouge clignote six fois rapidement
lorsque vous ouvrez l’étui-chargeur, cela indique
que le niveau de la batterie de l’étui-chargeur
est faible. Chargez-le dès que possible.
•
Voyant d'alimentation allumé en continu =
en charge
Voyant d'alimentation éteint = complètement
chargé
● Achage du niveau de batterie
du boîtier de charge
•
Le voyant indicateur d’alimentation indique
le niveau de charge lorsque l’étui-chargeur
est ouvert ou fermé;
trois clignotements lents: batterie pleinement
chargée;
deux clignotements lents: niveau de charge
moyen de la batterie;
un clignotement lent: niveau de charge
faible de la batterie;
S’il clignote six fois rapidement: le niveau de
batterie est inférieur à 10%
•
Voyant d'alimentation (à côté du port de charge)
R
L
