ECK24 Kegerator Installation Guide
1. Faucet Handle
2. Faucet
3. Beer Tower
4. Guard Rail
5. Drip Tray
6. Cylinder Strap
7. Metal Keg Floor Support
8. Casters (x4)
9. Bottle Reservoir and Tube
10. Beer Line
11. Thermostat Control
12. Internal Fan Pipe
13. Tower Gasket
14. Tower Bolts (4)
15. Rail Screws (4)
Tools Needed:
- Wrench
- Flat Head Screwdriver
- Phillips Head Screwdriver
13
14
12
15
1
2
3
4
5
6
7
8
9
11
10
For additional information
visit edgestar.com
Warning:
CO2can be dangerous! CO2cylinders contain high-pressured gas, which can be hazardous if handled improperly. Please handle with care.
12
34
5
Mount the tower gasket
(#13) by lining it up with
the preexisting holes at
the top of the unit.
Install the tower (#3) by
first unraveling the beer
line (#10) from the
bottom of the tower.
Feed the beer line
through the top opening
that was under the
cabinet plug.
Install Tower Secure Tower
Install Handle & Faucet Install Railing
Once the beer line (#10)
is fed into the unit line up
the holes at the bottom of
the tower, install the four
bolts (#14) and secure
with the flat washer and
nut from the inside.
Line up the guard rail (#4)
with the existing holes at the
top of the unit. Use the rail
screws (#15) to mount the
guard rail to the top of the
unit.
Secure CO2Tank
Place the CO2cylinder on
the inside ledge and secure
with the cylinder strap
(#6).
Screw the faucet handle (#1) to
the beer faucet (#2). Line up the
beer faucet to the tower shank
at the front of the tower (#3)
and tighten the collar by hand.
6Power on unit
Adjust the temperature by
turning the thermostat
knob (1 is the warmest to
7 is the coldest setting).
Note: To help keep the
temperature uniform
throughout the unit, the
circulation fan will
continually run even if you
turn the thermostat to off.
You can only shut off the
circulation fan by unplug-
ging the unit.
Warning:
This guide is provided for informational purposes only. It is provided as a supplement to the owner’s manual.
Please refer to the owner’s manual for a full discourse on installation, usage and maintenance. If you have any questions about the installation of
this appliance, feel free to contact EdgeStar service at 866.319.5473 or consult a qualified installer. Neither the manufacturer nor its distributors
shall be liable for any incidental, consequential, indirect, special, or punitive damages of any nature, including without limitation, lost revenues or
profits, or any other damage whether based in contract, tort, or otherwise.
CO2cylinder comes empty due to HAZMAT restrictions. It will need to be filled locally at any air/gas
supplier prior to use.
Removing the Unit from the Pallet
Cleaning the Unit
1 2
3 4
1. Carefully remove the straps and packaging from the unit
2. Locate the metal L-brackets on the base of the pallet.
3. Unscrew the metal L-brackets by using a screw driver.
4. Remove L-brackets from pallet. With two people, carefully lift the unit off the pallet.
*Note: We recommend keeping the packaging until you have inspected the product for damage and tested the unit to
work properly.
Monthly maintenance is required to be covered under the manufacturers warranty. To maintain your refrigerator,
unplug the unit and use a vacuum attachment to clean out the side and back vent grills. This will keep your refrigera-
tor running efficiently and prolong the life of your compressor.
