EdgeStar EAC420 Manual de usuario

THANK YOU!

Congratulations on your purchase of this versatile EdgeStar

product that combines an evaporative air cooler and a

humidifier. To get the best cooling effect from your product

please read these instructions carefully.

For the best cooling performance from your unit, first fill it with

water. If ice is available, this will increase its cooling power.

Position the unit in a place such that air will be able to “flow

through” the area. The greatest cooling effect will be felt if the

unit is operated in a partly opened doorway or window with

the cooled air directed into the room. If the unit cannot be

positioned in an area that will allow the air to “flow through,” it

will still cool, but the effect will be lessened.

NOTE AND CAUTIONARY INFORMATION:

This appliance is intended for use in a home or small office

environment. Any other use (e.g., outdoors) is not

recommended by the manufacturer and may cause fire,

electrical shocks or other injury to person or property.

When using electrical appliances, basic safety precautions

should always be followed:

1. Extreme care should be taken when any product is used

by or near children and the elderly, and whenever the

product is left operating and unattended.

2. Before operating the product remove the unit from its

packaging and check to ensure it is in good condition.

3. DO NOT let children play with the packaging, especially

plastic bags.

4. DO NOT operate any product with a damaged power cord

or plug.

5. DO NOT attempt to repair or adjust any electrical or

mechanical functions on this unit as this may void the

warranty.

6. Check the household voltage to ensure it matches the

appliance’s rate specification.

7. DO NOT cover the air inlet or outlet.

8. Always unplug the product before refilling the water tank.

9. Always unplug the product when not in use. To disconnect

from the power supply, grip the plug and pull it from the

power socket. Never pull by the plug out by the cord.

10.This product is not intended for use in wet or damp

locations. Never locate the product where it may fall into a

bathtub or other water container. DO NOT use in

bathrooms or outdoors. When not in use always store in a

dry area.

11.DO NOT run the power cord under carpeting or cover with

rugs or runners. Keep the cord away from areas where it

may be tripped over.

12.Avoid the use of an extension cord.

13.DO NOT insert or allow objects to enter any ventilation or

exhaust opening as this may damage the product and

could cause an electrical shock or fire.

14.DO NOT use the product in areas near gasoline, paint, or

other inflammable goods or objects.

15.If the supply cord is damaged it must be replaced by the

manufacturer or an authorized service center.

16.Unplug or disconnect the appliance from the power before

servicing and cleaning.

MAINTENANCE

• Before you clean the appliance, switch it off, remove the

plug from the power socket and wait until the product has

cooled down.

• Use a damp cloth to clean the product housing.

• Do not use water, detergents, abrasive cleaning liquids or

chemical agents (e.g., Alcohol, Gasoline etc…) to clean the

appliance.

• Store the unit in its original packaging in a dry, dust free

area during the off season.

TIMER OPERATION

• The TIMER can be used to switch the product off after a

selected number of hours.

• Turn the unit on.

• Select the desired operating mode, speed, etc.

• Press the TIMER button once and the product will switch

off after 1 hour. Press the button again for 2 hours, again for

3 hours etc. The maximum timer setting is 8 hours. The LED

display will show the number of hours the timer is currently set

for.

• To cancel the Timer setting press the TIMER button again

until all the timer indicators are dark.

REMOTE OPERATION

 POWER: This button

turns the unit ON or OFF.

 MODE: This button turns

the COOL MODE on or

off.

 SPEED: This button

toggles through the fan

speeds

 TIMER: This button

controls the TIMER

 SWING: This button

adjusts the louver swing.

a) To replace the batteries, remove the cover of the battery

compartment. Install two AAA 1.5V Batteries, and then

replace the cover.

b) The effective operating range of the remote control is

about 13 feet in front of the unit and about 10 feet on the

side.

c) Take out the batteries if the remote will not be used for a

long period.

d) Replace the batteries as soon as the remote control does

not work normally.

e) Do not allow children to use the remote as a toy.

SPECIFICATIONS

Model No. EAC420

Voltage 120V

Frequency 60Hz

Wattage 250W

Net Weight 23 pounds

PARTS DESCRIPTION

1 Top cover 9 Air vent

2 Handle 10 Front cover

3 Horizontal louvers 11 Water level

4 Left side 12 Remote control

5 Front cover ornament 13 Remote control holder

6 Power cord hole 14 Right side

7 Caster wheels 15 Water inlet panel

8 Top cover lid 16 Drain

CONTROL PANEL

OPERATING INSTRUCTIONS

• Choose a suitable location for your unit; as noted in the

first section, the unit will produce greater cooling when

located in an area in which air can “flow through.”

• This unit can be operated by the controls on the control

panel or with the remote control

COOLING OPERATION

• Remove the plug from the electrical socket.

• Open the top cover lid or water inlet panel and pour clean

water into tank. The water inlet panel will allow you to pour

more water in, faster. Additionally, some ice cubes will

increase the cooling performance. Then connect to the

power supply.

• Press the POWER button to turn the unit on. The fan will

start at MEDIUM speed, and after few seconds it will

switch to LOW speed.

• Press the SPEED button to increase or decrease the

speed.

• Press the MODE button to select the COOL MODE, as

indicated by the LED. The full effect of this mode will

begin to be felt after about 3 minutes.

• Once all the water in the tank has been used turn the

product OFF, unplug it from the electrical socket, and refill

the tank.

• To turn the product OFF press the POWER button again.

If you do not intend to use the product again for some time

empty the water tank.

• To empty the water tank, turn the unit off using the

POWER button. Unplug the unit from the power outlet.

Remove the drain cap from the drain and allow the water

to drain out.

HUMIDIFICATION CONTROL

• Open the top cover lid

• Turn the dial counter-clockwise for maximum

humidification.

• Turn the dial clockwise for minimum humidification.

LOUVER CONTROL

• Press the SWING button to start the vertical louvers

automatically moving from side to side. To stop the louvers

press the SWING button again.

• You can change the air direction up or down by manually

adjusting the horizontal louvers.
