Edelbrock 5711 Manual de usuario

Brochure #63-5711

Rev. 8/07 - DA/mc

Page 1 of 2

Catalog #5711

Edelbrock Cat-back Exhaust System

Catalog #5711

for 2007-2008 1500 Standard, Extended, & Crew Cab with

Short Bed (New Body Style)

Pick-Up, 4.8L & 5.3L V8, 2 & 4 W/D

INSTALLATION INSTRUCTIONS

Please study these instructions carefully before installing your new Cat-back Exhaust System. If you have any questions,

contact our Technical Hotline at: 1-800-416-8628 , 7am - 5pm, Monday-Friday, Pacific Standard Time or e-mail us at

[email protected].

Suggested Tools for Installation:

❑3/8" ratchet set with SAE and metric sockets ❑9/16” & 15mm wrench

❑Jackstands and jack ❑Liquid penetrant and rubber lubricant

DISASSEMBLY

1. Raise vehicle and support with proper jackstands for

the weight, leaving the suspension hanging.

2. Use caution around hot exhaust systems to avoid

burns.

3. Use penetrating oil on all nuts and bolts.

Note: Some GM Trucks have a brace bar attached to

the left and right side frame rails. Remove bolt and

swing bar out of the way during installation.

4. Remove the bolts and clamps from the system and

lubricate the rubber hangers.

5. Use a pry bar to pull the rubber isolators off of the

pipe hangers.

6. Remove the old system. In some cases, you will find

it easier to cut the overaxle pipe to remove it.

ASSEMBLY

1. Bolt I-Pipe to factory outlet flange (behind catalytic

converters). Install hanger clamp assembly #23-

4099 onto I-pipe and engage hanger bar into OE

isolator and snug the clamp. Note: Do not tighten

flange bolts at this time, (snug only).

2. Slip the muffler onto the intermediate pipe with a

3" band clamp on the front. Note: Inlet end of

muffler is marked. Snug the clamp so you can adjust

the system later.

3. Install a 3” band clamp onto the outlet of the muffler.

Slip the overaxle pipe into outlet of muffler.

4. Install hanger clamp assembly #23-4100 behind

band clamp and engage into OE isolator. Install

hanger clamp assembly #23-4042 onto outlet end of

overaxle pipe and engage into OE isolator. Snug

clamps for adjustments later.

5. Slip tailpipe onto overaxle pipe, and install 3” band

clamp.

6. Working from the front of the system, align and

tighten each pipe from the cat-back.

7. Check for clearance to body, frame, suspension and

driveline as you tighten the system from front to rear.

8. Re-attach the brace bar to frame rail (if equipped).

9. Check for leaks and correct, if any are found.

WARNING!!!

Exhaust gas contains carbon monoxide, a deadly invisible gas. Correct any leaks before driving!

IMPORTANT NOTE:

Proper installation is the responsibility of the installer. Improper installation will void warranty and may

result in poor performance and engine or vehicle damage.

Brochure #63-5711

Rev. 8/07 - DA/mc

Page 2 of 2

Catalog #5711

KIT CONTENTS

WARNING: Support your vehicle with proper

jackstands or ramps rated for the total vehicle weight.

Place stands so that the rear axle is allowed to hang

free for easy system removal.

WARNING: These cat-back systems are engineered

to fit stock catalytic converters or equivalent

replacements. If you original system has been

modified, Edelbrock will not warranty fit or

performance.

Intermediate Pipe

Assembly

Muffler

Tailpipe

Assembly

Edelbrock Corporation, 2700 California St., Torrance, CA 90503

Tech Line: (800) 416-8628

E-Mail: [email protected]

Hanger Clamps

Overaxle Pipe

Qty. Part # Description

❑125-3282 I-Pipe Extended & Crew Cab

❑125-3295 I-Pipe Standard Cab

❑125-3166 Overaxle Pipe

❑125-3157 Tail Pipe

❑1 25-55725 Muffler

Qty. Part # Description

❑2 46-6613 3” Band Clamps

❑1 23-4099 Hanger / Clamp Assembly

❑1 23-4042 Hanger / Clamp Assembly

❑1 23-4100 Hanger / Clamp Assembly
