Installation Manual
Compact Removable Drive Subsystem
DataCOT
Things You Should Know
Items Required: Phillips Screwdriver, Serial ATA or SAS cable, Hard
Drive.
PREVENT DAMAGE TO YOUR COMPUTER AND DATA LOSS BY
GROUNDING YOURSELF PRIOR TO HANDLING ANY ELECTRICAL
COMPONENT. EDBENTOR ASSUMES NO LIABILITY FOR STATIC
DISCHARGE DAMAGE.
!
CAUTION
If necessary, please refer to your computer’s user manual and hard drive
manual for additional support.
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
Thank you for choosing Edbentor!
You have purchased one of the most advanced and reliable removable
storage systems on the market today.
Be sure to retain this manual as a convenient source of information.
1
The Receiver and Carrier Installations are now complete. Proceed
to Operation for immediate use of DataCOT™ unit.
Receiver Installation
Select applicable 5.25” drive bay in which to install DataCOT™
receiver assembly. Remove ller plate if present.
Slide receiver frame into the drive bay of the PC case. Secure the
receiver to the PC case using the screws provided.
Refer to the “WIRING DIAGRAM SHEET” for proper data and power
connection.
1.
2.
3.
Hard Drive Installation for Carrier
Remove the DataCOT™ carrier cover. The cover will snap off from
the rear of the carrier.
Mount the hard drive by connecting the male connector of hard drive
to the female connector of the carrier.
Secure the hard drive in place by using the screws provided.
Replace cover on the carrier. The cover will snap into place by
applying pressure to the rear of the cover. If desired, secure cover
using the screws provided for added security.
1.
2.
3.
4.
2
Operation of DataCOT™ Unit
Insert carrier by sliding into receiver. Rails inside receiver will ensure
proper alignment. The carrier guide pins will snap into receptacles in
receiver for secure connection.
The DataCOT™ unit features an electronic key lock that directly powers
the unit on/off*. Lock the carrier into position to power unit on and
prevent unintentional removal during operation. Turn the key lock 90
degrees clockwise into horizontal position. Unit is now locked, powered
on, and ready for operation.
When the DataCOT™ is powered on, the green power LED should be
illuminated to conrm the unit is operational.
* Some models feature a non-electronic key lock that functions
independently from drive power.
1.
2.
3.
Troubleshooting Guide
DataCOT™ does not turn on.
Check to make sure all cables are properly secured.
Make sure carrier is properly secured
DataCOT™ does not recognize hard drive.
Check to make sure all cables are properly secured.
Make sure carrier is properly secured.
Make sure hard drive is properly connected.
1.
2.
1.
2.
3.
TO PREVENT DAMAGE AND DATA LOSS TO YOUR HARD DRIVE, DO
NOT REMOVE CARRIER WHILE DATA IS TRANSFERRING.
!
CAUTION
Technical Support
Please contact us at (800) 550-8611
Email us at techsupport@edbentor.com
•
•
3
WIRING DIAGRAM SHEET
5
WIRING DIAGRAM SHEET
5
EDBENTOR LLC, MAKERS OF DATACOT, WARRANTS THE PRODUCT
AGAINST DEFECTS IN MATERIAL OR WORKMANSHIP AS FOLLOWS:
LIMITED WARRANTY
Labor:
For the product’s lifespan, if the product is determined to be defective, Edbentor
will repair or replace the product with an equivalent, at its option, at no charge.
Parts:
Edbentor will supply, at no charge, new or rebuilt replacements in exchange for
defective parts for the life of the product. This warranty does not apply to the hard
drive installed in the product.
This warranty does not cover a product that has been damaged due to accident,
misuse, abuse, improper installation, usage not in accordance with the product
specications and instructions, natural or personal disaster, or unauthorized
alterations, repairs, or modications. Edbentor reserves the right to determine
warranty eligibility.
Limitations:
No warranties for this product, expressed or implied, shall extend to any person
who purchases the product in a used condition.
Edbentor makes no other representations or warranties as to the tness for a
particular purpose, merchantability or otherwise in respect to the product. No
other representations, warranties or conditions, shall be implied by statute or
otherwise.
In no event shall Edbentor be responsible or liable for any damages, including
but not limited to the loss of revenue or prot, arising:
From the use of the product
From the loss of use of the product
As a result of any event, circumstance, action or abuse beyond the control of
Edbentor; whether such damages be direct, indirect, consequential, special
or otherwise and whether such damages are incurred by the person to whom
this warranty extends or a third party.
Warranty Service:
For warranty service instructions, contact one of our customer service
representatives at (800) 550-8611.
Before shipping any unit for repair, obtain an RMA number for warranty
service.
When shipping your product, pack it securely, show the RMA and serial
number of the product on the outside, ship prepaid and insured.
Edbentor will not be held liable for damage or loss to the product in
shipment.
•
•
•
•
•
•
6
38340-E Innovations Court, Unit 502
Murrieta, California 92563
