Eco 30 P Series Instrucciones de funcionamiento

ECO _30/60_P

Important Notice:

Please read this manual carefully before installing or operating BESS. Be sure to keep this manual for reference in the future.

The battery of the future

Energy Storage Solution



/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

Battery Energy Storage System

The battery of the future

Energy Storage Solution



Installation Manual & Commissioning

Contents

1. Preface.................................................................................................................. 2

1.1 Purpose .................................................................................................................................. 2

1.2 Application scope of the manual ............................................................................................ 2

1.3 Target readers ........................................................................................................................ 2

1.4 Preservation notes ................................................................................................................. 2

1.5 Key terms and definitions....................................................................................................... 2

1.6 label description...................................................................................................................... 3

2. Safety precautions................................................................................................ 4

2.1 Qualifications and responsibilities of operators...................................................................... 4

2.2 safety warning ........................................................................................................................ 5

3. BESS summary .................................................................................................... 6

3.1 BESS Components and dimensions...................................................................................... 7

3.2 Delivery list ........................................................................................................................... 10

4. Installation Preparation........................................................................................11

4.1 installation process................................................................................................................11

4.2 Installation Tool......................................................................................................................11

4.3 Environmental requirements for installation site.................................................................. 12

4.4 Site installation foundation ................................................................................................... 12

4.5 Transportation of outdoor energy storage cabinet............................................................... 15

5. Fixed ................................................................................................................... 21

5.1 fixing of outdoor energy storage cabinet.............................................................................. 21

6. wiring................................................................................................................... 22

6.1 Wiring of outdoor energy storage cabinet............................................................................ 25

6.2 BESS External wiring ........................................................................................................... 26

7. Complete the inspection..................................................................................... 31

8. Commissioning ................................................................................................... 32

1. Preface

1.1 Purpose

The purpose of this manual is to ensure safe operation during installation, ensure the quality of

equipment installation, ensure construction progress and promote installation technology.

1.2 Application scope of the manual

This manual is applicable to transportation, assembly, installation and commissioning. The

product model of enerark outdoor energy storage system is shown in the table。

ECO ESS Eco_30_P

Eco_60_PDMS

1.3 Target readers

This manual is for the use of designated operators only.

1.4 Preservation notes

This manual contains important information about the installation of outdoor energy storage

cabinets. Please read this manual carefully before operation. Please strictly follow the operation

methods described in the manual. Otherwise, it may cause equipment damage, personal injury

or death, and property loss. This manual shall be kept properly so that the operator can read it

at any time.

1.5 Key terms and definitions

BESS: energy storage system

PCS: power conversion system

DC-DC: voltage regulation system

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

BMS: battery management system

MPPT: maximum power point tracking system

STS: On-off-grid switching system

1.6 label description

Operators should read and understand the label carefully before any operation.

Note:

The outdoor energy storage label is only applicable to ECO_30/60_P ，Please note the capacity

WARNING:

AVERTISSEMENT:

REFER TO THE UESR

MANUAL WHEN

INSTALLIN OR OPERATING

CONSULTER LE MANUEL DE

L'UTILISATEUR LORS DE

L'INSTALLATION OU DE

FONCTIONNEMENT

WARNING:

AVERTISSEMENT:

SPARK HAZARD

To Reduce the Risk of injury.

read all instruction

RISQUE D'éTINCELLES

POUR RéDUIRE LE RISQUE DE

BLESSURES

LISEZ TOUTES LES INSTRUCTIONS

WARNING:

AVERTISSEMENT:

HAZARDOUS VOLTAGE

AUTHORISED ACCESS ONLY

ACCèS AUTORISé SEULEMENT

DES TENSIONS DANGEREUSES

CAUTION!

Risk of electric shock from energy stored in capacitor.

Do not remove cover until 5 minutes after disconnecting

all sources of supply.

ATTENTION!

RISQUE D'éLECTROCUTION EN RAISON DE

L'éLECTRICITé EMMAGASINéE. ATTENDRE 5

MINUTES APRèS AVOIR Dé BRANCHé TOUTES LES

SOURCES D'ALIMENTATION AVANT D'Y ACCéDER.

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

difference between different models.

2. Safety precautions

2.1 Qualifications and responsibilities of operators

A qualified operator is a person with the necessary knowledge, professional training and experience:

The Operators should obtain certificates in accordance with local regulations.

Protect and maintain the equipment according to relevant safety standards.

Help the injured at the first time.

Comply with local regulations, standards and management.

The operator must ensure that:

Before commissioning and closing the isolation circuit breaker, all basic information and step

instructions must be understood, especially the safety instructions for assembly and installation

that must be strictly observed.

FLASH PROTECTION

LEVEL A

Incident Energy : 1.0 cal/cm2

Working Distance: 45.7 cm

Arc Flash Boundary: 0.42 m

Non-melting or untreated natural fiber long-

sleeve shirtand long pants

SHOCK PROTECTION

Shock Hazard Exposure: 907 Vdc

Shock Hazard when covers removed

Limited Approach Boundary: 1.07 m

Restricted Approach Boundary: 0.3 m

PPE Glove Class 0

V-Rating 1500 Vdc

Equipment ID:

Arc Flash & Shock Hazard

Appropriate PPE Required

DANGER

FLASH PROTECTION

LEVEL A

Incident Energy: 0.6 cal/cm 2

Working Distance: 45.7 cm

Arc Flash Boundary: 0.27 m

Non-melting or untreated natural fiber long-

sleeve shirtand long pants

SHOCK PROTECTION

Shock Hazard Exposure: 480 Vac

Shock Hazard when covers removed

Limited Approach Boundary: 1.07 m

Restricted Approach Boundary: 0.3 m

PPE Glove Class 0

V-Rating 500 Vac

Equipment ID:

Arc Flash & Shock Hazard

Appropriate PPE Required

DANGER

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

Do not change the size and rating of the fuse.

Appropriate measuring devices must be used and appropriate standards and instructions must

be followed. Before making any measurement, you must understand the operation manual of the

measuring device.

Do not open the device during operation.

If required on site, forklifts, cranes and other construction machinery must be operated by

qualified operators.

When the equipment is connected to a place with power supply, a supervisor must be appointed

to protect the switch to be turned off.

Operators shall wear work clothes, and protective equipment, and be equipped with special tools

in accordance with the requirements of local laws and regulations.

The installation work must be undertaken by full-time operators;

During wiring, two or more operators are not allowed to connect one wire at the same time.

During the installation process, each completed item must be inspected once, and cross

inspection is required.

The equipment must be installed in sequence, and no steps can be skipped.

Isolation belt must be set during installation to prevent irrelevant personnel from entering the site.

2.2 safety warning

Danger: an extremely dangerous situation

This warning sign indicates that there is an immediate danger that may cause

serious personal injury or death.

Warning: indicates a very dangerous situation

Indicates a potentially dangerous situation that may result in serious personal

injury or death.

Warning: indicates a dangerous situation

Indicates a potentially dangerous situation that may cause minor personal injury.

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

3. BESS summary

Energy storage technology has been recognized as an important part of the six links of power

generation, transformation, transmission and distribution, application and energy storage in the

operation of power system. Incorporating energy storage into the power grid system can effectively

manage the demand side, eliminate the power grid peak, smooth the load curve, and adjust the

frequency and voltage. Promote the application of renewable energy by improving the stability of

power generation of renewable energy system. Energy storage has important strategic application

value in the future energy structure.

Bess includes battery, BMS, DCDC, PCs, MPPT, STS, auxiliary power system, fire protection

system, air conditioning system and grounding system.

Batteries and BMS systems are used to store electrical energy.

PCs is used for AC / DC conversion.

DCDC is used for voltage conversion.

MPPT is used for photovoltaic charging.

STS is used for parallel and off network switching.

The auxiliary power system provides power for all equipment in Bess.

The fire protection system is the protection of operators and Bess in case of fire.

The air conditioner is used to adjust the internal temperature of Bess.

Grounding system is the safety guarantee of Bess.

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

3.1 BESS Components and dimensions

Picture 3-1 BESS (Outside)

Item No Name Remark

thgilrotacidni1

renoitidnocria2

3 Emergency stop button

Picture 3-2 BESS inside （front）

Item No Name Remark

MMB1

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

xobdetargetnI2

hctiwsecnanetniaM3

ledoMyrettaB4 (the number of 30kW modules

is 15 packs)

lanoitpOCD-CD5

SCP6

lanoitpOSTS7

lanoitpOTPPM8

retemCA9

lanoitpOretemdaoL01

lanoitpOrekaerbtiucricCA11

rekaerbtiucricdaoL21

Picture 3-3 BESS inside （after ）

Item No Name Remark

1 Photovoltaic circuit breaker optional

noitcetorpgninthgil2

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

Picture 3-4 Front side view

Picture 3-5 Right side view

outdoor energy storage 1861.5 1267 1835 2300

/ecoess.co.uk

Mobile : + 44 (0) 7729636318

Landline : + 44 (0)116 366 9980

Website : www.ecoess.co.uk

E-mail : [email protected]

72- Evington Road,

LE2 1HH Leicester, UK

BESS measure

Name W(mm) D(mm) H(mm) W(kg)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Accesorios para cámaras de otras marcas

Viltrox

Viltrox EF-NEX Instrucciones de instalación

Calumet

Calumet 7100 Series CK7114 Manual de usuario

Ropox

Ropox 4Single Series Manual de usuario

Cambo

Cambo Wide DS Digital Series Instrucciones de funcionamiento

Samsung

Samsung SHG-120 Manual de usuario

Ryobi

Ryobi BPL-1820 Manual de operación

Aegis

Aegis ABL-36020P Manual de usuario

Pentax

Pentax Data Back Fc Manual de usuario

Fantasea

Fantasea EyeGrabber F Series Manual de usuario

Honeywell

Honeywell HDZ20HD Manual de usuario

EGO

EGO BA1400T Manual de usuario

Sima

Sima SRW-62 Manual de usuario

Shape

Shape A7SSMKIT Manual de usuario

Slide Kamera

Slide Kamera HST-2 Manual de usuario

Power works

Power works 2902613 Manual de usuario

SES

SES SE-2047-2 Manual de usuario

Olympus

Olympus PT-EP05L Manual de usuario

Starlite

Starlite OctoDome nxt Manual de usuario
