Eclipse TD725SWMK2 Manual de usuario
Thank you for purchasing this product.
Please read this instruction manual carefully and use the product correctly.
Before using the product, please read the "Important Safety Instructions" section.
Please keep this instruction manual together with the original product purchase receipt in a place
where it can be referred to when necessary.
Instruction Manual ENGLISH
JAPANESE ENGLISH FRANÇAIS
td725swmk2en.indd21 2014/04/1417:51:38
22
Contents
Audio etiquette
Your enjoyable music may be bothersome depending on the location. Please enjoy your
music at an appropriate volume so that it does not bother your neighbours.
In particular, even music at a low volume can easily travel through your surroundings at
night.
Please be considerate of your neighbours and help create a comfortable living
environment.
•
•
Features......................................... 23
Checking the main unit and
accessories................................... 23
Important Safety Instructions...... 24
Important items for safety................. 27
Part names and functions............ 29
Rear panel........................................ 29
Front panel ....................................... 30
Remote control................................. 30
Inserting batteries into the remote
control ........................................... 32
Setting up the subwoofer ............ 33
Attaching the feet ............................. 33
Setup location................................... 33
Connecting the subwoofer .......... 34
Typical connection............................ 34
Connection with the speaker terminals
... 35
Basic usage (listening to audio)
... 36
Mute ................................................. 36
Automatically turning the power on and
off (auto power) ................................ 36
Adjusting the audio...................... 37
Adjusting the volume........................ 37
Adjusting the LPF............................. 37
Switching the phase polarity............. 38
Switching bass emphasis (BASS).... 38
Care and cleaning......................... 39
When a problem occurs............... 39
Specifications ............................... 40
Warranty and customer service .. 41
td725swmk2en.indd22 2014/04/1417:51:39
23
JAPANESE ENGLISH FRANÇAIS
Subwoofer x1•
Checking the main unit and accessories
Instruction manual x1•
Power cable x1 (P.34, 35)•
For the USA
For the UK
For Europe
Remote control x1•
Battery for remote control (size AA) x2
(P.32)
•
Foot x4 (P.33)•
Logo sticker x1•
This product is a subwoofer system that has been designed based on Time Domain theory.
This will give you an enjoyable, fast and crisp bass sound.
Features
Time Domain theory
Theory with the goal of reproducing accurately the audio waveforms carefully created by
artists and engineers. This conveys the delicate expressions that musicians have included
in their music and creates a space that feels alive.
td725swmk2en.indd23 2014/04/1417:51:39
24
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.
• Explanation of Graphical Symbols
The lightning flash with arrowhead
symbol, within an equilateral
triangle, is intended to alert you
to the presence of uninsulated
dangerous within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock.
The exclamation point within an
equilateral triangle is intended
to alert you to the presence
of important operating and
maintenance (servicing) instructions
in the literature accompanying the
appliance.
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT
AND FULLY INSERT.
Important Safety Instructions
WARNING
When there is a problem or malfunction...
When one of the following problems occurs, immediately stop using the product,
turn off the power, and unplug the power plug from the power outlet.
- The product produces an unusual noise or smell - The product produces smoke
- The product is falls or is damaged
If you continue using the product when there is a problem, there is a risk of fire or
electric shock.
Do not repair, disassemble, or modify the product yourself.
There is a risk of fire, electric shock, or injury.
For repair, inspection, and adjustment, contact customer service. (P.41)
During use...
Do not place vases, flower pots, cups, makeup, chemicals, or other containers
that contain liquids on or near the product.
There is a risk of fire or electric shock due to leaks and foreign substances.
■
■
■
td725swmk2en.indd24 2014/04/1417:51:39
25
JAPANESE ENGLISH FRANÇAIS
Power plug and cable...
Do not use the product with a power supply voltage outside that displayed on the
main unit.
There is a risk of fire, electric shock, or malfunction.
Always use the included power cable.
There is a risk of fire or accidents.
Do not overload the power outlet by plugging in many devices.
There is a risk of fire due to the heat generated.
Do not damage the power cable in the following ways.
- Scratching the cable - Forcibly bending the cable - Twisting the cable
- Working on the cable - Heating the cable - Pulling the cable
- Placing heavy objects on the cable
There is a risk of fire or electric shock due to damage.
If the power cable is damaged such as when the core is exposed or the cable is broken,
please replace it.
When there is a risk of lightning, unplug the power plug from the power outlet and
do not touch the plug.
There is a risk of fire, electric shock, or malfunction.
■
■
■
■
■
CAUTION
During setup or when moving the product...
Do not place the product in the following kinds of locations.
- Rickety platforms, inclined and unstable locations, and elevated locations
There is a risk of falls, malfunction, or injury.
- Locations exposed to oily smoke or steam such as kitchen countertops and
near humidifiers
- Locations exposed to direct sunlight for long periods of time and near heaters
or open flames
There is a risk of fire, deformation, discoloration, accidents, or malfunction.
- Locations directly exposed to cold air
- Extremely cold locations
There is a risk of electrical leakage or burnout, accidents, or malfunction due to
condensation.
Be aware of the following items when moving the product.
- This product is heavy. Always open the product packaging and carry the product
with two or more people.
There is a risk of injury.
- Turn off the power to the connected devices and unplug the power cable,
connection cables, and speaker cables.
If the product is moved with the cables connected to it, there is a risk of fire, or electric
shock due to damaging the cables.
■
■
WARNING
td725swmk2en.indd25 2014/04/1417:51:40
26
During setup or when moving the product... (Continued)
First turn off the power to all devices to connect to the product before making the
connections.
Connect each device according to its instruction manual.
If you connect devices with the power turned on, there is a risk that product may
suddenly produce a loud noise and malfunction.
Power plug and cable...
Do not use an unstable or loose power outlet.
There is a risk of fire or electric shock due to the heat generated.
Ask an electrician to replace the power outlet.
Do not plug or unplug the power plug with wet hands.
Do not touch the power plug's pins.
There is a risk of electric shock.
Plug the power plug all the way into the power outlet.
There is a risk of fire due to the heat generated or from accumulated dust.
Do not place the power cable near heaters. Do not use the power plug and cable
when they are hot.
The cable jacket will melt causing a risk of fire or electric shock.
Regularly remove any accumulated dust on the power plug pins.
There is a risk of fire or electric shock.
Unplug the power plug and wipe it with a dry cloth.
During use...
Do not climb on the product or use it as a step or a seat.
There is a risk of injury due to the product falling over or being damaged. Households
with small children should be particularly careful.
Do not take the following actions with the remote control.
- Dropping the remote control - Hitting the remote control - Getting the remote
control wet - Placing the remote control in humid or dusty locations
These actions will cause the remote control to break, malfunction, or increase the
consumption of the batteries.
Before turning on the power, set the volume of the amplifier and subwoofer to the
minimum level.
A loud noise may suddenly occur causing the risk of hearing loss or damage to the
product.
When the product produces unusual sounds during playback at high volumes,
lower the volume.
If the product is used in this state or the product is used for a long period of time when
the sound is distorted, the speaker will generate heat causing the risk of fire.
■
■
■
■
■
■
■
■
■
■
■
■
CAUTION
td725swmk2en.indd26 2014/04/1417:51:40
27
JAPANESE ENGLISH FRANÇAIS
Important items for safety
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
■
During care and cleaning...
Turn off the power and unplug the power plug from the power outlet.
There is a risk of electric shock or injury.
When not using the product for a long period of time...
Turn off the power and unplug the power plug from the power outlet.
There is a risk of fire.
■
■
CAUTION
td725swmk2en.indd27 2014/04/1417:51:41
28
<For the customers in European union>
The batteries, accumulators, or equipment incorporating batteries or accumulators which are
labeled with crossed-out wheeled bin may not be disposed of with household waste.
This mark is based on European Directive 2006/66/EC for the batteries and accumulators.
To dispose of waste batteries, accumulators or equipment incorporating them, please take
them to the designated collection facilities.
Waste batteries and accumulators have the potential effect on the environment and human
health as a result of the presence of hazardous substances, particularly heavy metals such as
cadmium, lead, or mercury, the chemical symbol for an element of which is indicated beneath
crossed-out wheeled bin.
You can contribute to eliminate this effect by your cooporation.
In accordance with the European Directive 2002/96/EC (for Waste Electric and Electronic
Equipment=WEEE), this product, which is labeled with crossed-out wheeled bin, may not be
disposed of with household waste in member states of the EU.
WEEE : Waste Electrical and Electronic Equipment
When disposing of this product in an EU member state, dispose properly in accordance with
the laws of that state, for example by returning it to the distributor. WEEE has the potential
effects on the environment and human health as a result of the presence of hazardous
substances. You can contribute to eliminate these effects and to enhance reuse/recycle/ other
forms of recovery by your cooperation.
td725swmk2en.indd28 2014/04/1417:51:41
29
JAPANESE ENGLISH FRANÇAIS
Part names and functions
Volume control (P.37)
Adjusts the volume.
L.P.F control (P.37)
Adjusts (cuts) the high-pass frequency.
Adjustment range: 30 Hz to 150 Hz
L.P.F selector switch (P.37)
Turns the LPF on and off.
XLR input terminal
Connect this terminal if the subwoofer
output or line output on your AV amplifier
is an XLR connector.
* TD725SWMK2 only
LINE input terminals (P.34)
Connect these terminals to the subwoofer
output or line output on your AV amplifier.
LINE output terminals
Converts the signal input to the XLR input
terminal, LINE input terminals, or speaker
input terminals to line level and outputs
it. (This is not linked to the subwoofer's
volume control on this product.)
Speaker input terminals (P.35)
Connect these terminals to the speaker
output on your AV amplifier if it does not
have a subwoofer output.
Speaker output terminals (P.35)
Outputs the signal input to the speaker
input terminals without modifications.
POWER switch (P.36)
Turns the power on and off.
AUTO POWER switch (P.36)
Turns auto power on and off.
AC IN terminal (P.34, 35)
Connect to a household AC power outlet
with the included power cable.
Rear panel
■
* , , , and are only
for INPUT 2
***
*
td725swmk2en.indd29 2014/04/1417:51:41
30
Remote control
■
Front panel
■
td725swmk2en.indd30 2014/04/1417:51:42
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Subwoofer de Eclipse
