MM-4320-DVR
4.3” Factory Mount Mirror Monitor
with Built-In DVR
Operating Instructions (continued)
Pressing the menu button when a video signal is being viewed will allow you
to adjust the following parameters.
Brightness Adjust the brightness level of the display (0-100).
Color Adjust the color of the display (0-100).
Contrast Adjust the contrast of the display (0-100).
Sharpness Adjust the display sharpness (0-100).
Reset This resets all values to the default setting.
The screen will automatically turn on when it detects a signal input on either
channel. If a signal is detected on both channels then V2 will take priority.
To stop and start recording, press the REC button. If a shock event is
detected, the unit will automatically protect the current le.
When using the DVR function the menus can be accessed by pressing the
MENU button. (Recording must be stopped for this to be enabled).
The menu categories can be scrolled through by pressing the MODE
button and then each list can be scrolled through by pressing the REC
button.
To enter a menu feature, press the REC button and change the values using
the up and down arrow buttons. Repeatedly pressing the REC button will
back out to the main menu.
Pressing MENU again will exit the menu structure.
Movie Mode menu:
Movie Mode Adjust the resolution of the recording.
Movie Quality Adjust the picture quality (lower quality will increase
the amount of video able to be recorded).
Movie Clip Time Sets the length of each individual recording clip.
Movie Off Time This sets how long after power off the unit will
continue to record for.
