EAW DWG FB276 Guía de inicio rápido
123 4
123 4
A
B
C
A
B
C
PRO ENGINEER
0026003-CD-A_DWG_FB276_FLYBAR
THE INFORMATION CONTAINED
HEREIN IS PROPRIETARY AND
CONFIDENTIAL PROPERTY OF
LOUD TECHNOLOGIES, INC.
ALL RIGHTS RESERVED
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN INCHES
DUAL [MM] DIMENSIONS
FOR REF ONLY
TOLERANCE IN INCHES
LINEAR ± 0.13 in / ± 3.3 mm
ANGLES ± 1°
(X.XX) = REF DIMS
NO TOLERANCE IMPLIED
TSC = THEORETICAL SHARP CORNER
DIMENSIONS ACROSS CENTERLINES
TO BE SYMMETRICAL
REVISION:
DRAWING NUMBER:
THIRD ANGLE PROJECTION
TITLE:
SCALE:
1 1
www.eaw.com
41.26
1048.0[ ]
46.00
1168.4[ ]
6.00
152.4[ ]
2X 9.31
236.5[ ]
25.50
647.7[ ]
2.76
70.1[ ]
DATECHANGE NUMBERREV
12/15/08DSRWH10221A
0026003-CD A
ASHEET OF 0.038
DWG CUSTOMER
FB276 FLYBAR
[MECHANICAL SPECIFICATION]
NOTES:
1. SYMBOL INDICATES CENTER OF BALANCE.
(CENTER OF BALANCE DOES NOT INCLUDE
SHACKLE BRACKETS.)
2. WEIGHT APPROX. 135.00 lb [61.4 kg].
3. WHEN SHACKLE BRACKETS ARE IN THEIR STORAGE
LOCATIONS THEY ARE FULLY CONTAINED WITHIN
FLYBAR DIMENSIONS.
FB276 FLYBAR
2X STORAGE LOCATIONS,
SEE NOTE 3
TOP
FRONT
2X SHACKLE BRACKETS,
SEE NOTE 3
