USER GUIDE

PowerRite XT UPS

400 VA, and 600 VA

www.powerware.com.au

Table of Contents

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

UPS Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Communication Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Eaton Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Trademarks

Windows is a registered trademark of Microsoft Corporation.

All other brand and product names are trademarks or registered trademarks of their respective holders.

Safety Instructions

IMPORTANT SAFETY INSTRUCTIONS!

SAVE THESE INSTRUCTIONS!

This User Guide contains important instructions for your PowerRite XT that must be followed

during installation and operation of the UPS.

The installation and use of this product must comply with all national, federal, state, municipal, or

local codes that apply. For assistance, call Eaton Power Quality Service or your local Eaton Power

Quality office.

If the PowerRite XT has been damaged during shipment, call your vendor immediately.

If the PowerRite XT is stored, the batteries should be recharged every 6 months. If stored above 25°

Celsius, recharge the batteries more often.

CAUTION!

Whenever the unit’s On/Off switch is “On,” there may be dangerous voltage present at the unit’s outlets. This

is true because the unit’s battery supplies power even if the unit is not plugged into the wall outlet. The unit

contains dangerous voltages.

To reduce the risk of electric shock, install the unit in a temperature-controlled and humidity-controlled indoor

area free of conductive contaminants. Do not allow liquids or other foreign objects to enter the UPS, or place

them near to it.

The power supply cord is intended to serve as the disconnect device. The socket-outlet must be near the

equipment and must be easily accessible.

All servicing of this equipment must be performed by qualified service personnel.

There are no user servicable parts within this UPS.

UPS Features

The PowerRite XT provides protection against power problems, including power outages,

brownouts, and surges. It also provides spike suppression and line noise filtering to protect your

equipment. Use the drawings below to identify features of the unit.

Start Up

1Your PowerRite XT has a removable power cord. Connect the power cord to the back of the unit.

Plug the UPS into a wall outlet.

2Let the unit charge the battery for at least 3 hours. You may use the unit while the battery charges,

but the battery backup runtime will be reduced until the battery is fully charged. This will take up

to 8 hours after a full discharge while the PowerRite XT is fully loaded.

3To start the unit, press the On/Off switch (located in the centre of the front panel). When the unit

starts, it will beep and light the front panel LED. The green light should remain on. This indicates

normal operation.

4Switch off the equipment you want to protect with battery backup and plug it into the outlets on the

rear of the PowerRite XT. This equipment will continue to operate from the battery when the input

line fails.

5Switch on the protected equipment, one piece at a time. If the UPS beeps an alarm when you start

your equipment, the UPS may be overloaded. See the Troubleshooting section.

6The PowerRite XT UPS is equipped with D.C. Start. To start the UPS when AC power is not

available, simply press the power switch.

On/Off

Switch

Indicator

LED

Output

Socket

Communication

Port

Input

Socket

and Fuse

PowerRite XT

Troubleshooting

If you have a question or problem, the troubleshooting table may help. (See Table 1.) If you need

assistance, phone Eaton Power Quality Service or your local Eaton Power Quality Customer Service

office. Please have the model number and serial number (located on the rear of the unit) available.

If the unit must be returned, Eaton Power Quality will give you a Return Authorization (RA) number.

Phone Eaton Power Quality for an RA number before returning the unit for any reason.

Table 1: Troubleshooting

Problem Possible Reasons What To Do

No LED display on the 1. Missing battery 1. Charge battery up to 8 hours

front panel 2. Battery defect 2. Replace with the same type of battery

Alarm buzzer beeps Overload of the UPS Verify that the load matches the UPS capability

continuously when AC specified in the specifications

supply is normal.

When power fails, backup 1. Overload of the UPS 1. Remove some noncritical load

time is shortened 2. Battery voltage is too low 2. Charge battery 8 hours or more

3. Battery defect due to high 3. Replace with the same type of battery

temperature operation

environment, or improper

operation to battery

Mains normal but LED 1. Fuse is blown 1. Replace the same type of fuse

is flashing 2. Power cord is loose 2. Reconnect the power cord properly

Eaton Power Quality

National Service & Repair Centre

Phone: 1300 303 059

Communication Port

Your PowerRite XT is equipped with a communication port, for use with LanSafe interfacing soft-

ware, and a cable. Further information is available on the LanSafe CD.

Specifications

Model PRXT-0400A PRXT-0600A

Capacity VA/Watts 400VA/240W 600VA/360W

Input Voltage 240VAC

Voltage Range 170-280VAC

Frequency 47-63 Hz (auto detection)

Output Voltage 230VAC

Voltage Regulation +10%

(Batt. Mode)

Frequency 50 Hz

Frequency Regulation +1 Hz

(Batt. Mode)

Output Waveform Modified Sinewave

Battery Battery Type Sealed Lead Acid Battery, Maintenance Free

Backup Time 6 mins at half load 10 mins at half load

Recharge Time 8 hours to 90% after complete discharge

Transfer Time Typical 10ms max.

Indicator AC Mode Green LED

Backup Mode Green Flashing LED

Audible Alarm Backup Mode Beeps every 10 seconds

Battery Low Beeps every 1 second

Overload Beeps every 0.5 second

Protection Discharge, Overcharge and Overload protection

Physical Dimensions (mm) 330 D x 100 W x 140 H

Weight Net Weight (kg) 5 6

Environment Operating Environment 0-40oC, 0-90% relative humidty

(non-condensing)

Noise Level Less than 40dBA

Interface Open Collector Supports Windows 98/NT/2000, Novell and

Linux

Warranty

This Warranty is subject to Eaton Power Quality Pty Ltd (EPQ) standard Conditions of Sale

which govern all sales of products by Eaton Power Quality Pty Ltd.

1. The PowerRite XT UPS is warranted against failure due to faulty materials and/or

workmanship for a period of 24 months from despatch date (ex EPQ store) as per

invoice.

2. If, within the applicable Warranty period, any EPQ product does not meet the

warranty specified above, and the product was installed and operated in accordance

with Australian standards and EPQ standard installation procedures, EPQ shall there-

upon correct any defects due to faulty materials and/or workmanship.

3. Any modifications made to the product other than those made by EPQ or its

authorised representative may cause the Warranty to be void.

4. The Warranty covers repair or replacement of defective parts at the factory, or other

service locations as nominated by EPQ.

5. Units returned for in-warranty repairs, which are found not to be defective, will be

subject to an inspection and handling charge, plus transportation charges. Units

returned for warranty must be freight pre-paid and accompanied by a Return

Authorisation Number, available from our Service Department.

6. EPQ reserves the right to charge for replacement batteries, if within the one year guar-

antee period replacement batteries are necessary as a result of misuse or

misapplication by the purchaser or end user.

SAVE TIME!

www.powerware.com.au

and receive the

Five-Year Pro-Rated Warranty and $50,000 Load Protection Guarantee

Absolutely FREE!

Disclaimers

The warranties and guaranties below, together with Powerware's Two-Year Limited Warranty, are exclu-

sive and in lieu of all other express and implied warranties whatsoever, including but not limited to

implied warranties of merchantability and fitness for particular purpose.

Powerware shall not be subject to any disclaims: 1) Any other obligations or liabilities arising out of

breach of contract or of warranty, 2) Any obligations whatsoever arising from tort claims (including neg-

ligence and strict liability) or arising under other theories of law with respect to products sold by

Powerware, or any undertakings, acts or omissions relating thereto, and 3) All consequential, incidental,

and contingent damages whatsoever.

Extended Five-Year Pro-Rated Warranty and

Computer/Load Protection Guarantee

Applies only to original purchasers for end use in Australia &New Zealand who file the

Warranty Registration Card on line within 30 days of purchase.

In addition to its standard Two-Year Limited Warranty and $50,000 Computer/Load Protection Guarantee

below, Powerware further warrants its UPS will have a service life of five years from the date of ship-

ment from Powerware's factory when used in accordance with the storage, handling, installation, opera-

tion, and maintenance procedures prescribed in the following section of this warranty and in the

Operator's Manual. "Service life" means the UPS' ability to deliver at least 80% of it original rated back-

up time.

If Powerware finds that any UPS has not provided the five-year warranted service life, Powerware will,

as its sole obligation and the user's sole remedy for breach of this warranty, repair or replace the unit, at

its option, F.O.B. Powerware Corporation's factory, for a charge pro-rated on the following basis. The

user will be allowed a credit against the list price of equivalent equipment at the time of return to

Powerware, in proportion to the percentage of the warranted service life remaining at the time of return

to Powerware Corporation. (In calculating the available credit, the remaining warranted service life will

be rounded up or down to the nearest whole year.) The user will be responsible to pay the balance of the

list price of equivalent equipment; and Powerware reserves the right to require payment prior to delivery

of the repaired or replacement equipment.

Powerware's complete warranty responsibilities are therefore summarized as follows:

Years 1-2 - Unit Repaired or Replaced Free of Charge

Years 3-5 - Credit ($) = Current List Price X Years of Unexpired Life

5 Years of Warranted Life

Required Operating Conditions and Extended Five-Year Pro-Rated Warranty Exclusions

1. If you plan to store the UPS or battery cabinets prior to use, store them in a cool, dry environment.

Storage temperature should not exceed 95°F (35°C) in order to preserve battery life. For longer term

storage, energize the UPS and battery cabinet for approximately 8 hours every 90 days in order to

maintain battery charge. Whenever the units are not energized, verify that the circuit breaker on all

battery cabinets is returned to the OFF (O) position.

2. Average annual temperature at equipment site shall not exceed 77°F (25°C).

3. The above warranty does not apply to units with broken or damaged enclosures, input cables or out

put receptacles, or to units that have been frozen or damaged due to neglect, accident, or abuse such

as fire, flooding, explosives, or exposure to weather conditions.

4. The above warranty also does not apply to units that have been improperly installed, altered, or

tampered with in any way, or if the equipment was not used under normal operating conditions and in

accordance with labels and instructions.

Extended Five-Year Pro-Rated Warranty Claims Procedure

Powerware will not accept any product for return, credit, or exchange unless expressly authorized by

Powerware in writing and delivered to F.O.B. Powerware's factory. Nor will Powerware be responsible

for any charges for testing, checking, removal, or installation of a warranted UPS or component part of a

UPS.

All defective UPS units and parts, when returned and replaced, become the property of Powerware.

This warranty applies only to the original end user of the equipment and is nontransferable.

$50,000 Computer/Load Protection Guarantee

For the lifetime of the original purchaser who has filed the Warranty Registration, Powerware promises to

repair or replace (at Powerware's option) equipment (valued up to $50,000) that is damaged by an AC

power line surge, spike, or other transient when properly connected to Powerware's UPS (reimbursement

for or restoration of data loss excluded). This guarantee applies only in all of the following circum-

stances:

1. The UPS is plugged in to properly grounded and wired outlets using no extension cords, adapters,

other ground wires, or other electrical connections.

2. The installation of the UPS complies with all applicable electrical and safety codes described by the

AS/NZ Standards.

3. The UPS was used under normal operating conditions and in accordance with all labels and

instructions.

4. The UPS was not damaged by accident (other than AC power line transient), misuse, or abuse.

Standard Warranty Registration

Please complete this form, photocopy and mail to

Eaton Power Quality Pty Ltd, 13 Healey Road

Dandenong Victoria 3175 Australia

or register online at

www.powerware.com.au

UPS Model Number: ..................................... UPS Serial Number: .................................

Date of Purchase: ..................................... Contact Person: .................................

Company/Organisation: .........................................................................................................

Address: .........................................................................................................

City: .................................................... State: ..................... Postcode: ........................

Telephone: ................................................... Fax: .................................................

Email: ......................................................................................................................

1. Where did you purchase this Powerware UPS from?

Retail Store Computer Store EPQ Distributor Direct from EPQ

Electrical Wholesaler Internet Other .......................................

2. Why did you purchase a Powerware UPS (check all that apply)?

Recommendation Reputation After Purchase Support Features

Price Other .......................................

3. What features of a UPS are important to you?

Appearance Front Panel Display Backup Time RS232

Communications UPS Management Software Other .........................................

4. Please specify the equipment being protected by your Powerware UPS?.

Brand ..................................... Model .............................. Operating System ..................

5. Would you like information about EPQ Extended Warranty?

Yes No

Eaton Power QualityAustralia/New Zealand Offices

Head Office - Sydney

Eaton Power Quality Pty Ltd

119-127 Wicks Road

North Ryde NSW 2113

Phone: 61-2-9878 5000

Fax: 61-2-9887 2186

National Service and Repair Centre: 1300 303 059

Customer Service Offices

Adelaide

PO Box 481, Marlestone Business Centre

SA 5033

Phone: 08-8347-3622

Fax: 08-8445-6328

Brisbane

Unit 4, 11 Donkin Street

West End, QLD 4101

Phone: 07-3891-1211

Fax: 07-3891-2492

Melbourne

13 Healey Road

Dandenong VIC 3175

Phone: 03-9706 5662

Fax: 03-9794 9150

Perth

Unit 2, 23 Geddes Street

Balcatta, WA 6021

Phone: 08-9240 5655

Fax: 08-9240 5644

New Zealand

PO Box 39-572

Howick 1730 Auckland NZ

Phone: 64-9-535 3084

Fax: 64-9-535 3083

PRXTManual Rev 2 December 2004

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unión Postal Universal de Eaton

Eaton

Eaton MX 4000 RT Manual de usuario

Eaton

Eaton 93PM IBC-L Manual de usuario

Eaton

Eaton Ellipse ECO 500 Manual de usuario

Eaton

Eaton Powerware 9135 Manual de usuario

Eaton

Eaton 3S850 Instrucciones de montaje

Eaton

Eaton Power Xpert 9395 550/275 Manual de usuario

Eaton

Eaton 9395-275 Manual

Eaton

Eaton 93PM IBC-L Manual de usuario

Eaton

Eaton Power Xpert Gateway Minislot Manual de programación

Eaton

Eaton Power Xpert 9395P 250 kVA Manual

Eaton

Eaton 93PM 150 kW SIAC-B Three-Wire Manual de usuario

Eaton

Eaton Powerware 5110 Manual de usuario

Eaton

Eaton 93PM-L IAC-B Manual de usuario

Eaton

Eaton E.T.N 1500 VA - 60kVa Manual de usuario

Eaton

Eaton Powerware 9155 Manual de usuario

Eaton

Eaton 9135 Two-in-One UPS 5000/6000 VA Manual de usuario

Eaton

Eaton Powerware 9395 Manual de usuario

Eaton

Eaton Evolution 650/650 Rack 1UEvolution 850 Manual de usuario

Eaton

Eaton Power Xpert 9395C Manual de usuario

Eaton

Eaton Pulsar Series Manual de usuario

Eaton

Eaton Powerware 9170+ Manual

Eaton

Eaton 9315 Manual de usuario

Eaton

Eaton 93PM G2 Series Manual

Eaton

Eaton 5S 700VA Manual de usuario

Manuales populares de Unión Postal Universal de otras marcas

Pylontech

Pylontech Victron & Pylontech US5000 Manual de usuario

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manual de usuario

Mecer

Mecer ME-1000-WTU Manual de usuario

Mustek

Mustek PowerMust 530(B) Plus Manual de instalación y operación

Emerson

Emerson Liebert NXL series Manual de usuario

MAKELSAN

MAKELSAN BOXER SERIES Manual de usuario

Block

Block PC-0524-400-0 Manual de usuario

CyberPower

CyberPower CP585LCD Manual de usuario

CyberPower

CyberPower Office Tower Series UPS 1000 Manual de usuario

CyberPower

CyberPower BM100 Manual de usuario

Best Power

Best Power 610 Manual de usuario

Best Power

Best Power Unity/I UT3K Manual de usuario

Mustek

Mustek PowerMust 400 Offline Manual de usuario

Xantrex

Xantrex Trace 512 UR-UPS Manual de usuario

Forza

Forza SL-1501UL Manual de usuario

LEGRAND

LEGRAND keor 310081 Manual de usuario

ABB

ABB Conceptpower DPA 500 Manual de usuario

ZincFive

ZincFive BC Series Manual de usuario
