EASY COOPS Chicken Coop Plan 8x15 Manual de usuario

8'x15' Chicken Coop Plan

Up to 8 chickens

Compare Free vs. Premium plan

Free plan Premium edion

Pages

 0 0

 0 0

 0 0

 0 0

 0 0

 0 0

 0 0

 0 0

 0 0

TRY PREMIUM

8'x15' chicken coop material list

Site Preparation

•Concrete

•Bricks

Bottom Frame

•Pressure-Treated Lumber

•Plywood

Walls Exterior Siding

•Pressure-Treated Lumber

•Wood siding boards

Walls Frames

•Pressure-Treated Lumber

Top Frame

•Pressure-Treated Lumber

Shed’s Roof

•Pressure-Treated Lumber

•Pressure-Treated Board

•Plywood

•Building paper

•Asphalt shingles

•Metal drip edge

Fasteners & Hardware

•Corner braces

•Galvanized nails

•Wood screws

Front/Side Shed's Window

•Pressure-Treated Lumber

•Window beading

•Glass

Assemble The Bottom Frame

1.1 Assemble the frame using 3 1/2” x 3 1/2” pressure-treated material. You will need two boards

cut to 12' that will be the rim joist and four boards cut to 3'-5" that will be the joist.

1.2 Secure the beams into the frame with 2x5" wood screws.

1.3 Using a speed square or carpenter's square, check the corners to make sure they are 90 degrees.

STEP 1

6'-4"

3 1/2"

3'-5"

Assemble The Coop's Studs

2.1 Using 3 1/2" x 3 1/2" pressure-treated material, cut four studs and assemble using the illustrations

below as a reference.

2.2 Use 4 1/2 “ x 4 1/2 “ x 1/2 “ corner braces and 8x1” wood screws to secure the corners (node A).

2.3 Make sure the corners are 90 degrees using a carpenter’s square or speed square.

STEP 2

Assemble The Aviary's Top Frame Joists

3.1 Provide the top frame joists using 3 1/2” x 3 1/2” and 1 1/2" x 3 1/2"pressure-treated material.

3.2 Make the round handle from the dowel 2" diameter and put it in round opening.

3.3 Secure the joists to the top frame with 4x5" wood screws.

3.4 Using a speed square or carpenter's square, check the corners to make sure they are 90 degrees.

D 2"

STEP 3

Framing The Floor

4.1 Using 1 1/2 “ x 3 1/2 “ pressure-treated material, cut three joist using the illustration

below as a reference.

4.2 Secure the joists to the bottom frame with 4x5" wood screws.

STEP 4

3'-5"

Assemble The Coop's Top Frame

5.1 Using 3 1/2" x 3 1/2" pressure-treated material, cut four joist and assemble using the

illustrations below as a reference.

5.2 Use 4 1/2 “ x 4 1/2 “ x 1/2 “ corner braces and 1” wood screws to secure the corners (node D).

5.3 Make sure the corners are 90 degrees using a carpenter’s square or speed square.

STEP 5

6 1/2"

1'-3"

8 1/2"

1'-11"

Framing The Left And Right Walls

6.1 Using 1 1/2 “ x 3 1/2 “ pressure-treated material, cut rough sills, window headers and attach them

using the illustration below as a reference.

6.2 Secure the stud with 4x5" wood screws.

STEP 6

Framing The Back Wall

7.1 Using 1 1/2 “ x 3 1/2 “ pressure-treated material, cut two studs and attach it using the illustration

below as a reference.

7.2 Secure the stud with 4x5" wood screws.

STEP 7
