electric vehicles
visit e-mio.eu
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
IMPORTANT VEHICLE COMPONENTS
Chain
The chain can stretch over time - this is normal. The
chain is tensioned with two counter screws. Clean the
chain in case of dirt and lubricate with a chain lubricant.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1.
Seat lock: turn the key in the ignition switch to
the left - you will be able to raise the seat and gain
access to the storage compartment and battery.
2.
Press the seat down and it will lock automatically.
Front and rear disc brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
3.
When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its war-
ming up, color change, distortion or other irregu
-
larities, immediately stop using the battery and
move away.
Recommendations for the storage and use of lithium-
-ion batteries
To extend battery life, follow these guidelines:
Charging:
1.
Use only the charger provided with the electric
motorbike. Connect the power supply to the char-
ger. Insert the charger output connector into the
battery input connector. When the indicator light
for fully charged battery comes on, rst pull the
plug from the battery input connector. The usual
charging time is about 4-5 hours. If the battery
is damaged, charging or discharging must stop.
2.
Avoid over-discharging the battery, charge the
battery before it is completely discharged. Full
discharge of the battery aects its life.
Storage:
1.
Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1.
When you test a single battery cell, you must test
it directly, not through, for example, a wire. In this
way a voltage drop can be avoided.
2. You must put on gloves or cut nails before remo-
ving a single battery cell so as not to damage the
cell and as a protection against the substances in
the cell. Pay special attention to the battery cover,
do not damage it.
3.
It is forbidden to bend the battery cell, drop it, hit
it, short circuit it or damage its seal.
4.
When assembling the battery, there are a few
important things to remember: the temperature
of the soldering iron should not exceed 350 Celsius
degrees, the soldering time should not exceed
3 seconds, the soldering frequency should not
exceed 5 times, the next soldering can be applied
to the previous ones only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1.
Press the adapter (1), turn the adjusting nut (3)
while holding the brake lever (2) and squeezing
the brake lever until the distance is 1/3-1/2 L. The
brake shoes must t snugly against the brake disc.
Press the brake lever. When it reaches the braking
performance, tighten the adjustment nut.
2.
The distance between the brake shoes and the
brake disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area
reaches 1/2.
Charger control
1.
Use only the original charger supplied with the
motorbike scooter. Remember to check the mains
voltage in your country. Do not confuse the 110
V charger with the 220 V charger.
2.
The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to
damage while charging.
4.
Check the charger sockets, make sure that the
soldered components are not damaged.
Engine and driver maintenance
1.
During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2.
Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3. Slow down when the weather conditions on the
road are not good. High vibrations and humidity
can break the connection of electrical parts.
USER
MANUAL
Maintenance schedule
check adjust replace oil/grease
Parts to be checked daily
eve-
ry 60
days
eve-
ry
180
days
engine, moving parts
tires and all light bulbs
brake discs and pads
wheels
fork
brakes
horn, charger and battery
chain
TROUBLESHOOTING
Problem Cause Solution
The power indicator will
light up but the electric
otorcycle is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or
is not fully folded, which cuts o the
power supply.
1. Replace the engine. Call your dealer
to order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power
is turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is
damaged.
3. Frequent stopping and starting, over-
loading the vehicle, driving uphill, strong
wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid
acceleration and braking maneuvers,
maintain your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut
o the circuit.
1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
RESOURCES
bulbs: 1 x 12V 5W W5W (front), 1 x 12V 35W HS1 (front),
4 x 12V 10W R10W BA15S (direction indicators, orange),
LED (back)
brake uid: DOT3/DOT4
gearbox oil: 80W90
electric vehicles
visit e-mio.eu
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
IMPORTANT VEHICLE COMPONENTS
Chain
The chain can stretch over time - this is normal. The
chain is tensioned with two counter screws. Clean the
chain in case of dirt and lubricate with a chain lubricant.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1.
Seat lock: turn the key in the ignition switch to
the left - you will be able to raise the seat and gain
access to the storage compartment and battery.
2.
Press the seat down and it will lock automatically.
Front and rear disc brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
3.
When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its war-
ming up, color change, distortion or other irregu
-
larities, immediately stop using the battery and
move away.
Recommendations for the storage and use of lithium-
-ion batteries
To extend battery life, follow these guidelines:
Charging:
1.
Use only the charger provided with the electric
motorbike. Connect the power supply to the char-
ger. Insert the charger output connector into the
battery input connector. When the indicator light
for fully charged battery comes on, rst pull the
plug from the battery input connector. The usual
charging time is about 4-5 hours. If the battery
is damaged, charging or discharging must stop.
2.
Avoid over-discharging the battery, charge the
battery before it is completely discharged. Full
discharge of the battery aects its life.
Storage:
1.
Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1.
When you test a single battery cell, you must test
it directly, not through, for example, a wire. In this
way a voltage drop can be avoided.
2. You must put on gloves or cut nails before remo-
ving a single battery cell so as not to damage the
cell and as a protection against the substances in
the cell. Pay special attention to the battery cover,
do not damage it.
3.
It is forbidden to bend the battery cell, drop it, hit
it, short circuit it or damage its seal.
4.
When assembling the battery, there are a few
important things to remember: the temperature
of the soldering iron should not exceed 350 Celsius
degrees, the soldering time should not exceed
3 seconds, the soldering frequency should not
exceed 5 times, the next soldering can be applied
to the previous ones only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1.
Press the adapter (1), turn the adjusting nut (3)
while holding the brake lever (2) and squeezing
the brake lever until the distance is 1/3-1/2 L. The
brake shoes must t snugly against the brake disc.
Press the brake lever. When it reaches the braking
performance, tighten the adjustment nut.
2.
The distance between the brake shoes and the
brake disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area
reaches 1/2.
Charger control
1.
Use only the original charger supplied with the
motorbike scooter. Remember to check the mains
voltage in your country. Do not confuse the 110
V charger with the 220 V charger.
2.
The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to
damage while charging.
4.
Check the charger sockets, make sure that the
soldered components are not damaged.
Engine and driver maintenance
1.
During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2.
Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3. Slow down when the weather conditions on the
road are not good. High vibrations and humidity
can break the connection of electrical parts.
USER
MANUAL
Maintenance schedule
check adjust replace oil/grease
Parts to be checked daily
eve-
ry 60
days
eve-
ry
180
days
engine, moving parts
tires and all light bulbs
brake discs and pads
wheels
fork
brakes
horn, charger and battery
chain
TROUBLESHOOTING
Problem Cause Solution
The power indicator will
light up but the electric
otorcycle is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or
is not fully folded, which cuts o the
power supply.
1. Replace the engine. Call your dealer
to order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power
is turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is
damaged.
3. Frequent stopping and starting, over-
loading the vehicle, driving uphill, strong
wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid
acceleration and braking maneuvers,
maintain your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut
o the circuit.
1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
RESOURCES
bulbs: 1 x 12V 5W W5W (front), 1 x 12V 35W HS1 (front),
4 x 12V 10W R10W BA15S (direction indicators, orange),
LED (back)
brake uid: DOT3/DOT4
gearbox oil: 80W90
