E-matic EGlide Pro 2 Manual de usuario

Contents

1. Preface

2. Safety Notices

3. Ready to Use

3.1 Packing List

3.2 Product Appearance

3.3 Instructions on Keys

3.4 Features Overview

3.5 Technical Specifications

4. Quick Guides

4.1Switch On/Off

4.2Battery Management and Charging

4.3 Operation of the Function Icons

4.4WIFI Settings

4.5USB-HOST and Extended Function

4.6.1 External USB Function

4.6.2 External 3G USB Dongle Function

4.6.3External RJ45 USB Dongle Function

4.7 Camera Function

4.8 HDMI Function

4.9 MicroSD Card Storage

4.10 APK Install and Manage

5. Operation Details

5.1 Desktop System 1(Multimedia)

5.1.1 Audio Player

5.1.2 Video Player

5.1.3 Photo Browser

5.1.4 Sound Recorder

5.1.5 Explorer

5.2 Desktop System 2 (E-book)

5.2.1 Local E-book Reader

5.2.2 Online E-book Reader

5.3 Desktop System 3 (Network Function)

5.3.1 Web Brower

5.3.2 Email

5.4 Desktop System 4 (Games)

5.5 Desktop System 5 (Other Functions)

5.5.1 Calculator

5.5.2 Clock

5.5.3APK Installer

5.5.4Settings

5.5.4.1 Wireless and network

5.5.4.2 Sound

5.5.4.3 Display

5.5.4.4 HDMI

5.5.4.5 Location and security

5.5.4.6 Application

5.5.4.7 Accounts and sync

5.5.4.8 Privacy

5.5.4.9 Storage

5.5.4.10 Language and keyboard

5.5.4.11 Voice input and output

5.5.4.12 Date and time

5.5.4.13 About MID

5.6 Desktop Function Icon and Setting

5.6.1 Desktop Function Icon

5.6.2 Desktop Notification

5.6.3 Add, Move, or Delete Desktop Icon

6. Firmware Update

7. Troubleshooting and FAQ

7.1Troubleshooting

7.2Frequently Asked Questions

8 Limitations of Liability Statement

8.1 Links to Third Party Sites

8.2 Limitation of Liability

1. Preface

Dear Customers,

Thank you for purchasing our product!

This device is a built-in high performance WiFi receiver module,

supporting an external 3G USB-DONGLE wireless network card,

using broadband wireless networks, breaking through the restraint of

network cables; it will bring you into the portable media player world

and fulfill your entertainment needs. It also supports picture

browsing, eBook reading, games, online chat and other functions;

various settings will fully show your individuality.

To operate this player easily, first, please read this User Manual

included with the player. Before operating this player, please

carefully read all data we provide about the player, so that you will

have a better understanding of the product and its operations.

The Company will not be responsible for any loss of personal data

and damage caused by incorrect operation of the

Software/Hardware, artificial damages, replacement of batteries or

any other accident. To avoid loss of your data, please backup your

data to your computer at all times.

Also, since we cannot control any dispute from users’

misunderstanding or incorrect operation against the manual, the

Company will not take any relevant responsibility for any accidental

loss potentially occurring in the process of using this manual.

Due to constant product development, the information in this manual

is subject to change without any prior notice.

This manual is protected by copyright and no part is permitted to be

copied or reproduced in any way without prior written permission of

the Company.

The Company reserves the final explanation right of this manual,

warranty as well as its related information.

(Note: When compiling this manual, we are very careful to provide

you completely reliable information. However, there is inevitably

some error and oversight, please understand, and we welcome your

suggestions. If any problem occurs during your use of this product,

please immediately contact your local seller)

Thanks for your support and please pay attention to our other

products

2. Safety Notices

1) Please keep the device away from strong magnetic fields in order

to avoid damage to the product.

2) Please do not let the device fall onto, rub against or knock against

hard objects during use, because this may cause surface scratches

on the device, battery damage, dataloss or other damage to the

hardware.

3) Never let this product be exposed to a humid environment or rain

as the water leaking into the device could disable it to the extent of

being beyond repair.

4) Never clean the device with any chemicals or detergent, these will

damage the product surface and corrode the finish.

5) You are recommended not to use the headset with the volume at

its highest settings, please adjust the volume to an appropriate safe

level and limit the amount of time you spend using headphones to

avoid possible damage to your hearing. Excessive volume will cause

permanent hearing damage.

6) Please do not cut off the power abruptly during software updates

or downloading, because this may cause dataloss or system errors.

7) Over-voltage, power cable strain and bending or squeezing of the

power cable by heavy objects must be avoided to prevent the

possibility of overheating or fire.

8) In order to eliminate the risk of electric shock, do not touch the

cable power plug with wet hands.

9) Some movies, music and pictures are under the protection of

laws of copyright.

10) Please don’t turn on the device on in locations where wireless

equipment is forbidden or when the usage of the device will cause

interference and possible danger.

11) All the wireless equipment is subject to external interference and

this can affect its performance.

12) Please comply with any related restrictions and rules, wireless

equipment can influence the flight of the plane; please consult the

relevant airline company if you intend to use the device on a plane.

13) Please don’t use the device in a petrol station, or near to fuel or

chemicals.

14) Please comply with any related restrictions and rules; do not use

the device where blasting operations are in progress.

15) Only qualified maintenance personnel can install or repair the

device. Opening the device in any way will void the warranty.

16) Please use the original accessories and battery provided with

the device, do not use the incompatible products.

17) The device is not waterproof, please keep it dry.

18) For the sake of data safety, please back up any important

information on the device, or keep a handwritten record.

19) When connecting with other devices, please read the user

manual for detailed safety instructions. Do not connect the device to

incompatible products.

3. Ready to Use

3.1 Packing List

Components

Quantity

eGlide Pro 2 Tablet

Wall Charger

USB Cable

User Manual

CD-Rom

Warranty Card

eMusic Card

Kobo Offer

3.2 Product Appearance

3.3 Instructions on Keys

Symbol

Name

Description

RESET

Short press this button to reset

the system when the device has

stopped working (Freezes)

POWER

Short press this button to enter

sleeping/wake up mode, press

long to switch ON/OFF

Press this button shortly to enter

the submenu

ESC

Short press to return, long press

to enter the touch screen

calibration

MicroSD Card Slot

Micro SD Card Slot

HDMI

1080P HDMI Jack

Stereo Earphone Jack

DC Socket

Connect with 5V@2A Charger

MINI USB Port

MINI_5 PIN USB Port

USB Host Port

Port for external USB Driver,3G

Dongle, Mouse, etc

Display

HD Display area

Camera

Front camera

3.4 Features Overview

ARM embedded Dual CPU Structure（ARM Cortex A9 1.0GHz）

with ANDROID 2.3 operating system

7" high resolution TFT capacitive multi touch panel LCD display,

800x480 pixel resolution

Supports 4GB built-in Flash memory, supports max. 32GB

external Micro SD card

Supports HD 1080P MKV, AVI, RM, RMVB, MP4, MOV, VOB,

DAT, FLV, 3GP, H.246 etc formats, Max resolution supported is

1920*1080

Supports MP3, WMA, OGG, APE, FLAC, AAC, WAV audio

formats and multi EQ modes

Supports JPG, JPEG, BMP, GIF etc. picture formats

Supports TXT, LRC, PDF, Html, Html, EPUB file formats,

supportsauto-browse, zoom, bookmarks, flip over functions

WiFi ready, you can connect with broadband wireless internet and

operate various software in the Android 2.3OS, the system is

preset parts of third softwares: Office (Open Office version),

Google browser, IM (MSN/QQ), Web TV, Online MP3, online

novel, network games, eBook, etc

Supports built-in microphone recording function

Supports USB-HOST and external U-disk, Keyboard, Mouse, etc

Supports external 3G USB-DONGLE wireless network card (3G

card or USB-Dongle should be purchased separately)

Supports built-in front web camera

Supports 1080P HDMI output

Supports G-sensor screen rotation function

Supports built-in speaker and stereo earphone jack

Supports multiple languages

Can be used as a USB portable hard disk, driver not needed for

WIN2000 or above

3.5 Technical Specifications

Size

7.0” TFT capacitive touch panel LCD

display 160k color

LCD Display

Resolution

800x480

PC interface

High speed USB2.0 (FS)

Built-in Flash

Flash Memory: 4GB

Built-in RAM

RAM: DDRIII 512MB

Capacity Expansion

Support MicroSD Card, capacity 1GB~32GB

Built-in 3.7V@4000mAH Lithium rechargeable battery AC charger,

Input: AC110V~240V, Output: DC 5V@2A

Power Supply

Max. 6h video playing time（factory default）

Format

MP3, WMA, OGG, APE, FLAC, AAC, WAV

Headset max. output

（L）5mW＋（R）5mW（32Ohm）

MP3 Bit rate

8Kbps ~ 392 Kbps

WMA、WMV、Bit rate

5Kbps ~ 192 Kbps

Frequency response

20Hz to 20KHz

SN ratio

90dB

Music Function

Distortion

＜0.05%

Play format

MKV, AVI, RM, RMVB, MP4, MOV, VOB,

DAT, FLV, 3GP, etc

Max Resolution

1920x1080

Video Function

Ratio

4:3, 16:9, full screen for optional

Photo Browse

Support max. 8000x8000 JPG, JPEG, BMP, GIF

Format

TXT, LRC, PDF, Html, Htm, EPUB, etc

eBook Function

Max. capacity

Main chip set

802.11b/g/n

Transmission rate

Max108Mbps

WI-FI Function

Work Frequency

2.4GHz

Main chip set

IT6610 (Optional)

HDMI Function

Resolution

720P, 1080P

Camera Function

Support front web camera function

Recording function

Format

WAV

Working temperature

-5 -40 

Languages

English, French, German, Spanish, Simplified Chinese, Traditional

Chinese, etc

Operation systems

supported

Windows98SE/ME/2K/XP

4. Quick Guides

4.1 Switch On/Off

Switch ON and Unlock: When the device is in its OFF mode, press

and hold the Power key for 3 seconds to enterthe Android startup

process. The device will take about 100 seconds to enter the system

desktop, with the display in locked mode, please press and slide the

iconout of the white circle, the display will unlock automatically,

see the image below:

When the device is not in use, please put it into SLEEP mode, then

the device will be ready to use whenever you like, and you don’t

need to start the Android operating system again.

4.1.1 Power Saving Mode and Locked Mode:Pressing the

“POWER” key when the device is in use will result in the system

entering SLEEP power save and locked mode. Pressing the

POWER key will return the system to locked mode within 1 second.

Note: The primary operation of the device will not stop under the

power saving mode, it is just the display that is turned off and

showing a black screen. This means that music or movie playback

etc. will still continue to run.

4.4.2 Switch OFF: When the device is in use, press and hold the

POWER key for 3 seconds, the screen will display the power off

interface, choose the power off option to confirm your selection and

the system will shut down automatically.

Note: When the device is running low on battery power, it will sound

an alarm and then shut down automatically if it isn’t plugged intoa

power source to start charging. If the device cannot start up please

check if the battery power is too low by charging the device.

4.2Battery Management and Charging

4.2.1 Charge the battery about 8-12 hours to make sure the battery

is fully charged for the first time.

4.2.2 Insert the micro port of the battery adaptor into the DC slot on

the device, and connect the other side with the power socket. The

desktop icon of the battery will be rolling to show it is charging,

please wait until the battery is fully charged, don’t disconnect the

power when charging. Once the battery is fully charged the Icon on

the desktop will stop rolling. When the battery is exhausted

completely, please charge at least one minute before starting it up

Note:In order to keep the battery working to its full potential, please

pay attention to the following advice:

1) Don’t charge the power in excessively high temperatures.

2) There is no need to run down the power for this Li-ion battery, you

can charge the battery even when there is still power left in the

battery without it affecting the lifespan of the battery.

3) In order to keep the battery in good condition, Make sure you

charge it at least once every two weeks if the device hasn’t been

used for a long time.

4.3 Operation of the Function Icons

Definition of the Function Icons:

Icon

Function

instruction

Icon

Function instruction

Back to main menu

Notifications

Google Search

Voice Search

Menu Switch

App Menu

Browse All Menu

Google Search

Return

Home Page

Recent Browse

Function Menu

Reduce the volume

Increase the volume

Notifications

WiFi Status

Power Status

System Time

4.4 WI-FI Settings

4.4.1 Turn on WIFI: Tap the App Menu icon to enter into the

app menu list, tap “Settings” to enter into the setting interface, tap

“Wireless and networks” to setup, select the “WiFi”as below:

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tableta de E-matic

E-matic

E-matic FunTab Manual de usuario

E-matic

E-matic Genesis EGL26BL Manual de usuario

E-matic

E-matic Genesis Series-EGP007 Manual de usuario

E-matic

E-matic eGlide Steal Manual de usuario

E-matic

E-matic CinemaTab ETH103 Manual de usuario

E-matic

E-matic EXLB3B pro series Manual de usuario

E-matic

E-matic FunTab pro Manual de usuario

E-matic

E-matic WR762 Manual de usuario

E-matic

E-matic eGlide Pro X Manual de usuario

E-matic

E-matic eGlide Reader 2 Manual de usuario

E-matic

E-matic EWT132 Manual de usuario

E-matic

E-matic FunTab pro Instrucciones de montaje

E-matic

E-matic Pro Series - EGP008 Manual de usuario

E-matic

E-matic eGlide Reader 2.3 Manual de usuario

E-matic

E-matic EGQ223 Manual de usuario

E-matic

E-matic eGlide Pro III Manual de usuario

E-matic

E-matic eGlide Prism Manual de usuario

E-matic

E-matic Genesis Prime XL EGS102 Manual de usuario

E-matic

E-matic EGQ178 Manual de usuario

E-matic

E-matic PBDV704DVD Instrucciones de montaje

E-matic

E-matic Fun Tab 2 Manual de usuario

E-matic

E-matic EGM003 Manual de usuario

E-matic

E-matic eGlide Steal Manual de usuario

E-matic

E-matic 4 XL - EGLXL102B Manual de usuario

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje

E-matic eGlide Pro 2 Manual de usuario

Manuales populares de Tableta de otras marcas
