Description of four flying modes
V：v tail mode
1，The mixture function of ch1 and ch6 can be achieved by switch 1.
2，The range of servo for CH4 can be changed by tiny mix2
3，The function of CH1,CH2,CH4 small angel and large anglec an b e c hanged
by switch 3
4，There aret woi solateds witch c hannel C H5an dCH 6.An d col lapsable land ing
gear as wel l as photo-taking can be achieved by switch channe l 1 and 2
5，reverse switch for CH1,CH2,CH3,CH4 and CH6
6，lock and unlock function.W hen e very d ata i s s ettled, the s ituation c an b e
saved with lock function and every change wil l be no t accepted.
7，Alarm for low voltage:w hen v oltage o f b attery i s u nder8 .5V,the r ed L ED
wil l flash and when under 7.5V,LEC wil l close.
H：Helicopter mode
1，PIT and PLT can be adjusted by tiny mix 1 and 2
2，The function of CH1,CH2,CH4 small angel and large angle can be changed
by switch 3
3，There is a switch for the function of Gyro and can be switched between
norma l mode and head lock mode by switch 1
4，The switch 2 is settled for 3D diverted flight
5，reverse switch for CH1,CH2,CH3,CH4 and CH6
6，lock and unlock functionW. hen e very d ata is s ettled ,t he s ituation c an b e
saved with lock function and every change wil l be no t accepted.
7，Alarm for low voltage:w hen v oltage o f b attery i s u nder 8 .5V,the r ed L ED
wil l flash and when under 7.5V,LEC wil l close.
C：CCPM helicopter mode
1，The mixture function o f C H1,CH2,CH3 a nd C H6 c an b y a chieved f or C CPM
helicopter.PIT and PLT can be adjusted by tiny mix 1 and 2
2，The function of CH1,CH2,CH4s mall a ngel a nd l arge a ngle c an b e c hanged
by switch 3
3，There is a switch for the function o f Gyro and can be switched between
normal mode and head lock mode by switch 1
4,The switch 2 is settled for 3D diverted flight。
5，reverse switch for CH1,CH2,CH3,CH4 and CH6
6，lock and unlock functionW. hen e very d ata is s ettled ,t he s ituation c an b e
saved with lock function and every change will be not accepted.
7，Alarm for low voltagew: hen v oltage o f b attery is u nder 8 .5V,the r ed L ED
will flash and when under 7.5V,LEC will close.
ETC61-2.4GHz with four flying mode installed:A(aeroplane mode); V(V tail mode);C (CCPM h elicopter m ode);
H(helicopter mode) The swithc between each mode is very convenient. There is a reverse switch for Ch1,
CH2,CH4 and CH6 separately.The LCD on the transmitter can show voltage o f transmitter, chann el status,
flying mode and flying time.It has a function of auto-alarm for low voltage.
A：Aeroplane
1.The ranges of CH1,CH2 and CH4 of servos can be adjuste d b y Tin y mix 1
in order to adjus t for differen t aerobatics.
2.The function of CH1,CH2,CH4 small angel and large angle can be changed
by switch 3
3.The mixture function of ch1 and ch6 can be achieved by switch 2.
4.There is a isolated channe l fo r landin g ge ar a nd that func tion ca n be
achieved by switch 1
5.reverse switch for CH1,CH2,CH3,CH4 and CH6
6.lock and unlock function.W hen e very d ata i s s ettled , the s ituation c an b e
saved with lock function and every change wil l be no t accepted.
7.Alarm for low voltage:w hen v oltage o f b attery i s u nder 8 .5V,the r ed L ED
wil l flash and when under 7.5V,LEC wil l close.
C1: CCPM helicopter mode
Comparing C1 mode, C mode keeps all the operation function same as C mode
except Pitch's direction to the opposite, which takes much better compatibility
for CCPM helicoper.
