Mini Pulse XT
Assembly Manual
2
Introduction................................................................3
Specifications.............................................................3
Using the Manual .......................................................3
Contents of Kit/Parts Layout .........................................4
Required Radio Equipment...........................................5
Important Information About Motor Selection .................6
Sport Outrunner Setup.................................................6
Optional Accessories ..................................................6
Required Tools and Adhesives......................................6
Note Regarding Hinges...............................................7
Note on Lithium Polymer Batteries.................................7
Warning....................................................................7
Limited Warranty Period ..............................................8
Limited Warranty & Limits of Liability.............................8
Safety Precautions.......................................................9
Questions, Assistance, and Repairs...............................9
Questions or Assistance...............................................9
Inspection or Repairs...................................................9
Warranty Inspection and Repairs................................10
Table of Contents
Non-Warranty Repairs...............................................10
Safety, Precautions, and Warnings..............................11
Landing Gear Installation...........................................12
Outrunner Motor Installation.......................................14
Cowling Installation ..................................................15
Tail Installation..........................................................19
Wing Preparation .....................................................24
Final Assembly .........................................................26
Control Throws .........................................................30
Range Testing the Radio ............................................31
Center of Gravity......................................................31
Preflight ...................................................................32
Notes ......................................................................33
2006 Official AMA
National Model Aircraft Safety Code..........................34
3
Introduction
Thank you for purchasing the Mini Pulse XT. Designed
from the beginning for electric power, the Mini Pulse XT
is developed from the Hangar 9®Pulse™ XT with the
same flight characteristics as the 40-size version. It is a
perfect transitional airplane for beginners who want to
learn aerobatics and for sport flyers who want an easy,
comfortable sport flyer. All flight control surfaces, hinges,
and control horns have been installed at the factory to
help speed up the building time.
Specifications
Wingspan: 42.5 in (1080mm)
Length: 37.5 in (875mm)
Wing Area: 330 sq in (21.5 sq dm)
Weight w/o Battery: 21–22 oz (710–820 g)
Weight w/ Battery: 25–27 oz (795–965 g)
Using the Manual
This manual is divided into sections to help make assembly
easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed
next to each step to keep track of each step completed.
Steps with a single circle () are performed once, while
steps with two circles () indicate that the step will
require repeating, such as for a right or left wing panel,
two servos, etc.
Remember to take your time and follow the directions.
4
Contents of Kit/Parts Layout
Large Replacement Parts:
EFL2376 Wing w/Ailerons
EFL2377 Fuselage
EFL2378 Tail Set
EFL2380 Main Landing Gear
EFL2381 Cowling
EFL2382 Wheel Pants
Small Replacement Parts:
EFL2379 Pushrod Set
EFL2383 Motor X-Mount
EFLA200 Micro Control Horns
FLA203 Micro Control Connectors
EFLA219 Steerable Tailwheel Assembly
EFLA223 Foam Park Wheels, 2"
EFLA213 E-flite/JR/Horizon Decals
5
You will need a minimum 4-channel transmitter, crystals,
micro receiver, and four sub-micro servos. You can choose
to purchase a complete radio system that includes all of
these items or, if you are using an existing transmitter, just
purchase the other required equipment separately.
Complete Radio System
SPM2460 DX6 DSM 6CH Park Flyer w/4-S75
Servos
Note: We recommend the crystal-free,
interference-free Spektrum®DX6 2.4GHz DSM®
6-Channel System, which includes a micro
receiver and 4 sub-micro servos.
Or Purchase Separately
SPM6000 AR6000 DSM DualLink™ 6-Channel
Park Flyer Rx
Or
JSP30610 6-Channel UltraLite Rx w/o Crystal,
Positive Shift JR/AIR (72MHz)
Or
JSP30615 6-Channel UltraLite Rx w/o Crystal,
Negative Shift FUT/HRC (72MHz)
JRPXFR** FM Receiver Crystal
JSP98110 6" Servo Extension (2)
JSP98030 12" Servo Extension (2)
JSP98020 Y-harness, Standard 6"
EFLRS75 7.5-Gram Sub-Micro Servo (4)
Required Radio Equipment
6
Important Information About Motor
Selection
We recommend the E-flite®Park 450 Brushless Outrunner,
890Kv (EFLM1400) to provide you with excellent sport
and aerobatic power and a worry-free outrunner motor.
The Mini Pulse XT does not include a propeller, but we
recommend our 10X8 Electric Prop (EFLP1080E).
Sport Outrunner Setup
EFLM1400 Park 450 Brushless Outrunner
Motor, 890Kv
EFLA1025 25-Amp Pro Brushless ESC
THP21003SPL 2100mAh 3-Cell 11.1V Li-Po,
16GA
Or
EFLB1035 11.1V 2100mAh 3-Cell Li-Po,
16GA
EFLP1080E 10 x 8 Electric Prop
EFLAEC302 EC3 Battery Connector, Female (2)
EFLC3005 Celectra 1- to 3-cell Li-Po Charger
This is a sport flyer setup for smooth and stable flights.
Optional Accessories
EFLA110 Power Meter
Required Tools and Adhesives
Tools & Equipment
EFLA250 Park Flyer Tool Assortment, 5-piece
Or Purchase Separately
EFLA257 Screwdriver, #0 Phillips (or included
with EFLA250)
EFLA251 Hex Wrench: 3/32" (or included
with EFLA250)
Nut driver: 1/4"
Drill
Drill bit: 1/16" (1.5mm), 5/64" (2mm)
Masking tape
Card stock
Felt-tipped pen
Needle-nose pliers
Canopy glue
7
Note Regarding Hinges
For your convenience and to speed the assembly process,
the hinges have already been installed and glued. We
suggest that you take a minute before beginning assembly
of your model to check them.
Grasp the wing and aileron at each hinge location, then
gently pull on the aileron to ensure the hinges are secure
and cannot easily be pulled away from either surface.
Use caution when gripping the wing and aileron to avoid
crushing or damaging the structure. Repeat this process for
the elevator and rudder.
If, however, you find that the hinges pull away, simply
wick thin CA into the hinge slots and reinstall the
hinges/surfaces.
Note on Lithium Polymer Batteries
Lithium Polymer batteries are significantly
more volatile than alkaline or Ni-Cd/Ni-MH
batteries used in RC applications. All
manufacturer’s instructions and warnings
must be followed closely. Mishandling of
Li-Po batteries can result in fire. Always follow
the manufacturer’s instructions when disposing
of Lithium Polymer batteries.
Warning
An RC aircraft is not a toy! If misused, it can cause
serious bodily harm and damage to property. Fly
only in open areas, preferably at AMA (Academy of
Model Aeronautics) approved flying sites, following all
instructions included with your radio.
Keep loose items that can get entangled in the propeller
away from the prop, including loose clothing, or other
objects such as pencils and screwdrivers. Especially keep
your hands away from the propeller.
Limited Warranty Period
Horizon Hobby, Inc. guarantees this product to be free
from defects in both material and workmanship at the
date of purchase.
Limited Warranty & Limits of Liability
Pursuant to this Limited Warranty, Horizon Hobby, Inc.
will, at its option, (i) repair or (ii) replace, any product
determined by Horizon Hobby, Inc. to be defective. In the
event of a defect, these are your exclusive remedies.
This warranty does not cover cosmetic damage or damage
due to acts of God, accident, misuse, abuse, negligence,
commercial use, or modification of or to any part of
the product. This warranty does not cover damage due
to improper installation, operation, maintenance, or
attempted repair by anyone other than an authorized
Horizon Hobby, Inc. service center. This warranty is
limited to the original purchaser and is not transferable.
In no case shall Horizon Hobby’s liability exceed the
original cost of the purchased product and will not
cover consequential, incidental or collateral damage.
Horizon Hobby, Inc. reserves the right to inspect any and
all equipment involved in a warranty claim. Repair or
replacement decisions are at the sole discretion of Horizon
Hobby, Inc. Further, Horizon Hobby reserves the right to
change or modify this warranty without notice.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER. HORIZON HOBBY, INC. SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
As Horizon Hobby, Inc. has no control over use, setup,
final assembly, modification or misuse, no liability shall be
assumed nor accepted for any resulting damage or injury.
By the act of use, setup or assembly, the user accepts all
resulting liability.
If you as the purchaser or user are not prepared to accept
the liability associated with the use of this product, you
are advised to return this product immediately in new and
unused condition to the place of purchase.
8
Safety Precautions
This is a sophisticated hobby product and not a toy. It
must be operated with caution and common sense and
requires some basic mechanical ability. Failure to operate
this product in a safe and responsible manner could result
in injury or damage to the product or other property. This
product is not intended for use by children without direct
adult supervision.
The product manual contains instructions for safety,
operation and maintenance. It is essential to read and
follow all the instructions and warnings in the manual,
prior to assembly, setup or use, in order to operate
correctly and avoid damage or injury.
Questions,Assistance, and Repairs
Your local hobby store and/or place of purchase cannot
provide warranty support or repair. Once assembly, setup
or use of the product has been started, you must contact
Horizon Hobby, Inc. directly. This will enable Horizon to
better answer your questions and service you in the event
that you may need any assistance.
Questions or Assistance
For questions or assistance, please direct your email to
productsupport@horizonhobby.com, or call 877.504.0233
toll-free to speak to a service technician.
Inspection or Repairs
If your product needs to be inspected or repaired, please
call for a Return Merchandise Authorization (RMA). Pack
the product securely using a shipping carton. Please note
that original boxes may be included, but are not designed
to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and
insurance for lost or damaged parcels, as Horizon Hobby,
Inc. is not responsible for merchandise until it arrives and
is accepted at our facility. Include your complete name,
address, phone number where you can be reached during
business days, RMA number, and a brief summary of the
problem. Be sure your name, address, and RMA number
are clearly written on the shipping carton.
9
Warranty Inspection and Repairs
To receive warranty service, you must include your
original sales receipt verifying the proof-of-purchase
date. Providing warranty conditions have been met, your
product will be repaired or replaced free of charge.
Repair or replacement decisions are at the sole discretion
of Horizon Hobby.
Non-Warranty Repairs
Should your repair not be covered by warranty and the
expense exceeds 50% of the retail purchase cost, you will
be provided with an estimate advising you of your options.
You will be billed for any return freight for non-warranty
repairs. Please advise us of your preferred method of
payment. Horizon Hobby accepts money orders and
cashiers checks, as well as Visa, MasterCard, American
Express, and Discover cards. If you choose to pay by
credit card, please include your credit card number and
expiration date. Any repair left unpaid or unclaimed
after 90 days will be considered abandoned and will be
disposed of accordingly.
Electronics and engines requiring inspection or
repair should be shipped to the following address
(freight prepaid):
Horizon Service Center
4105 Fieldstone Road
Champaign, Illinois 61822
All other products requiring inspection or repair should be
shipped to the following address (freight prepaid):
Horizon Product Support
4105 Fieldstone Road
Champaign, Illinois 61822
10
Otros manuales para Mini Pulse XT
1
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Juguete de E-FLITE
E-FLITE
E-FLITE UMX AS3Xtra Manual de usuario
E-FLITE
E-FLITE SLICK 3D 480 Manual de usuario
E-FLITE
E-FLITE Apprentice S 15e Manual de usuario
E-FLITE
E-FLITE Fokker DVII 250 Slow Flyer ARF Manual de usuario
E-FLITE
E-FLITE Enticement F3P Manual de usuario
E-FLITE
E-FLITE Mini Pulse XT PNP Manual de usuario
E-FLITE
E-FLITE BAe Hawk 15 DF Manual de usuario
E-FLITE
E-FLITE EFLH2200 Manual de usuario
E-FLITE
E-FLITE G210 Manual de usuario
E-FLITE
E-FLITE J-3 Cub 450 Manual de usuario
E-FLITE
E-FLITE UMX Vapor Lite HP BNF Basic Manual de usuario
E-FLITE
E-FLITE Blade MCX Tandem Rescue Manual de usuario
E-FLITE
E-FLITE EDGE 540QQ 280 Manual de usuario
E-FLITE
E-FLITE Mystique EFL4905 Manual de usuario
E-FLITE
E-FLITE S.E.5a Slow Flyer ARF EFL1925 Manual de usuario
E-FLITE
E-FLITE Viper 70mm EDF Manual de usuario
E-FLITE
E-FLITE Blade 400 3D Manual de usuario
E-FLITE
E-FLITE 25-Size Float Set Manual de usuario
E-FLITE
E-FLITE Beechcraft Bonanza 15e ARF Manual de usuario
E-FLITE
E-FLITE Advance 25e ARF Manual de usuario
