Dynamic Engineering PMC-4U-CACI Manual de usuario
DYNAMIC ENGINEERING
435 Park Dr., Ben Lomond, Calif. 95005
831-336-8891 Fax 831-336-3840
www.dyneng.com
Est. 1988
User Manual
PMC-4U-CACI
Quad UART - Dual Synchronous
Serial Data Interface
PMC Module
Revision OR
Corresponding Hardware: Revision 01
Hardware and Software Design • Manufacturing Services
P a g e 2
PMC-4U
Quad UART - Dual Synchronous
Serial Data Interface
PMC Module
Dynamic Engineering
435 Park Drive
Ben Lomond, CA 95005
831-336-8891
831-336-3840 FAX
This document contains information of proprietary
interest to Dynamic Engineering. It has been supplied
in confidence and the recipient, by accepting this
material, agrees that the subject matter will not be
copied or reproduced, in whole or in part, nor its
contents revealed in any manner or to any person
except to meet the purpose for which it was delivered.
Dynamic Engineering has made every effort to ensure
t
hat this manual is accurate and complete. Still, the
company reserves the right to make improvements or
changes in the product described in this document at
any time and without notice. Furthermore, Dynamic
Engineering assumes no liability arising out of the
application or use of the device described herein.
The electronic equipment described herein generates,
uses, and can radiate radio frequency energy.
Operation of this equipment in a residential area is
likely to cause radio interference, in which case the
user, at his own expense, will be required to take
whatever measures may be required to correct the
interference.
Dynamic Engineering’s products are not authorized for
use as critical components in life support devices or
systems without the express written approval of the
president of Dynamic Engineering.
This product has been designed to operate with PMC
Module carriers and compatible user-provided
equipment. Connection of incompatible hardware is
likely to cause serious damage.
©2001 by Dynamic Engineering.
Trademarks and registered trademarks are
owned by their respective manufactures.
Manual Revision OR. Revised July 2, 2001.
Hardware and Software Design • Manufacturing Services
P a g e 3
Table of Contents
PRODUCT DESCRIPTION 6
THEORY OF OPERATION 9
ADDRESS MAP 10
PROGRAMMING 12
REGISTER DEFINITIONS 13
PMC4U_BASE 13
PMC4U_STAT 16
PMC4U_MSK 16
PMC4U_SCC_IVEC 17
PMC4U_DIR_TERM 17
PMC4U_SW_IN 18
PMC4U_SCC_A_CNTL 19
PMC4U_SCC_A_DATA 19
PMC4U_SCC_B_CNTL 19
PMC4U_SCC_B_DATA 19
PMC4U_UART_A 20
PMC4U_UART_B 20
PMC4U_UART_C 20
PMC4U_UART_D 20
PMC4U_IRUPT/PMC4U_IRUPT_CLR 21
Interrupts 22
Loop-back 23
PMC PCI PN1 INTERFACE PIN ASSIGNMENT 24
PMC PCI PN2 INTERFACE PIN ASSIGNMENT 25
PMC-4U FRONT PANEL IO PIN ASSIGNMENT 26
PMC PN4 USER INTERFACE PIN ASSIGNMENT 27
APPLICATIONS GUIDE 28
Hardware and Software Design • Manufacturing Services
P a g e 4
Interfacing 28
CONSTRUCTION AND RELIABILITY 29
THERMAL CONSIDERATIONS 29
WARRANTY AND REPAIR 30
SERVICE POLICY 31
OUT OF WARRANTY REPAIRS 31
FOR SERVICE CONTACT: 31
SPECIFICATIONS 32
ORDER INFORMATION 33
SCHEMATICS 33
Hardware and Software Design • Manufacturing Services
P a g e 5
List of Figures
FIGURE 1 PMC-4U BLOCK DIAGRAM 6
FIGURE 2 PMC-4U INTERNAL ADDRESS MAP 10
FIGURE 3 PMC-4U UART ADDRESS MAP 11
FIGURE 4 PMC-4U BASE CONTROL REGISTER BIT MAP 13
FIGURE 5 PMC-4U TX CONTROL REGISTER BIT MAP 16
FIGURE 6 PMC-4U INTERRUPT MASK REGISTER BIT MAP 16
FIGURE 7 PMC-4U DIRECTION TERMINATION CONTROL BIT MAP 17
FIGURE 8 PMC-4U SWITCH READ BIT MAP 18
FIGURE 9 PMC-4U INTERRUPT STATUS/CLEAR 21
FIGURE 10 PMC-4U PN1 INTERFACE 24
FIGURE 11 PMC-4U PN2 INTERFACE 25
FIGURE 12 PMC-4U FRONT PANEL INTERFACE 26
FIGURE 13 PMC-4U PN4 INTERFACE 27
Hardware and Software Design • Manufacturing Services
P a g e 6
Product Description
PMC-4U-CACI is part of the PMC Module family of modular I/O components
by Dynamic Engineering. The PMC-4U is capable of providing multiple serial
protocols both synchronous and asynchronous with a wide range of baud
rates. The CACI interface uses an RS-423 driver, an RS-422 driver, and
an RS-422 receiver for each UART channel. Two enhanced hysteresis MIL
STD 188-114A receivers, a MIL STD 188-114A driver, and an open drain
active low output driver for one synchronous channel and an RS-422 driver
and receiver for the other synchronous channel.
Other variations are possible. Different oscillators can be installed, or
other modifications can be made to accommodate your particular
requirements. That variation will then be offered as a “standard” special
order product. Please see our web page for current products offered and
contact Dynamic Engineering with your custom application.
FIGURE 1 PMC-4U BLOCK DIAGRAM
+5V
Xilinx
XCS40XL
Quad
UART
XR16C854
SCC
Z85X30
2 channels
PCI Bus 33/32
Osc
Dip Switch
Osc
Osc
DATA
CONTROL
2
1V HYSTERISIS
± 5V
8
8
±12V, ±6V selectable
16
+5V
GND
switched
termination
RS232
RS423
RS188
RS485
RS422
2
Hardware and Software Design • Manufacturing Services
P a g e 7
An EXAR XR16C854 implements the UART interface. This quad UART
device is compatible with the industry standard 16550 UART, but is
equipped with 128 byte FIFOs, independent Tx and Rx FIFO counters,
automatic hardware/software flow control, and many other enhanced
features. An 18.432 MHz oscillator supplies the reference clock for this
device allowing baud rates up to 1.152 Mbps.
The synchronous interface uses a Zilog Serial Communication Controller,
the Z85C30. This dual channel, multi-protocol device can implement
various bit-oriented and byte-oriented synchronous protocols such as HDLC
and IBM Bisync and handles asynchronous formats as well.
The PMC-4U also has a wide range of IO drivers and receivers to interface
with these two devices. There are 16 differential RS422/485
transceivers that can be configured as either receivers or transmitters,
eight single-ended RS188/232/423 drivers operating at selectable
voltage levels, and eight single-ended receivers capable of up to +/- 25V
input range. There are also two enhanced hysteresis (~1.5V) RS423
receivers for handling noisy input signals and two open drain outputs that
sink up to 65 mA. The differential input signals are selectively terminated
with switched 150Ωterminations. All IO lines have series 33Ωresistors
for circuit protection.
The UART, SCC, and IO lines all interface through the Xilinx FPGA to allow
maximum flexibility of connections. All configuration registers internal to
the Xilinx support read and write operations for software convenience. All
addresses are long word aligned including the UART and SCC internal
registers even though they have only a byte-wide data interface. Please see
the XR16C854 and Z85C30 data sheets and user’s manuals for more
information on register access and functions.
The PMC-4U conforms to the PMC and CMC draft standards. This
guarantees compatibility with multiple PMC Carrier boards. Because the
PMC may be mounted on different form factors, while maintaining plug and
software compatibility, system prototyping may be done on one PMC
Carrier board, with final system implementation on a different one.
PMC-4U uses a 10 mm inter-board spacing for the front panel, standoffs,
and PMC connectors. The 10 mm height is the "standard" height and will
work in most systems with most carriers. If your carrier has non-standard
connectors [height] to mate with the PMC-4U, please let us know. We may
be able to do a special build with a different height connector to
compensate.
Interrupts are supported by the PMC-4U. Each of the four UARTs and the
SCC has a maskable input to the interrupt generation logic in the Xilinx.
Hardware and Software Design • Manufacturing Services
P a g e 8
There is also a master interrupt enable that can be set to gate the
interrupt onto the PCI bus. The interrupt status is still available in a status
register even when the master interrupt enable is off. This facilitates polled
operation of interrupt conditions. The individual interrupt conditions are
specified in the internal registers of the UART and SCC. Please see the
XR16C854 and Z85C30 documentation for more information on interrupt
conditions and configuration.
Hardware and Software Design • Manufacturing Services
P a g e 9
Theory of Operation
The PMC-4U is designed for transferring data from one point to another
with a variety of serial protocols.
The PMC-4U features a Xilinx FPGA. The FPGA contains the general control
and status registers as well as the interface to the quad UART, SCC, and
IO drivers and receivers. Many additional control and status registers
reside in the UART and SCC, which are accessed through the Xilinx
interface.
The PMC-4U is a part of the PMC Module family of modular I/O products.
It meets the PMC and CMC draft Standards. Contact Dynamic Engineering
for a copy of this specification. It is assumed that the reader is at least
casually familiar with this document and logic design. In standard
configuration, the PMC-4U is a Type 1 mechanical with no components on
the back of the board and one slot wide, with 10 mm inter-board height.
The PCI interface to the host CPU is controlled by a logic block within the
Xilinx. The PMC-4U design requires one wait state for read or write cycles
to addresses other than the SCC and UART which require from three for
simple read or write operations to nine for the SCC interrupt
acknowledge/vector read cycle. The wait states refer to the number of
clocks after the PCI core decode before the “terminate with data” state is
reached. Two additional clock periods account for the 1 clock delay to
decode the signals from the PCI bus and to convert the terminate with data
state into the TRDY signal.
The quad UART and dual Serial Communication Controller can handle
multiple asynchronous and synchronous protocols and the IO drivers and
receivers support a range of electrical interface standards.
Each of the serial interfaces has its own oscillator and on-board baud rate
generator to supply a wide range of clock reference frequencies. The SCC
can also operate from external clock sources with separate Rx clock input
and Tx clock input/output pins for each channel.
Please refer to the XR16C854 and Z85C30 documentation for more
information on the operation and capabilities of these devices.
Hardware and Software Design • Manufacturing Services
P a g e 10
Address Map
REGISTER OFFSET FUNCTION TYPE
PMC4U_BASE 0X00 base control read/write
PMC4U_STAT 0X04 status read read
PMC4U_MSK 0X08 interrupt mask control read/write
PMC4U_SCC_IVEC 0X0C SCC interrupt vector read read
PMC4U_DIR_TERM 0X10 direction and termination control read/write
PMC4U_SW_IN 0X14 read user switch read
PMC4U_SCC_A_CNTL 0X18 SCC channel A control read/write
PMC4U_SCC_A_DATA 0X1C SCC channel A data read/write
PMC4U_SCC_B_CNTL 0X20 SCC channel B control read/write
PMC4U_SCC_B_DATA 0X24 SCC channel B data read/write
PMC4U_UART_A 0X40 UART A base offset read/write
PMC4U_UART_B 0X60 UART B base offset read/write
PMC4U_UART_C 0X80 UART C base offset read/write
PMC4U_UART_D 0XA0 UART D base offset read/write
PMC4U_IRUPT 0XE0 interrupt source read read
PMC4U_IRUPT_CLR 0XE0 interrupt write clear write
FIGURE 2 PMC-4U INTERNAL ADDRESS MAP
Each UART channel has a number of registers associated with it. These
register offsets and their general functions are given in figure 3. For
details of the bits and functions of each register consult the documentation
for the XR16C854.
The SCC also has a number of internal registers that are accessed in a
two-step process. First the register number is written to the control
address for the respective channel. Then an additional read or write to the
same control address is performed. This causes the data to be read from
or written to the desired register. At the end of this process the register
pointer is reset so that the next access is again to/from the base control
register. For a more complete description of this process, as well as
details of registers and their functions, see the user’s manual for the
Z85C30.
The address map provided is for the local decoding performed within the
PMC-4U. The addresses are all offsets from a base address. The carrier
board that the PMC is installed into provides the base address.
The VendorId = 0x10EE. The CardId = 0x0007. Current revision = 0x00
Tabla de contenidos
Otros manuales de Equipo de grabación de Dynamic Engineering
Manuales populares de Equipo de grabación de otras marcas
Strymon
Strymon NIGHTSKY Manual de usuario
Mitsubishi Electric
Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manual de usuario
Tews Technologies
Tews Technologies TPMC465 Manual de usuario
Honeywell
Honeywell Excel 50 Manual de usuario
SeaLevel
SeaLevel COMM+8.LPCI Manual de usuario
Arturia
Arturia AUDIOFUSE STUDIO Manual de usuario
