Duronic DH06 Manual de usuario
DH06
Dehumidier
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE
2
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
Instrukcja obsługi. Polski
Türkçe Kullanım Kılavuzu
Gebruikershandleiding Nederlands
Svensk manual
3
10
17
24
31
38
45
52
59
Contents
3
English Manual
4
Features and Specications
Components
1
4
7
8
5
6
2
3
1. Top air vent
2. Main unit
3. Water gauge
4. Power switch
5. Power adapter port
6. Power adapter
7. Back air vent
8. Water tank
Size Noise Level Weight Cable Power Voltage
21.5x14.5x14.5cm
8.5x5.7x5.7in 32dB(A) 1kg 180cm
71in 18W 220-240V
50-60Hz
Dehumidifying
Performance
Water
Tank
Capacity
Suitable for
Room size
Air Flow
Rate
Refrigerant
Type
Energy
Consumption
Operating
Range
0.24L/24 hours 0.8L 5-10m211.5m3/h Peltier 23W 0-40°C
5
PLEASE READ THIS MANUAL CAREFULLY AND RETAIN FOR FUTURE
REFERENCE
• This appliance is for indoor/household use only. Do not use outdoors.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be closely supervised at all times to ensure that they do not
play with the appliance.
• Never try to replace the parts and repair the unit by yourself.
• Never open and repair the machine yourself. Do not modify the machine
in any way that is not described in the instructions for use. The machine
contains live parts. Repairs may only be carried out by Duronic, using original
spare parts and accessories.
• Always operate the appliance on a dry, smooth, even and stable surface. Do
not place the unit on a hot surface.
• Disconnect the mains plug from the power socket if you are going to be
absent for long periods.
• Make sure that the appliance and its mains cable are not located close to hot
surfaces.
• To reduce the risk of electric shock, never operate this product near water,
with wet hands, spill liquid on the appliance or submerge it in water or any
other liquid.
• Do not use the dehumidier near gas or other inammable materials (such as
benzene, paint thinner, sprays, etc.)
Safety Information
Do not operate this appliance if the power cable or plug is damaged.
If either is damaged, return it to Duronic for service or repair by
professional technician.
6
• Do not place the appliance on or near a hot gas or on a heated oven.
• Do not put any extension leads or portable power supplies near or behind the
appliance.
• Do not use any accessories which are not recommended by Duronic.
• Do not insert any foreign or electrical objects into the appliance.
• Do not store explosive substances such as aerosol cans with a ammable
propellant in or next to this appliance.
• There may be trace of odour during the rst few minutes of initial use. This is
normal and will quickly disappear.
• Do not place the appliance against furniture, upholstery, a wall, or other
appliances.
• Do not cover the appliance or restrict the air ow of the inlet or exhaust vents
whilst in use.
• Do not cover, obstruct or push objects into the vents and opening of the
appliance as this may cause an electric shock, re or damage the appliance.
• Do not operate the appliance with wet hands.
• Do not use this appliance near water or in the immediate surroundings of a
bath, shower or a swimming pool. Never place the appliance where it may fall
into a bathtub or other water container.
• Do not allow water or other liquids to run into the interior of the appliance, as
this could create a re and/or electrical hazard.
• Do not use mechanical devices to accelerate the appliances defrosting
process. Do not operate the appliance with the water tank removed.
Safety Information (Continued)
7
Introduction
Before First Use
Cleaning and Maintenance
The DH06 is a compact dehumidier suitable for use in and around the home. It
can collect up to 240ml per day and has a water tank can hold up to 800ml.
The overow protection feature protects the appliance from overlling itself; so
when the water tank is full, the machine will stop collecting water and switch itself
off.
It’s highly energy-efcient and effective at preventing and removing damp and
mould. It is suitable for use all around the home from the bedroom to the kitchen,
as well in other areas prone to damp too such as caravans, garages, utility rooms
and more.
1. Before rst use, remove all packaging and set aside.
2. Using a dry cloth, wipe clean the main unit and water tank.
3. Place the dehumidier on a at, dry surface and located close to an electrical
mains socket.
• Before cleaning, switch off and unplug the machine. Remove any water from
the tank.
• Clean the water tank with warm tap water and mild detergent (e.g. washing
up liquid). Note: Do not use boiling water to clean the water tank.
• Ensure to remove any scale or deposits that have formed inside the water
tank.
• Dry the outside of the water tank.
• Wipe all surfaces dry before placing the water tank back into the appliance.
If you do not plan on using the dehumidier for a long period of time, allow the
tank to air dry both inside and outside before storing it away.
8
How to Use
1. Plug the power cable into the mains socket and switch on.
2. Slide the water tank into the dehumidier, ensuring it has clicked rmly into
place.
3. To turn on the dehumidier, press the power button. The appliance will beep
once.
4. To turn off the dehumidier, press the power button again.
Overow Protection:
1. When the water tank is full, the dehumidier will automatically turn off.
2. Empty and replace the water tank according to the instructions below.
3. Restart the dehumidier and use as normal.
Emptying the Water Tank:
1. Press the power button to turn off the dehumidier and leave it to stand for a
1-2 minutes to allow the nal drips of water to drop into the tank.
2. Pull out the water tank from the back of the appliance.
3. Empty the water from the tank.
4. Dry the tank with a cloth and then place it back into the dehumidier. Ensure
that it is pushed properly in place, it should click into place securely.
When not in use, always empty the water tank, clean and dry the
dehumidier to prevent mould build up.
9
Troubleshooting
Problem Probable Cause Solution
The dehumidier
is not collecting
water or does not
work.
The doors or windows
in the room where the
appliance is in use are
open.
Close all windows and doors.
The air vents are blocked. Close all windows and doors.
Remove any blockages.
The humidity in the room
is increasing.
Turn off any appliances that may be
creating steam.
The temperature is too
low.
Ensure the temperature indoors is not
lower than 8°C/47°F.
The water tank is full. Empty the tank.
The dehumidier
is not turning on.
The power has been cut
off.
Check to ensure the power adapter is
correctly connected and the wall socket
is plugged in and turned on.
The water tank is in the
wrong position.
Remove and replace the water tank,
positioning it correctly.
Water is leaking. The unit is not placed on
a at stable surface.
Place the unit on a at and stable
surface.
Outlet air is warm. Heat exchanging process. This is normal.
Water noise. Refrigerating uid is
owing. This is normal.
