DUROMAX DS5500EH Manual de usuario

DS5500EH GENERATOR

This manual provides information regarding the operation

and maintenance of these products. We have made every

effort to ensure the accuracy of the information in this

manual. We reserve the right to change this product at

any time without prior notice.

5800 Ontario Mills Pkwy

Ontario, CA 91764 USA

www.DuroMaxpower.com

Call our Customer Care Team Toll Free 8-5pm PST Mon-Fri

844-DuroMax

User Manual

*Gasoline & Propane Tank Not Included

REV:DS5500EH-05232018

CONTENTS

Introduction .................................................................................................................... 6

General Safety Procedures ........................................................................................... 7

Quick Start Guide (Gasoline) ....................................................................................... 10

Quick Start Guide (Propane)........................................................................................ 12

Generator Components............................................................................................... 14

Package Contents ......................................................................................................... 16

Introduction

Checking the Oil ........................................................................................................... 24

Check the Gas Level ..................................................................................................... 25

Starting the Generator Using Gasoline ...................................................................... 26

Starting the Generator Using Propane....................................................................... 28

Starting the Generator

Shipping Braces ............................................................................................................ 18

Wheel Kit Installation.................................................................................................... 19

Adding Oil ...................................................................................................................... 20

Adding Gasoline ............................................................................................................ 21

Grounding the Generator ........................................................................................... 22

High Altitude Operation .............................................................................................. 22

Generator Setup

AC Usage ........................................................................................................................ 32

Connecting a Load to the Generator.......................................................................... 34

Voltage Selector Switch ................................................................................................ 35

DC Usage........................................................................................................................ 36

Using the Generator

CONTENTS

Maintenance Schedule.................................................................................................. 40

Maintenance Log ........................................................................................................... 41

Checking the Oil ............................................................................................................ 42

Changing the Oil............................................................................................................. 43

Cleaning the Air Cleaner ............................................................................................... 44

Spark Plug Maintenance ............................................................................................... 46

Emptying the Gas Tank ................................................................................................. 48

Cleaning the Fuel Filter Cup.......................................................................................... 50

Storage and Transportation ......................................................................................... 51

Specications.................................................................................................................. 52

.......................................................................................................................... 62

Basic Troubleshooting .................................................................................................. 54

Changing / Inspecting the Carbon Brushes ............................................................... 55

Changing / Inspecting the AVR .................................................................................... 57

Wiring Diagram ............................................................................................................. 60

Maintenance and Care

Warranty

Troubleshooting

8. .................................................................................................. 66

Contact Information

INTRODUCTION

Notice Regarding Emissions

DuroStar has cemented its reputation as one of the markets leading power equipment companies

who are headquartered in the US. All of our products are manufactured to the strictest guidelines

and go through countless testing in all phases of production.

Evolving our strong engine line, DuroStar has complemented its oerings to include Pressure

Washers, Water Pumps, Engines and now oering V-Twin engines. Reliability is the highest

standard we hold ourselves to, whether its powering a heater during a winter storm that knocks

out power, dewatering a ooded property, or washing away a deck for the summer season

Engines that are certied to comply with U.S. EPA emission regulations for SORE (Small o Road

Equipment), are certied to operate on regular unleaded gasoline, and may include the following

emission control systems: (EM) Engine Modications and (TWC) Three-Way Catalyst (if so equipped).

STOP

Please do not return

to store.

Durostar representatives are ready to help you

with any questions, concerns, or issues about your

new product. We can guide you through assembly,

start up, and how to operate your new generator.

We want you to be able to put your new generator

to use right away!

CALL US BEFORE YOU CONSIDER

RETURNING THE PRODUCT!

1-844-DUROMAX

TOLL FREE

SAFETY ALERT SYMBOL

DANGER: This generator produces poisonous carbon monoxide gas when running. This

gas is both odorless and colorless. Even if you do not see or smell gas, carbon monoxide

may still be present. Breathing this poison can lead to headaches, dizziness, drowsiness,

and eventually death.

●Use outdoors ONLY in non-conned areas.

●Keep several feet of clearance on all sides to allow proper ventilation of the generator.

WARNING: The exhaust from this product contains chemicals known to the State of

California to cause cancer, birth defects, or other reproductive harm.

WARNING: This generator produces heat when running. Temperatures near exhaust can

exceed 150°F (65°C).

●Do not touch hot surfaces. Pay attention to warning labels on the generator denoting

hot parts of the machine.

●Allow generator to cool several minutes after use before touching engine or areas

which heat during use.

The safety alert symbol is used with one of the safety words (DANGER,

CAUTION, or WARNING) to alert you of hazards. Please pay attention to

these hazard notices both in this manual and on the generator.

GENERAL SAFETY PROCEDURES

Please familiarize yourself with the following safety symbols and words:

●DANGER: Indicates a hazard that will result in serious injury or death if instructions are not

followed.

●WARNING: Indicates a strong possibility of causing serious injury or death if instructions are not

followed.

●CAUTION: Indicates a possibility of personal injury or equipment damage if instructions are not

followed.

WARNING: This generator may emit highly ammable and explosive gasoline vapors,

which can cause severe burns or even death. A nearby open ame can lead to an

explosion even if not directly in contact with gas.

●Do not operate near an open ame.

●Do not smoke near generator.

●Always operate on a rm, level surface.

●Always turn generator o before refueling.

●Allow generator to cool for at least 2 minutes before removing fuel cap. Loosen cap

slowly to relieve pressure in tank.

●Do not overll gas tank. Gas may expand during operation. Do not ll to the top of

the tank.

●Always check for spilled gas before operating.

●Empty the gasoline tank before storing or transporting the generator.

●Before transporting, turn fuel valve to the o position and disconnect the spark plug.

WARNING: This generator produces a powerful voltage, which can result in electrocution.

●ALWAYS ground the generator before using it (see the “Grounding the Generator”

portion of the “PREPARlNG THE GENERATOR FOR USE section).

●Generator should only be plugged into electrical devices, either directly or with an

extension cord. NEVER connect to a building electrical system without a qualied

electrician. Such connections must comply with local electrical laws and codes. Failure

to comply can create a backow of power, which may result in serious injury or death

to utility workers.

●Use a ground fault circuit interrupter (GFCI) in highly conductive areas such as metal

decking or steel work. GFCls are available in-line with some extension cords.

●Do not use uncovered in rainy or wet conditions.

●Do not touch bare wires or receptacles (outlets).

●Do not allow children or non-qualied persons to operate.

GENERAL SAFETY PROCEDURES

In addition to the above safety notices, please familiarize yourself with the safety and

hazard markings on the generator.

GENERAL SAFETY PROCEDURES

QUICK START GUIDE (GASOLINE)

Remove shipping braces

The shipping braces prevent engine movement during

shipment. Flip the generator over and remove the brightly

colored brace between the motor and the frame, and the

wood brace under the generator.

Add gasoline

The fuel cap is located on top of the fuel tank. Fill the tank

with fresh unleaded gasoline 87 octane or higher. The tank

is full when you see fuel in the bottom of the fuel lter cup.

DO NOT overll the tank.

Turn gas valve on

The gas valve is located above the recoil start on the

bottom of the fuel tank. Rotate the valve clockwise to the

vertical position to turn on the gas supply.

Add oil

The oil ll cap is located on the lower engine block to the

right of the recoil start housing. Remove the oil ll cap and

ll with 10w30 oil.

Turn breaker o

The breaker is located on the right side of the front power

panel. Flip the breaker down to prevent accidental load

when starting the generator.
