H867

Additional Instructions

Tilting support

Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,

including extracts, is prohibited without the prior written approval of Dürkopp Adler AG.

IMPORTANT

READ CAREFULLY BEFORE USE

KEEP FOR FUTURE REFERENCE

Table of Contents

Additional Instructions H867 - 00.0 - 03/2015 1

1 Components of the parts set.....................................................3

2 Function of the parts set............................................................4

3 Installing the parts set ...............................................................6

Table of Contents

2Additional Instructions H867 - 00.0 - 03/2015

Components of the parts set

Additional Instructions H867 - 00.0 - 03/2015 3

1 Components of the parts set

Check whether the scope of delivery for parts set 0867 142224 is correct

prior to installing the tilting support.

Part number Quantity Description

9202 002887 3 Screw M6x12

9351 000087 4 Adjusting ring

0867 142200 2 Ring

0867 142260 2 Bolt

0867 142190 1 Holder

0867 142240 1 Lever

9706 000314 1 Gas spring

9202 003317 4 Screw M8x25

0867 142173 1 Holder

0867 142250 2 Bolt

0867 142210 1 Lever

Function of the parts set

4Additional Instructions H867 - 00.0 - 03/2015

2 Function of the parts set

The tilting support is designed to allow for easier tilting of the machine

head. It also increases safety for the user while tilting back the machine.

Position 1 - machine in working position

In this position, the gas spring mechanism acts on the base plate. This

effect makes it easier to tilt the machine head back into the service

position.

Fig. 1: Position 1

CAUTION

Risk of crushing due to the weight of the

machine!

The machine should only be tilted by qualified

technicians.

Function of the parts set

Additional Instructions H867 - 00.0 - 03/2015 5

Position 2 - machine in idle position

The machine head is slowed down by the lever when being tilted back.

This deceleration prevents an uncontrolled tilting motion and stops the

machineheadfromcollidingwiththebaseplateonaccountofthemachine

head's own weight. This feature prevents damage to the machine as well

as injury to the user.

Tilting the machine head all the way into the service position requires that

the machine be tilted backwards by applying active force.

Fig. 2: Position 2

Position 3 - machine in service position

In this position, the machine head is tilted back all the way. The parts set

of the tilting support will also act as a limit stop in this position. This stops

the machine head from slipping out of the hinges and, consequently, the

table top.

Fig. 3: Position 3

Installing the parts set

6Additional Instructions H867 - 00.0 - 03/2015

3 Installing the parts set

Fig. 4: Installation I

Handling step

1. Loosen the adjusting screws (1).

2. Pull out the bolt (2) on the lever (3).

Fig. 5: Installation II

Handling step

1. Set the machine to the working position.

2. Screw the holder (5) into the table top using the screws (4).

3. Screw the holder (6) into the base plate using the screws (7).

WARNING

Risk of crushing due to the weight of the machine!

Secure the machine against tipping during installation.

Installation of the tilting support by qualified techni-

cians ONLY!

Switch off the machine prior to installation.

(1) - Adjusting screws

(2) - Bolt (3) - Lever

①②

③

(4) - Screws

(5) - Holder (6) - Holder

(7) - Screws

④

⑤

⑥

⑦

⑥

Installing the parts set

Additional Instructions H867 - 00.0 - 03/2015 7

Fig. 6: Installation III

Handling step

1. Tilt the machine head back into the service position.

2. Use the bolt (2) to connect the lever (3), the spacer ring (8) and the

eye of the gas spring (10).

3. Fit the adjusting ring (9) onto the bolt (2) and tighten until there is no

more axial play.

4. Tighten the adjusting screw (1).

Fig. 7: Installation IV

Handling step

1. Tilt the machine back into the working position.

2. Use the bolt (14) to connect the lever (3) and the connecting rod (13).

3. Fit the adjusting ring (11) onto the bolt (14) and tighten until there is

no more axial play.

4. Tighten the adjusting screw (12).

(1) - Adjusting screw

(2) - Bolt

(3) - Lever

(8) - Spacer ring

(9) - Adjusting ring

(10) - Gas spring

③

⑧

⑨①

②

⑩

(3) - Lever

(11) - Adjusting ring

(12) - Adjusting screw

(13) - Connecting rod

(14) - Bolt

⑪

⑫

③

⑬

⑭

Installing the parts set

8Additional Instructions H867 - 00.0 - 03/2015
