Dual XDM6830 Instrucciones de funcionamiento

INSTALLATION/OWNER’S MANUAL

AM/FM/CD/MP3/WMA Receiver with Detach Face

XDM6830

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

Please read entire manual before installation.

Before You Start

• Disconnect negative battery terminal. Consult a qualified technician for instructions.

• Avoid installing the unit where it would be subject to high temperatures, such as from

direct sunlight, or where it would be subject to dust, dirt or excessive vibration.

Getting Started

• Remove trim ring from unit,

• Remove 2 transit screws located

on top of the unit.

• Insert the supplied keys into the

slots as shown, and slide the unit

out of the mounting sleeve.

• Install mounting sleeve into

opening, bending tabs to secure.

• Connect wiring harness and

antenna. Consult a qualified

technician if you are unsure.

• Certain vehicles may require an

installation kit and/or wiring

harness adapter (sold separately).

• Test for correct operation and slide

into mounting sleeve to secure.

• Snap trim ring into place.

• Mount the iplug™ adapter to any

smooth clean surface using the

supplied double-sided tape or #2 x

3/8” Phillips head screws.

XDM6830 INSTALLATION

Preparation

SECURITY

LED

RESET

BUTTON

FUSE

When replacing the fuse,

make sure new fuse is the

correct type and amperage.

Using an incorrect fuse

could damage the radio.

The XDM6830 uses one

10 amp ATM fuse located

beside the wiring connector.

XDM6830 INSTALLATION

Wiring Diagram

Tune/Track Down

Eject

Volume/Audio/Setup

AS/PS/Enter

Tune/Track Up

Infrared Sensor

Display/*Key #0

Preset #5/Folder Up

EQ/*Key #9

Preset #4/Folder Down

Tuner Scan/*Key #8

Preset #3/Intro

*Key #7

Preset #2/Random

Preset #6

Preset #1/Repeat

Mode/Search

Mute

Power

Band/Play/Pause

19 18 15

1 2 56

*Function keys 7, 8, 9 and 0 apply to MP3/WMA operation only.

XDM6830 OPERATION

Control Locations - Receiver

71112 89101314

XDM6830 OPERATION

Control Locations - Remote

EQ/*Key #9

Tuner Scan/*Key #8

*Key #7

Preset #5/Folder Up

Preset #4/Folder Down

Preset #1/Repeat

Mode/Search

Tune/Track Down

Band/Play/Pause

Power

Volume Up

AS/PS/Enter

Audio/Setup

Tune/Track Up

Display/*Key #0

Volume Down

Preset #3/Intro

Preset #2/Random

Preset #6

Press EJECT to allow the front panel to slide down. Gently

squeeze the release tab located on the bottom center

underside and pull front panel down and away from unit to

remove. To install, insert either side first, then push opposite

side to secure.

Press EJECT to allow the front panel to slide down. Install

supplied #2 x 5 mm Phillips head screws from underside of

the mounting frame into faceplate.

Press PWR or any other button (except EJECT) to turn the unit

on. Inserting a disc will turn the unit on automatically. Press

PWR to turn the unit off.

Press MODE to select between tuner, CD player and auxiliary

input. Modes of operation are indicated in the display.

Adjust volume using rotary encoder (00-46).

Press MUTE to silence the audio. “MUTE” will flash in the

display. Press MUTE again to cancel.

Press and hold PWR for 3 seconds to program currently

selected volume level. "P-VOL" and the current volume level

will momentarily appear in the display.

Press EQ to select between POP, JAZZ, CLASSIC, BEAT,

ROCK and OFF (default) equalization curves. Any adjustment

to the Bass or Treble settings automatically cancels the

current EQ curve (if one is selected).

Press DISP to select between clock and radio frequency

(tuner mode), clock and CD track/elapsed time (CD mode), or

clock and AUX (AUX mode).

With the unit on, press and hold DISP until the clock begins to

flash, then release. Press TUNE

to adjust the hours and

TUNE

to adjust the minutes. Press DISP momentarily to

save the selected time.

The clock will display 12-hour AM/PM time in USA frequency

spacing mode (PM 10:00). In European frequency spacing

mode, the clock will display 24-hour time (22:00).

Front Panel Removal

Semi-permanent

Faceplate Installation

Power On/Off

Mode

Volume

Mute

Programmable

Turn-On Volume

Preset EQ Curves

Display

Set the Clock

12/24-hour Clock

XDM6830 OPERATION

General Operation

XDM6830 OPERATION

General Operation - Setup Menu

Menu Function Options Action

Loudness Curve LOUD OFF Disables the loudness function.

LOUD ON Enables the loudness function. Activating

this feature will enhance the bass and treble

frequencies when listening to music at low

volumes.

Clock Display

Priority

FUNC PRI Radio frequency (tuner mode), CD elapsed time/

track or MP3/WMA file information (CD mode) or

AUX (AUX mode) will be displayed by default. Clock

is accessed by pressing DISP momentarily.

CLK PRI Clock will be displayed by default. Radio frequency

(tuner mode), CD elapsed time/track or MP3/WMA

file information (CD mode) is accessed by pressing

DISP momentarily.

Tuner Frequency

Spacing

FREQ USA Programs the unit to USA tuner spacing.

(200kHz for FM and 10kHz for AM)

FREQ EUR Programs the unit to European tuner spacing.

(50kHz for FM and 9kHz for AM)

Clock Display CLK OFF Programs the unit to not display the clock when the

power is off.

CLK ON Programs the unit to display the clock when the

power is off.

Auxiliary Mode AUX ON Enables access to auxiliary mode.

AUX OFF Disables access to auxiliary mode.

Beep

Confirmation

BEEP OFF Disables the confirmation beep.

BEEP ON Enables the confirmation beep.

Local/Distance

Tuning

LOC OFF Activates Distance tuning.

LOC ON Activates Local tuning for strong station reception

only.

Power on

Message

MSG ON Enables power on message to be displayed.

MSG OFF Disables power on message.

Setup Menu Press and hold the rotary encoder for more than 3 seconds

to access the setup menu. Press the rotary encoder

momentarily to select between the menu functions and

rotate the rotary encoder left/right to adjust or activate the

desired function.

Press rotary encoder momentarily to select between

Volume (default), Bass, Treble, Balance & Fader.

Press rotary encoder until BAS appears then rotate encoder

left/right to adjust ( -6 minimum / +6 maximum).

Press rotary encoder until TRE appears then rotate encoder

left/right to adjust ( -6 minimum / +6 maximum).

Press rotary encoder until BAL appears then rotate encoder

left/right to adjust (BAL L 12-BAL 00-BAL R 12).

BAL 00 represents equal balance

Press rotary encoder until FAD appears then rotate encoder

left/right to adjust (FAD F 12-FAD 00-FAD R 12).

FAD 00 represents equal fader

Individual Bass and Treble settings are retained in memory

for AM, FM, CD, and AUX modes. This allows you to save the

Bass and Treble settings separately for each mode.

Example:

FM tuner mode can have Bass +3 and Treble -1 while CD

mode can have Bass +2 and Treble +2.

Note:

Any adjustment to the Bass or Treble settings automatically

cancels the current EQ curve (if one is selected).

Press and hold for more than 2 seconds to RESET the unit

upon initial installation or if abnormal operation occurs. The

reset button is located behind the faceplate.

Audio

Bass

Treble

Balance

Fader

Source Audio Memory

Reset

XDM6830 OPERATION

General Operation - Audio Settings

BASS

VOLUME TREBLE BALANCE FADER

Seek Tuning

Manual Tuning

Scan Tuning

Band

Storing and Recalling

Station Presets

Automatically Store

Stations

Preset Scan

Press TUNE

or TUNE

momentarily to seek the

next strong station.

Press TUNE

or TUNE

for more than 2 seconds,

then release. "MANUAL" will momentarily appear in the

display. Press TUNE

or TUNE

momentarily to

move radio frequency up or down one step at a time. Press

and hold to advance quickly. If tuning is not adjusted for 5

seconds, the unit will return to seek tuning mode (default).

"AUTO" will momentarily appear in the display.

Press SCN to preview strong stations on the current band,

pausing for 5 seconds at each. Press SCN again to cancel.

Press BAND to select between FM1, FM2, FM3, AM1 and

AM2 bands.

Up to 18 FM stations and 12 AM stations can be stored. To

store a station, select the desired band and station. Press

and hold the desired preset button (1-6) for more than

2 seconds. When stored, the preset number will appear in

the display. The station can be recalled anytime by pressing

the corresponding preset button.

Note:

Function keys 7, 8, 9 and 0 apply to MP3/WMA operation

only.

Press AS/PS for more than 2 seconds to automatically store

the six strongest stations in the current band. Automatic

Local tuning is activated during the initial band scan.

Press AS/PS for less than 2 seconds to scan presets 1-6 on

the current band, pausing for 5 seconds at each. Press

AS/PS again to cancel.

XDM6830 OPERATION

Tuner Operation

Insert CD

Eject CD

Track Select

Fast Forward and Reverse

Pause

Intro

Repeat

Random

CD-R/CD-RW Compatibility

With the label facing up, insert a standard size CD into the

CD slot. The CD will automatically begin playback.

Press EJECT to eject the CD. The unit will change to

previous mode of operation (AM, FM, or auxiliary input).

If the disc is not removed within 10 seconds, the unit will

reload the disc. The unit does not have to be turned on to

eject CD.

Press TRACK

to skip to the beginning of the next

track. Press TRACK

to return to the beginning of the

current track. Pressing TRACK

again skips to the

beginning of the previous track.

Press and hold TRACK

or TRACK

to fast forward

or reverse a track.

Press

to temporarily stop CD playback.

Press

again to resume playback.

Press INT to play the first 10 seconds of each track.

Press INT again to cancel.

Press RPT to continuously repeat selected track.

Press RPT again to cancel.

Press RDM to play all tracks in random order. Press RDM

again to cancel. Random mode is retained in memory when

selecting between tuner, CD player and auxiliary input

modes and when the unit is turned on/off.

Some CD-Rs and CD-RWs may be incompatible with this

unit, depending on media type and recording method. In

addition, the following CDs may be incompatible with this

unit:

CDs exposed to extreme temperatures or direct sunlight

for extended periods of time, CDs recorded in which a

recording session failed or a re-recording was attempted

and, or encrypted or copy-protected CDs which do not

conform to the audio CD-DA red book recording standard.

XDM6830 OPERATION

CD Player Operation

Tabla de contenidos

Otros manuales de Receptor de coche de Dual

Dual

Dual XRM405BT Instrucciones de funcionamiento

Dual

Dual XD6320 Instrucciones de funcionamiento

Dual

Dual XDM270 Instrucciones de funcionamiento

Dual

Dual DC416BT Instrucciones de funcionamiento

Dual

Dual XD7500 Instrucciones de funcionamiento

Dual

Dual MXD426BT Instrucciones de funcionamiento

Dual

Dual XDMR7700 Instrucciones de funcionamiento

Dual

Dual AXXERA XDMA7800 Instrucciones de funcionamiento

Dual

Dual DV1014BH Instrucciones de funcionamiento

Dual

Dual DXDM280BT Instrucciones de funcionamiento

Dual

Dual ZDM6800 Instrucciones de funcionamiento

Dual

Dual DXRM59BT Instrucciones de funcionamiento

Dual

Dual DVM179 Instrucciones de funcionamiento

Dual

Dual XDM6350 Instrucciones de funcionamiento

Dual

Dual XDM260 Manual de usuario

Dual

Dual XD1215 Instrucciones de funcionamiento

Dual

Dual XHD6430 Instrucciones de funcionamiento

Dual

Dual XDMA690 Instrucciones de funcionamiento

Dual

Dual XDCPA9BT Instrucciones de funcionamiento

Dual

Dual XP Series Instrucciones de funcionamiento

Dual

Dual XDVDN8190N Instrucciones de funcionamiento

Dual

Dual XDMA6438 Instrucciones de funcionamiento

Dual

Dual XDVD156BT Instrucciones de funcionamiento

Dual

Dual XRM49BT Instrucciones de funcionamiento

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario
