Dual XDM6400 Instrucciones de funcionamiento

INSTALLATION/OWNER'S MANUAL

AM/FM/CD/MP3/WMA/USB/3.5mm/Bluetooth® Ready Receiver with Detachable Face

XDM6400

TYPICAL FRONT-LOAD DIN MOUNTING METHOD

Please read entire manual before installation.

Before You Start

• Disconnect negative battery terminal. Consult a qualified technician for instructions.

• Avoid installing the unit where it would be subject to high temperatures, such as from

direct sunlight, or where it would be subject to dust, dirt or excessive vibration.

Getting Started

• Remove trim ring from unit,

• Remove 2 transit screws located

on top of the unit.

• Insert the supplied keys into the

slots as shown, and slide the unit

out of the mounting sleeve.

• Install mounting sleeve into

opening, bending tabs to secure.

• Connect wiring harness and

antenna. Consult a qualified

technician if you are unsure.

• Certain vehicles may require an

installation kit and/or wiring

harness adapter (sold separately).

• Test for correct operation and slide

into mounting sleeve to secure.

• Snap trim ring into place.

XDM6400 INSTALLATION

Preparation

FUSE

When replacing the fuse,

make sure new fuse is the

correct type and amperage.

Using an incorrect fuse

could damage the radio.

The XDM6400 uses one

10 amp ATM fuse located

beside the wiring connector.

XDM6400 INSTALLATION

Wiring Diagram

BLACK 8-pin Female Mini-DIN

BTM60 Connection (sold separately)

Antenna Connector

The XDM6400 allows playback of your favorite MP3 and WMA files recorded on CD-R and

CD-RW discs. Its powerful on-board DSP processor decodes the compressed audio while

maintaining near-CD sound quality. An internal SRAM buffer provides ESP (Electronic

Skip Protection) to virtually eliminate skipping and allows alphanumeric or direct track

search - even while a song is currently playing!

Function keys 7, 8, 9 and 0 apply to Bluetooth and MP3/WMA operation only.

XDM6400 OPERATION

Control Locations - Receiver

Release

Eject

Mode/Search

Volume/Audio/Setup

Tune/Track Up

Talk/Redial

EQ/Key 9

Key 0

USB Port (Covered)

Auxiliary Input

Tuner Scan/Key 8

Key 7

Preset 6/Folder Up

Preset 5/Folder Down

Preset 4

Preset 3/Intro

Preset 2/Random

Preset 1/Repeat

Auto Store/Preset Scan/Enter/Key #

Band/Play/Pause/Key *

Display

Mute/End Call

Tune/Track Down

Power

2022 19 18 17 16 15 14 13

1235 6 7 8

21 11 10

2324

Faceplate Removal

Semi-Permanent

Faceplate Installation

Power On/Off

Mode

Auxiliary Input

Volume

Programmable

Turn-On Volume

Mute

Preset EQ Curves

Reset

Display

General Operation

XDM6400 OPERATION

Press RELEASE and pull away from the left side to remove.

To re-install, insert right side of faceplate first then push

left side to secure.

Remove trim ring and install supplied #1 x 7/32” Phillips

head screw through left side of mounting frame into faceplate.

Press POWER or any other button (except eject) to turn the

unit on. Inserting a disc will turn the unit on automatically.

Press POWER to turn the unit off.

Press MODE to select between AM/FM, CD player, auxiliary

input, USB and Bluetooth (optional). Modes of operation are

indicated in the display.

NOTE: CD, USB and Bluetooth modes will not appear unless

a CD is inserted, a USB device (sold separately) is connected

or BTM60 (Bluetooth module - sold separately) is attached.

Insert 3.5 mm plug to connect your portable audio device.

Adjust volume using rotary encoder (00-46).

Press and hold POWER for 3 seconds to program currently

selected volume level. "P-VOL" and the current volume level

will momentarily appear in the display.

Press MUTE to silence the audio. “MUTE” will flash in the

display. Press MUTE again to cancel.

Press EQ to select between POP, JAZZ, CLASSIC, BEAT,

ROCK and OFF (default) equalization curves. Any adjustment

to the Bass or Treble settings automatically cancels the

current EQ curve (if one is selected).

Press to RESET the unit upon initial installation or if

abnormal operation occurs. The reset button is located

behind the faceplate.

Press DISP to select between clock and different types of

information, such as radio frequency, CD track/elapsed time,

or MP3/WMA/USB song information.

With the unit on, press and hold DISP until the clock begins to

flash, then release. Press TUNE

to adjust the hours and

TUNE

to adjust the minutes. Press DISP momentarily to

save the selected time.

The clock will display 12-hour AM/PM time in USA frequency

spacing mode (PM 10:00). In European frequency spacing

mode, the clock will display 24-hour time (22:00).

Press and hold the rotary encoder for more than 3 seconds to

access the setup menu. Press the rotary encoder momentarily

to select between the menu functions and rotate the rotary

encoder left/right to adjust or activate the desired function.

Set the Clock

12/24-hour Clock

Setup Menu

XDM6400 OPERATION

General Operation

Setup Menu

Menu Function Options Action

Loudness Curve LOUD OFF Disables the loudness function.

LOUD ON Enables the loudness function. Activating this feature

will enhance the bass and treble frequencies when

listening to music at low volumes.

Tuner Frequency

Spacing

FREQ USA Programs the unit to USA tuner spacing.

(200kHz for FM and 10kHz for AM)

FREQ EUR Programs the unit to European tuner spacing.

(50kHz for FM and 9kHz for AM)

Clock Display CLK OFF Programs the unit to not display the clock when the

power is off.

CLK ON Programs the unit to display the clock when the power

is off.

Auxiliary Input AUX ON Enables the front panel 3.5mm auxiliary input.

AUX OFF Disables the auxiliary input.

Beep

Confirmation

BEEP OFF Disables the confirmation beep.

BEEP ON Enables the confirmation beep.

Local/Distance

Tuning

LOC OFF Activates distance tuning.

LOC ON Activates local tuning for strong station reception only.

Power on

Message

MSG OFF Disables power on message.

MSG ON Enables power on message to be displayed.

Demonstration

Mode

DEMO ON Enables the "BT READY" message.

DEMO OFF Disables the demonstration mode.

XDM6400 OPERATION

Press rotary encoder momentarily to select between

Volume (default), Bass, Treble, Balance, & Fader.

Press rotary encoder until BAS appears then rotate encoder

left/right to adjust ( -6 minimum / +6 maximum).

Press rotary encoder until TRE appears then rotate encoder

left/right to adjust ( -6 minimum / +6 maximum).

Press rotary encoder until BAL appears then rotate encoder

left/right to adjust (BAL L 12-BAL 00-BAL R 12).

BAL 00 represents equal balance

Press rotary encoder until FAD appears then rotate encoder

left/right to adjust (FAD F 12-FAD 00-FAD R 12).

FAD 00 represents equal fader

Individual Bass and Treble settings are retained in memory

for tuner, CD, AUX, USB and Bluetooth modes. This allows

you to save the Bass and Treble settings separately for each

mode.

Note:

Any adjustment to the Bass or Treble settings automatically

cancels the current EQ curve (if one is selected).

Audio

Bass

Treble

Balance

Fader

Source Audio Memory

General Operation

BASSVOLUME TREBLE BALANCE FADER

XDM6400 OPERATION

Seek Tuning

Manual Tuning

Scan Tuning

Band

Storing and Recalling

Station Presets

Automatically Store

Stations

Preset Scan

Press TUNE

or TUNE

momentarily to seek the

next strong station.

Press TUNE

or TUNE

for more than two seconds,

then release. "MANUAL" will momentarily appear in the

display. Press TUNE

or TUNE

momentarily to

move radio frequency up or down one step at a time. Press

and hold to advance quickly. If tuning is not adjusted for five

seconds, the unit will return to seek tuning mode (default).

"AUTO" will momentarily appear in the display.

Press SCN to preview strong stations on the current band,

pausing for five seconds at each. Press SCN again to cancel.

Press BAND to select between FM1, FM2, FM3, AM1 and

AM2 bands.

Up to 18 FM stations and 12 AM stations can be stored. To

store a station, select the desired band and station. Press

and hold the desired preset button (1-6) for more than

two seconds. When stored, the preset number will appear in

the display. The station can be recalled anytime by pressing

the corresponding preset button.

Note: Function keys 7, 8, 9 and 0 apply to Bluetooth, USB and

MP3/WMA operation only.

Press AS/PS for more than two seconds to automatically

store the six strongest stations in the current band.

Automatic local tuning is activated during the initial band

scan.

Press AS/PS for less than two seconds to scan presets 1-6

on the current band, pausing for five seconds at each. Press

AS/PS again to cancel.

AM/FM Tuner Operation

XDM6400 OPERATION

Insert CD

Eject CD

Track Select

Fast Forward and Reverse

Pause

Scan

Repeat

Random

CD-R/CD-RW Compatibility

With the label facing up, insert a standard size CD into the

CD slot. The CD will automatically begin playback.

Press EJECT to eject the CD. The unit will change to

previous mode of operation (tuner, AUX, USB or Bluetooth).

If the disc is not removed within 10 seconds, the unit will

reload the disc. The unit does not have to be turned on to

eject CD.

Press TRACK

to skip to the beginning of the next

track. Press TRACK

to return to the beginning of the

current track. Pressing TRACK

again skips to the

beginning of the previous track.

Press and hold TRACK

or TRACK

to fast forward

or reverse a track.

Press

to temporarily stop CD playback.

Press

again to resume playback.

Press INT to play the first 10 seconds of each track.

Press INT again to cancel.

Press RPT to continuously repeat selected track.

Press RPT again to cancel.

Press RDM to play all tracks in random order. Press RDM

again to cancel. Random mode is retained in memory

when selecting between tuner, CD, AUX, USB and Bluetooth

modes and when the unit is turned on/off.

Some CD-Rs and CD-RWs may be incompatible with this

unit, depending on media type and recording method. In

addition, the following CDs may be incompatible with this

unit:

CDs exposed to extreme temperatures or direct sunlight

for extended periods of time, CDs recorded in which a

recording session failed or a re-recording was attempted

and, or encrypted or copy-protected CDs which do not

conform to the audio CD-DA red book recording standard.

CD Player Operation

XDM6400 OPERATION

CD Player Operation - MP3/WMA Files

Playing an MP3/WMA Disc

Displaying Information

Title Icon

Artist Icon

Album Icon

Folder Icon

Character Support

When an MP3/WMA encoded disc is first inserted,

“READING” will appear in the display. Depending on the

number of files and folders, this may take several seconds.

Press DISP to select between track number/elapsed time

(default), clock, track name, directory name, title, artist and

album.

“NO ID3 TAG” will be displayed if the MP3 file contains no

ID3 tag information.

“UNKNOWN” will be displayed if the WMA file contains no

WMA tag information.

“ROOT” will be displayed if the directory name of a root

folder is not labeled.

This icon will illuminate when the song title is displayed.

This icon will illuminate when the artist name is displayed.

This icon will illuminate when the album name is displayed.

This icon will illuminate when the folder name is displayed.

Maximum character display information

• Track name – 32 character maximum

• Directory name – 23 character maximum

• *Song title – 30 character maximum

• *Artist name – 30 character maximum

• *Album name – 30 character maximum

*Song title, Artist Name, and Album name, will only be

displayed if included with the MP3/WMA file.

When referring to MP3/WMA playback, the following terms

are synonymous:

• File name and track name

• Folder name and directory name

Otros manuales para XDM6400

Tabla de contenidos

Otros manuales de Receptor de coche de Dual

Dual

Dual DCPA701 Instrucciones de funcionamiento

Dual

Dual XHD7714 Instrucciones de funcionamiento

Dual

Dual iPlug XDM6220 Instrucciones de funcionamiento

Dual

Dual XDVD3101 Instrucciones de funcionamiento

Dual

Dual XDC100BT Instrucciones de funcionamiento

Dual

Dual XDVD3101 Instrucciones de funcionamiento

Dual

Dual DMCPA70 Instrucciones de funcionamiento

Dual

Dual iplug XDM6820 Instrucciones de funcionamiento

Dual

Dual XML8110 Instrucciones de funcionamiento

Dual

Dual MXD420 Instrucciones de funcionamiento

Dual

Dual XD6150 Instrucciones de funcionamiento

Dual

Dual MXD105 Instrucciones de funcionamiento

Dual

Dual XD5220 Instrucciones de funcionamiento

Dual

Dual XRM69RGB Instrucciones de funcionamiento

Dual

Dual DV605 Instrucciones de funcionamiento

Dual

Dual XHD7714 Instrucciones de funcionamiento

Dual

Dual DXRM59BT Instrucciones de funcionamiento

Dual

Dual DV1014BH Instrucciones de funcionamiento

Dual

Dual DSA2062 Manual de usuario

Dual

Dual XHD6430 Instrucciones de funcionamiento

Dual

Dual DM90MIR Instrucciones de funcionamiento

Dual

Dual DMCPA70BT Instrucciones de funcionamiento

Dual

Dual XHD7714 - V3 Instrucciones de funcionamiento

Dual

Dual XDVDN8190 Instrucciones de funcionamiento

Manuales populares de Receptor de coche de otras marcas

Motorola

Motorola VWA63 Manual de usuario

Nextar

Nextar D3201 Manual de usuario

Alpine

Alpine CDE-163BT Manual de usuario

Pioneer

Pioneer DEH-P645R Manual de usuario

Axxera

Axxera XDMA7600 Instrucciones de funcionamiento

XM OnyX Manual de usuario

Sound Storm

Sound Storm STM93R Manual de usuario

Soundstream

Soundstream VIR-5000 Manual de usuario

Avson

Avson MKT Platform Manual de usuario

Sony

Sony MEX-1HD - Audio Library System Manual de usuario

Pioneer

Pioneer DVH-P500UB Manual de usuario

JVC

JVC KD-AHD69 Manual de usuario

Blaupunkt

Blaupunkt SANTIAGO CR 87 Manual de usuario

Sony

Sony CDX-4160 - Cd Receiver Manual de usuario

XFIRE AUDIO

XFIRE AUDIO BMW42S Manual de usuario

VDO

VDO CD 2253 Manual de usuario

Volvo

Volvo 13 84 580 Manual de usuario

ZENEC

ZENEC ZE-160DVD Manual de usuario
