DTK PAM-0057I Manual de usuario

PAM-0057I

High Performance

Pentium PCI Mainboard

User’s Guide

Edition 3.04

P/N: 155100-8624

CAUTION

The motherboard is an electrostatic sensitive device. Don’t open or handle except at a static-free

workstation.

Windows, MS-DOS, and MS Word are trademarks of Microsoft Corporation.

Novell, Netware are trademarks of Novell, Inc.

Lotus, 1-2-3, and Symphony are trademarks of Lotus Development Corporation.

PC, AT, PC-DOS, OS/2 and Presentation Manager are trademarks of IBM Corporation.

Intel 82430TX, Pentium is registered trademark of Intel Corp.

UNIX is the trademark of AT&T.

All other brand and product names are trademarks or registered trademarks of their respective

companies.

The information presented in this publication has been carefully checked for reliability; however,

no responsibility is assumed for inaccuracies, whereas, specification is subjected to change

without notice.

CONTENTS

CHAPTER 1 INTRODUCTION 1

CHAPTER 2 JUMPER SETTINGS 5

2.1 JUMPERS PRESENTATION 5

2.2 CPU TYPE 5

2.2.1 INTEL PENTIUM CPU 5

2.2.2 INTEL PENTIUM w/ MMXTECH (P55C) CPU 6

2.2.3 AMD-K6 CPU 6

2.2.4 AMD-K5 CPU 7

2.2.5 CYRIX 6x86 CPU 7

2.2.6 CYRIX 6x86L CPU 8

2.2.7 CYRIX 6x86MX CPU 8

2.2.8 IDT WinCHIP C6 CPU 9

2.3 GRAPHICAL DESCRIPTION OF JUMPER SETTINGS 10

2.4 CPU VOLTAGE SELECTION 11

2.5 CPU TO BUS FREQUENCY RATIO (JP12) 14

2.6 CPU EXTERNAL (BUS) FREQUENCY SELECTION

(JP9, JP10, JP13) 14

2.7 CPU SPEED 14

2.8 MEMORY CONFIGURATION 16

2.9 CACHE MEMORY CONFIGURATION 17

CHAPTER 3 CONNECTORS CONFIGURATION 19

3.1 J2 - RESET SWITCH, SMI SWITCH, SPEAKER, TURBO LED,

KEYLOCK AND HDD LED CONNECTOR 20

3.2 J10 - PRIMARY IDE CONNECTOR 22

3.3 J11 - SECONDARY IDE CONNECTOR 23

3.4 J12 - USB0, USB1, PS/2 MOUSE EXTENSION, IrDA AND FAST IR

CONNECTOR 23

3.5 J13 - SERIAL PORT 2 24

3.6 J14 - SERIAL PORT 1 24

3.7 J15 - PARALLEL PORT 24

3.8 J16 - FLOPPY DRIVE CONTROLLER 24

3.9 J19 - PS/2 STYLE MOUSE CONNECTOR (OPTIONAL) 24

3.10 J20 - KEYBOARD CONNECTOR 25

3.11 J21 - PS/2 STYLE KEYBOARD CONNECTOR (OPTIONAL) 25

3.12 J22 - POWER SUPPLY CONNECTOR 26

CHAPTER 4 AWARD BIOS SETUP GUIDE 27

4.1 AWARD BIOS SETUP 27

4.2 STANDARD CMOS SETUP 29

4.3 BIOS FEATURES SETUP 30

4.4 CHIPSET FEATURES SETUP 32

4.5 POWER MANAGEMENT SETUP MENU 33

4.6 PnP/PCI CONFIGURATION 35

III

4.7 INTEGRATED PERIPHERALS SETUP MENU 36

4.8 LOAD SETUP DEFAULTS MENU 38

4.9 SUPERVISOR PASSWORD 38

4.10 USER PASSWORD 39

4.11 IDE HDD AUTO DETECTION 39

4.12 SCSI HARD DISK INSTALLATION 39

4.13 SAVE & EXIT SETUP MENU 39

4.14 EXIT WITHOUT SAVING MENU 40

CHAPTER 5 FLASH AND DMI UTILITY 41

5.1 AWARD FLASH UTILITY 41

5.2 DESKTOP MANAGEMENT INTERFACE (DMI) OVERVIEW 43

APPENDIX A QUICK GUIDE 47

CHAPTER 1 INTRODUCTION

Preface

The motherboard is a 4-layer, 2/3 baby AT size high-performance mainboard. It includes Intel

82430TX system chipset, Winbond W83877F/W83877TF Super I/O controller.

Features

Processor

•Intel Pentium P54C, P55C series.

•Cyrix 6x86, Cyrix 6x86L; AMD-K5 and AMD-K6 series 64-bit microprocessors.

•The mainboard can run with following speeds:

90, 100, 110, 120, 133, 150, 166, 200, 233, 266 and 300MHz

Chipset

•Intel 82439TX (Intel 82430TX System Controller)

•Intel 82371AB (PCI ISA IDE Xcelerator)

•Winbond W83877F (Super I/O Controller)

Cache Size

•Synchronised Pipelined Burst Mode SRAM to achieve the high Pentium system

performance.

•Cache size is 0/256/512KB.

Main Memory

•Support Mixed Memory Technologies: EDO (Extend Data Output), Standard Page Mode

(SPM), Fast Page Mode (FPM), and Synchronous DRAM (SDRAM) SIMM can work

together.

•Memory configurations from 4MB to 256MB are possible using combination of 512K*32 to

8M*32 SIMM module (32Bits no-parity 72-pin SIMM Module) and 2M*32 to 8M*32

SDRAM DIMM Module.

•DIMM socket for SDRAM (3.3V unbuffered).

Multi I/O

•On board Multi-I/O supports two serial, one parallel ports and floppy drive controller.

•Serial ports are 16550 Fast UART compatible.

•Parallel port has EPP and ECP capabilities.

•PS/2 mouse and keyboard supported.

•IrDA supported.

•Dual standard USB (Universal Serial Bus) ports supported.

Chapter 1

Fig. 1 Key Components of the Mainboard

Introduction

PCI IDE

•On board supports PCI Master IDE Controller, two connectors support up to four IDE

devices such as HDD, CD ROM drive and Tape Back-up drives, etc.

•PCI Master IDE controller supports PIO Mode 3 and 4 devices, I/O data transfer rate can be

up to 17Mb/s. DMA mode transfer rate can be up to 22Mb/s.

•Ultra DMA mode supported. Transfer rate can be up to 33Mb/s.

System BIOS

•Award BIOS (128KB Flash EPROM).

Slots

•Four PCI slots

•Four ISA slots

Board

•4 Layer

Form Factor

•2/3 Baby AT Size (220 x 260mm)

Environment

Working Specifications

Actual Field MTBF (hours) 104,515 hours

Preventive Maintenance Not Required

Environmental Limits

Operating Non-operating

Temperature 0 to 50 Degree Celsius -10 to 65 Degree Celsius

Relative Humidity

(without condensation) 8 to 85% 5 to 95%

Altitude 10,000ft 40,000ft

Power Specifications

Configuration: 133MHz Intel P54C CPU, 16MB 60ns EDO SIMM, 256KB Cache, 3.5 inch

floppy drive, 840MB Hard Disk, running at DOS prompt.

DC Voltage Tolerance Consumption (mA)

+5V +/- 5% 860

+5V Stand by +/- 5% 0.5

+5V +/- 5% 0

+12V +/- 5% 200

-12V +/- 5% 30

Chapter 1
