Drive TRIDENT HD Manual de usuario

TRIDENT HD

OWNER’S MANUAL

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

I. PREFACE 3

II. SAFETY NOTICES 4

III. SAFETY GUIDELINES 6

IV. EMI & RFI INFORMATION 13

V. PARTS 14

VI. ASSEMBLY 16

VII. COMFORT ADJUSTMENTS 19

VIII. OPERATION 23

IX. BATTERIES & CHARGING 25

X. INSPECTION & MAINTENANCE 27

XI. BASIC TROUBLESHOOTING 31

XII. SPECIFICATIONS 32

XIII. LIMITED WARRANTY 33

XIV. ACCESSORIES 35

TABLE OF CONTENTS

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

Please read this Owner’s Manual before operating your power wheelchair for the first

time. Improper use or unfamiliarity of the power wheelchair may result in harm,

injury, or traffic accidents.

This Owner’s Manual includes operation instructions, assembly instructions, and best

practices to ensure maximum use from your power wheelchair.

The symbols used throughout this Owner’s Manual are explained below. Read

carefully, and fully understand the sections marked with these symbols:

WARNING –Improper use could lead to death, serious injury, hazardous

conditions, or product malfunction.

ATTENTION –Improper use could lead to injury and/or damage to your

power wheelchair.

SUGGESTION –Follow these instructions for best practices, and to keep

your power wheelchair in prime operating order.

This Owner’s Manual includes a repair maintenance record chart and warranty. Please

keep it in a safe place, or with the power wheelchair.

If someone else uses the power wheelchair, please provide a copy of the Owner’s

Manual for their consideration.

This Owner’s Manual is composed from the product design and specifications at the

time of publication. As designs change, some illustrations and pictures in the manual

may not correspond to the power wheelchair that you purchased. We reserve the

right to make design modifications.

This product has been designed to provide a comfortable and secure solution for

individuals limited to a seated position who are capable of operating a power

wheelchair.

The manufacturer disclaims all responsibilities for any personal injury or property

damage which may occur as a result of improper or unsafe use of this product.

I. PREFACE

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

II. SAFETY NOTICES

Read and follow the information in the owner’s manual.

Fully charge the battery after every trip and prior to using the power wheelchair. If

you do not frequently use the power wheelchair fully charge the batteries every

two weeks to prevent battery failure.

If the battery gauge drops to red, charge the power wheelchair as soon as possible.

Completely discharging the batteries may damage the batteries, or shorten the

expected life of the batteries.

Batteries contain lead and lead compounds. Wear proper safety attire when

handling batteries.

Only use sealed lead acid AGM or gel-cell batteries in this product.

Keep metal objects away from the battery terminals, electric shock may occur.

Always replace both batteries at the same time for optimum performance.

Always make sure the power is turned off when getting in and out of the power

wheelchair.

Always make sure freewheel levers are in the drive position before getting in or out

of the power wheelchair.

Do not put the power wheelchair in freewheel when on an incline or decline.

To ensure the user’s familiarity with the power wheelchair’s operation, practice

driving at low speeds in a spacious hazard-free area travelling forward, backward,

left, right, decelerating, maneuvering up inclines, and down inclines.

Avoid unnecessary movement of the power wheelchair.

Always wear the seat belt included with this product when operating.

Never reach, lean or bend when driving your power wheelchair.

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

II. SAFETY NOTICES

Avoid exposure to moisture, standing water, rain, snow, ice or salt when possible.

Store in a clean and dry condition.

Do not drive your power wheelchair at night without proper lighting.

Do not remove the anti-tip wheels.

Keep your feet on the footplate at all times during operation.

Do not stand on the footplate.

Keep your hands and feet away from moving parts while driving.

Be aware of loose fitting clothes that can become caught in the drive wheels.

Do not connect an extension cord to the battery charger.

Disassembling the electronics by anyone other than an authorized Drive Medical

service agent is prohibited, and voids any applicable warranty.

Do not take your power wheelchair on roads or highways.

Do not operate your power wheelchair when you are tired, or after consuming

alcohol.

Be cautious when driving your power wheelchair in busy areas or shopping malls.

Under no circumstances should the power wheelchair be used as a seat in a motor

vehicle.

Do not attempt to lift your power wheelchair by any parts other than the frame.

WARNING - The items and packaging in this shipment contain chemicals known to

the state of California to cause cancer, birth defects or other reproductive harm.

If you will be seated in your power wheelchair for an extended period of time,

power off the power wheelchair. This will prevent inadvertent movement from

unexpected joystick contact.

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

GENERAL GUIDELINES

Before operating your power wheelchair fully read and understand this Owner’s

Manual.

Be sure to follow the setup instructions prior to using your power wheelchair for the

first time.

Users may encounter difficult maneuvering situations such as narrow doorways,

travelling up and down ramps, cornering, and travelling on uneven terrain. Be sure to

lower the speed, take your time, and carefully maneuver the power wheelchair.

MODIFICATIONS

Do not modify, remove, disable, or add any parts, features, or functions on your

power wheelchair. Drive Medical offers a wide variety of accessories for your power

wheelchair to help accommodate your needs.

WARNING –Do not modify your power wheelchair in any way; doing so

will void the warranty.

SAFETY CHECK

ATTENTION –Inspect the following components before each use:

Electrical connections –secure and free from corrosion

Joystick connections –secure and routed properly to the base of the power

wheelchair

Freewheel Levers –engaged in drive position

Batteries –fully charged and free from corrosion

If you notice a problem please contact your authorized Drive Medical Provider for

assistance.

III. SAFETY GUIDELINES

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

WEIGHT CAPACITY

This power wheelchair has a maximum weight capacity that should never be

exceeded. Please refer to Section XII SPECIFICATIONS for this information. The

maximum weight capacity includes the user and any accessories.

WARNING –Exceeding the maximum weight capacity will void your

warranty. Drive Medical will not be held responsible for injuries and/or

damages resulting from failure to observe weight capacities.

WARNING –Do not carry passengers on your power wheelchair. Your

power wheelchair is designed and tested for one user to operate while

seated with the safety belt fastened.

INCLINE GUIDELINES

Use caution when approaching inclines or declines; if necessary lower the speed

before travelling on a slope.

When travelling up an incline try to keep the power wheelchair moving forward. If you

must come to a stop, use caution and slowly accelerate the power wheelchair

forward.

When travelling down an incline lower the speed on your power wheelchair to the

slowest setting, and proceed cautiously. If the power wheelchair is travelling down the

incline faster than you expected, release the joystick to come to a stop, then slightly

push the joystick forward to continue safely down the incline.

WARNING –Never put the power wheelchair in freewheel model while on

an incline.

WARNING –Drive your power wheelchair straight up or down an incline,

never backwards. Erratic movements, or back and forth patterns may

increase the chance of tipping.

III. SAFETY GUIDELINES

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

WARNING –Do not travel up an incline with the seat completely reclined

without an attendant. Inclines vary, and doing so may decrease stability.

WARNING –Do not, under any circumstances, travel on a slope greater

than the maximum climbing angle for this power wheelchair. Please refer

to Section XII SPECIFICATIONS for this information. Exceeding the climbing

angle may cause unstable conditions.

FREEWHEEL GUIDELINES

Your power wheelchair is equipped with manual freewheel levers to maneuver the

unit without power. The manual freewheel levers can be engaged or disengaged.

Disengaged, or “freewheel” mode, releases the locking mechanism on the gearbox

allowing the power wheelchair to roll freely with or without power.

Engaged, or “drive” mode, secures the locking mechanism on the gearbox preventing

the power wheelchair from rolling freely.

WARNING –Never attempt to personally put your power wheelchair in

freewheel mode while seated in the unit.

WARNING –Never put the power wheelchair in freewheel mode while on

an incline. This may cause uncontrollable movements.

ATTENTION –When your power wheelchair is in freewheel mode you may

feel resistance when maneuvering; this is normal, and prevents damage

to the gearbox.

ATTENTION –Please refer to Section V PARTS to locate the freewheel

levers on your power wheelchair.

SUGGESTION –If you hear a “clicking” noise when moving the joystick,

but the power wheelchair will not move –turn off the power, engage the

freewheel levers, and power back on to continue.

III. SAFETY GUIDELINES

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

BRAKES & STOPPING

Coming to a stop in your power wheelchair can simply be done by releasing the

joystick. The joystick will automatically return to the center position, and the power

wheelchair will come to a stop.

ATTENTION –Quickly moving the joystick in the opposite direction of

travel will cause the power wheelchair to come to an abrupt stop, and if

held continuously in the opposite direction may cause erratic movements

if you are unfamiliar with the controls.

Your power wheelchair is equipped with two types of brake systems:

Regenerative brakes –when the joystick is returned to the center position, or

stop neutral position, regenerative brakes use electricity to quickly decelerate

the vehicle.

Park brakes –once the power wheelchair comes to a complete stop the park

brake activates automatically locking the drive wheels.

OUTDOOR OPERATION & INCLEMENT WEATHER PRECAUTIONS

While your power wheelchair is purposed for in-home use to assist you in daily living

activities; Drive Medical understands there are times you need to operate the power

wheelchair outdoors, and has designed it to perform superbly on level outdoor

surfaces.

ATTENTION –When operating outdoors avoid uneven terrain, soft

surfaces, tall grass, loose gravel, loose sand, fresh water, salt water, edges

of streams, lakes or oceans. If you are unsure about a surface, avoid it.

Exposure to inclement weather should always be avoided. If you find yourself caught

in inclement weather while operating your power wheelchair, proceed to the closest

shelter immediately. Completely dry your power wheelchair before operating,

charging, or storing.

III. SAFETY GUIDELINES

REV.1.09.08.14

Trident HD Owner’s Manual www.drivemedical.com

STEPS, CURBS & FIXED OBSTACLES

Use extreme caution when operating your power wheelchair near curbs, porches,

stairs, escalators, drop-offs, unprotected ledges, and raised areas.

WARNING –Never attempt to navigate your power wheelchair over a

fixed obstacle taller than the maximum ground clearance. Please refer to

Section XII SPECIFICATIONS for this information.

WARNING –Never attempt to navigate your power wheelchair backwards

over an obstacle.

WARNING –Never attempt to operate your power wheelchair on steps or

escalators.

ATTENTION –Refer to the following guidelines and diagrams when

travelling over a fixed obstacle lower than the maximum ground

clearance of your power wheelchair:

To maneuver up a fixed obstacle –Approach slowly, and make sure the front of the

power wheelchair is perpendicular to the obstacle. Increase the forward speed until

the power wheelchair has cleared the obstacle, and then you may reduce the speed or

return the joystick to neutral.

To maneuver down a fixed obstacle –Approach slowly, and make sure the front of the

power wheelchair is perpendicular to the obstacle. Reduce the forward speed just

before the front wheels come in contact with the obstacle, and remain at the reduced

speed until power wheelchair has cleared the obstacle, and then you may increase the

forward speed.

CORRECT

APPROACH:

INCORRECT

APPROACH:

III. SAFETY GUIDELINES

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Silla de ruedas de Drive

Drive

Drive DKS 130 Manual de usuario

Drive

Drive CIRRUS Guía del usuario

Drive

Drive 990X Manual de usuario

Drive

Drive Travelite Chair In A Bag Guía del usuario

Drive

Drive Enigma Manual de usuario

Drive

Drive DKS 130 Manual de usuario

Drive

Drive PowerStroll Guía del usuario

Drive

Drive NRS185008 Manual de usuario

Drive

Drive Deluxe steel drop arm commode Manual de usuario

Drive

Drive DURO Manual de usuario

Drive

Drive TRS 200 XXL Manual de usuario

Drive

Drive Seren Manual de usuario

Drive

Drive SSP118FA-SF Manual de usuario

Drive

Drive FC 8025N Manual de usuario

Drive

Drive Enigma Manual de usuario

Drive

Drive Aston Shower Commode Guía del usuario

Drive

Drive Duro KD Manual de usuario

Drive

Drive KG P800 Manual de usuario

Drive

Drive Inspired Supreme BCCS-8510S Manual de usuario

Drive

Drive Sunfire Gladiator Manual de usuario

Drive

Drive Blue Streak Manual de usuario

Drive

Drive DeVilbiss Lightweight Powerstroll Manual de usuario

Drive

Drive Inspired Kanga Manual de usuario

Drive

Drive inspired POZIFORM P-CS180S Instrucciones de montaje

Manuales populares de Silla de ruedas de otras marcas

Otto Bock

Otto Bock Skippi plus Manual de usuario

Invacare

Invacare Action 4NG series Manual de usuario

SORG

SORG LoopSORG 802 Manual de usuario

Designability

Designability WizzyBug Instrucciones de instalación

Vermeiren

Vermeiren RAPIDO Manual de usuario

Excel

Excel G5 KIDS 0285 Manual de usuario

M. Bartels

M. Bartels SA-3 Manual de usuario

nino robotics

nino robotics NIno Manual de usuario

Vermeiren

Vermeiren Turios Manual de usuario

Invacare

Invacare MK5 EX Manual de usuario

Invacare

Invacare Solara Spree GT Manual

Nova

Nova TKW-12 Manual de usuario

BCW

BCW Advantage Manual de usuario

You-Q

You-Q Luca Manual de usuario

interco

interco Ortolight Standard Manual de instrucciones

Nova

Nova 7190L Manual de usuario

Vermeiren

Vermeiren EZ1 Manual de usuario

PaceSaver

PaceSaver Scout M-300 Manual de usuario
