Drill Master 90374 Manual de usuario

18V CORDLESS COMBO PACK

Model 90374

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit ourWeb site at: http://www.harborfreight.com

manual or any artwork contained herein may be reproduced in any shape or form

without the express written consent of Harbor Freight Tools.

For technical questions, please call 1-800-444-3353.

Distributed exclusively by

Harbor Freight Tools

Due to continuing improvements,

actual product may differ slightly from the product described herein.

REV 07l

PRODUCT SPECIFICATIONS

SAVE THIS MANUAL

You will need this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures, parts list and as-

sembly diagram. Keep your invoice with this manual. Write the invoice number

on the inside of the front cover. Keep this manual and invoice in a safe and dry

place for future reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS

Failure to follow all instructions listed below may result in

electric shock, fire, and/or serious injury.

SAVE THESE INSTRUCTIONS

WORK AREA

1. Keep your work area clean and well lit. Cluttered benches and dark areas

invite accidents.

2. Do not operate power tools in explosive atmospheres, such as in the

presence of flammable liquids, gases, or dust. Power tools create sparks

which may ignite the dust or fumes.

SKU 90374 PAGE 2 REV 05g, 07l

metInoitpircseD

stnemeriuqeRlacirtcelE zH06/CAV021:tupnIregrahCrettaB

CDV81:tuptuOyrettaB

emiTgnigrahCyrettaBsruoH5ot3

sno

itacificepSllirD MPR009/deepSelgniS/elbisreveR/sselyeK"8/3

8-1:stnemtsujdAeuqroT/reggirTezeeuqS

rednaSgn

itallicsO

snoitacificepS

tnemhcattApooL&kooH/epahSelgnairT

hctiwSrewoPrekcoR/MPO000,6

snoitacificepSthgil

hsalF hctiwSrewoPredilS/daeHleviwSeergeD09-0/pirGlotsiP

bluBttaW8/)raelC(sneLdeppetS

snoitacificepSwasgi

JreggirTezeeuqS/deepSenO/MPS007,1/ekortS"2/1

elbatsujdAelgnA/drauGedalB/kcoLytefaS

seirosseccA regrahCyr

ettaB/yrettaBCDV81elbaegrahceR

thgieWsdnuoP04.31

3. Keep bystanders, children, and visitors away while operating a power tool.

Distractions can cause you to lose control. Protect others in the work area from

debris such as chips and sparks. Provide barriers or shields as needed.

ELECTRICAL SAFETY

4. Grounded tools must be plugged into an outlet properly installed and

grounded in accordance with all codes and ordinances. Never remove the

grounding prong or modify the plug in any way. Do not use any adapter

plugs. Check with a qualified electrician if you are in doubt as to whether

the outlet is properly grounded. If the tools should electrically malfunction or

break down, grounding provides a low resistance path to carry electricity away

from the user.

5. Double insulated tools are equipped with a polarized plug (one blade is

wider than the other). This plug will fit in a polarized outlet only one way. If

the plug does not fit fully in the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician to install a polarized outlet. Do not

change the plug in any way. Double insulation eliminates the need for the

three wire grounded power cord and grounded power supply system.

6. Avoid body contact with grounded surfaces such as pipes, radiators,

ranges, and refrigerators. There is an increased risk of electric shock if your

body is grounded.

7. Do not expose power tools to rain or wet conditions. Water entering a power

tool will increase the risk of electric shock.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools

or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,

sharp edges, or moving parts. Replace damaged Power Cords immediately.

Damaged Power Cords increase the risk of electric shock.

9. When operating a power tool outside, use an outdoor extension cord

marked “W-A” or “W”. These extension cords are rated for outdoor use, and

reduce the risk of electric shock.

PERSONAL SAFETY

10. Stay alert. Watch what you are doing, and use common sense when

operating a power tool. Do not use a power tool while tired or under the

influence of drugs, alcohol, or medication. A moment of inattention while

operating power tools may result in serious personal injury.

SKU 90374 PAGE 3

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.

Keep your hair, clothing, and gloves away from moving parts. Loose

clothes, jewelry, or long hair can be caught in moving parts.

12. Avoid accidental starting. Be sure the Power Switch is off before plugging

in. Carrying power tools with your finger on the Power Switch, or plugging in

power tools with the Power Switch on, invites accidents.

13. Remove adjusting keys or wrenches before turning the power tool on. A

wrench or a key that is left attached to a rotating part of the power tool may result

in personal injury.

14. Do not overreach. Keep proper footing and balance at all times. Proper

footing and balance enables better control of the power tool in unexpected

situations.

15. Use safety equipment. Always wear eye protection. Dust mask, non-skid

safety shoes, hard hat, or hearing protection must be used for appropriate

conditions.

TOOL USE AND CARE

16. Use clamps (not included) or other practical ways to secure and support

the workpiece to a stable platform. Holding the work by hand or against your

body is unstable and may lead to loss of control.

17. Do not force the tool. Use the correct tool for your application. The correct

tool will do the job better and safer at the rate for which it is designed.

18. Do not use the power tool if the Power Switch does not turn it on or off.

Any tool that cannot be controlled with the Power Switch is dangerous and must

be replaced.

19. Disconnect the Battery from the tool before making any adjustments,

changing accessories, or storing the tool. Such preventive safety measures

reduce the risk of starting the tool accidentally.

20. Store idle tools out of reach of children and other untrained persons. Tools

are dangerous in the hands of untrained users.

21. Maintain tools with care. Keep cutting tools sharp and clean. Properly

maintained tools with a sharp cutting edge are less likely to bind and are easier

to control. Do not use a damaged tool. Tag damaged tools “Do not use” until

repaired.

SKU 90374 PAGE 4 REV 03j

22. Check for misalignment or binding of moving parts, breakage of parts, and

any other condition that may affect the tool’s operation. If damaged, have

the tool serviced before using. Many accidents are caused by poorly main-

tained tools.

23. Use only accessories that are recommended by the manufacturer for your

model. Accessories that may be suitable for one tool may become hazardous

when used on another tool.

SERVICE

24. Tool service must be performed only by qualified repair personnel. Service

or maintenance performed by unqualified personnel could result in a risk of injury.

25. When servicing a tool, use only identical replacement parts. Follow

instructions in the

“Inspection, Maintenance, And Cleaning”

section of this

manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

GROUNDING

SKU 90374 PAGE 5

WARNING!

Improperly connecting the grounding wire can result in the risk of electric shock.

Check with a qualfified electrician if you are in doubt as to whether the outlet is

properly grounded. Do not modify the power cord plug provided with the tool.

Never remove the grounding prong from the plug. Do not use the tool if the power

cord or plug is damaged. If damaged, have it repaired by a service facility before

use. If the plug will not fit the outlet, have a proper outlet installed by a qualified

electrician.

REV 03j

SKU 90374 PAGE 6 REV 03j

DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS

1. Tools marked “Double Insulated” do not require grounding. They have a special

double insulation system which satisfies OSHA requirements and complies with

the applicable standards of Underwriters Laboratories, Inc., the Canadian

Standard Association, and the National Electrical Code. (See Figure B.)

2. Double insulated tools may be used in either of the 120 volt outlets shown in the

following illustration. (See Figure B.)

FIGURE B

EXTENSION CORDS

Grounded

tools require a three wire extension cord.

Double Insulated

tools

can use either a two or three wire extension cord.

2. As the distance from the supply outlet increases, you must use a heavier gauge

extension cord. Using extension cords with inadequately sized wire causes a

serious drop in voltage, resulting in loss of power and possible tool damage.

(See Figure C, below.)

3. The smaller the gauge number of the wire, the greater the capacity of the cord.

For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.

(See Figure C.)

4. If using more than one extension cord to make up the total length, make sure

each cord contains at least the minimum wire size required. (See Figure C.)

SKU 90374 PAGE 7

5. If you are using one extension cord for more than one tool, add the nameplate

amperes and use the sum to determine the required minimum cord size.

(See Figure C.)

6. If you are using an extension cord outdoors, make sure it is marked with the

suffix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.

7. Make sure your extension cord is properly wired and in good electrical condition.

Always replace a damaged extension cord or have it repaired by a qualified

electrician before using it.

8. Protect your extension cords from sharp objects, excessive heat, and damp or

wet areas.

RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*

(120 VOLT)

NAMEPLATE

AMPERES

(

At Full Load

)

EXTENSION CORD LENGTH

Feet

100

Feet

150

Feet

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 18 14 12 10 -

12.1 – 16.0 14 12 10 - -

16.1 – 20.0 12 10 - - -

* Based on limiting the line voltage drop

to five volts at 150% of the rated amperes.

FIGURE C

SKU 90374 PAGE 8

SYMBOLOGY

Double Insulated

Canadian Standards

Association

Underwriters

Laboratories, Inc.

Volts Alternating Current

Amperes

No Load Revolutions

per Minute (RPM)

noxxxx/min.

V ~

SPECIFIC SAFETY RULES

1. Maintain a safe working environment. Keep the work area well lit. Make sure

there is adequate surrounding workspace. Always keep the work area free of

obstructions, grease, oil, trash, and other debris. Do not use the Combo Pack in

areas near flammable chemicals, dusts, and vapors.

2. Maintain labels and nameplates on the Combo Pack. These carry

important information. If unreadable or missing, contact Harbor Freight Tools for

a replacement.

3. Ground this product. To comply with the National Electric Code, and to provide

additional protection from the risk of electrical shock, the Battery Charger (1B)

should only be connected to a 120 volt electrical outlet that is protected by a

Ground Fault Circuit Interrupter (GFCI).

4. When using a hand-held power tool, always maintain a firm grip on the tool

with both hands.

5. To avoid electrical shock, do not pull or carry the Battery Charger/Charger

Base (1B, 1C) by its Power Cord or pull the Power Cord around sharp

corners or edges. Do not unplug the Battery Charger by pulling on the Power

Cord. Keep the Power Cord away from heated surfaces.

6. Never leave the Battery Charger (1B) unattended when it is plugged into an

electrical outlet. Make sure to unplug the Battery Charger from its outlet before

leaving.

REV 04f

7. Use eye protection. Always wear ANSI approved safety impact eye goggles

when working with these products.

8. Proper Battery Care: Battery (1A) leakage may occur under extreme usage or

temperature conditions. If Battery fluid comes in contact with skin, wash with soap

and water and rinse with lemon juice and vinegar. If the fluid comes in contact

with eyes, flush with water for several minutes and contact a doctor immediately.

Never burn the Battery, as it can explode in a fire. Do not attempt to charge a

leaking Battery. Contact local solid waste authorities for instructions on correct

disposal or recycling of the Battery.

9. Do not allow children to handle or play with these products.

10. Store idle equipment. When not in use, tools and equipment should be stored

in a dry location to inhibit rust. Always lock up tools and equipment, and keep out

of reach of children.

11. Do not use these products if under the influence of alcohol or drugs. Read

warning labels on prescriptions to determine if your judgement or reflexes are

impaired while taking drugs. If there is any doubt, do not attempt to use these

products.

12. Industrial applications must follow OSHA requirements.

13. Maintain this product with care. Keep these products clean and dry for better

and safer performance.

14. Maintenance: For your safety, service and maintenance should be performed

regularly by a qualified technician.

15. Check for damaged parts. Before using these products, carefully check that

they will operate properly and perform their intended function. Check for

damaged parts and any other conditions that may affect the safe operation of

these products. Replace or repair damaged or worn parts immediately.

16. Replacement parts and accessories: When servicing, use only identical

replacement parts. Only use accessories intended for use with this product.

17. Use the right tool or attachment for the right job. Do not attempt to force a

small tool or attachment to do the work of a larger industrial tool or attachment.

There are certain applications for which these products were designed. They will

do the job better and more safely at the rate for which they were intended. Do

not modify these products, and do not use these products for a purpose for which

they were not intended.

SKU 90374 PAGE 9

18. WARNING! Some dust created by power sanding, sawing, grinding, drilling,

and other construction activities, contain chemicals known (to the State of

California) to cause cancer, birth defects or other reproductive harm. Some

examples of these chemicals are: lead from lead-based paints, crystalline silica

from bricks and cement or other masonry products, arsenic and chromium from

chemically treated lumber. Your risk from these exposures varies, depending on

how often you do this type of work. To reduce your exposure to these chemicals:

work in a well ventilated area, and work with approved safety equipment, such as

those dust masks that are specially designed to filter out microscopic particles.

(California Health & Safety Code 25249.5, et seq.)

19. WARNING! People with pacemakers should consult their physician(s)

before using this product. Operation of electrical equipment in close proximity to

a heart pacemaker could cause interference or failure of the pacemaker.

20. WARNING! The warnings, precautions, and instructions discussed in this

manual cannot cover all possible conditions and situations that may occur. The

operator must understand that common sense and caution are factors which

cannot be built into this product, but must be supplied by the operator.

UNPACKING

When unpacking, check to make sure all the parts shown on the Parts Lists on pages 18,

19, 20, and 21 are included. If any parts are missing or broken, please call Harbor Freight

Tools at the number shown on the cover of this manual as soon as possible.

ASSEMBLY AND OPERATING INSTRUCTIONS

NOTE: For additional information regarding the parts mentioned in the following pages,

refer to the Assembly Diagrams on pages 18, 19, 20, and 22.

SKU 90374 PAGE 10

1. NOTE: The Battery (1A) requires charging. The first charge requires 5 hours

charge time prior to using a cordless tool. (See Figure D, next page.)

2. The Battery (1A) should only be re-charged when the Flashlight Bulb (7C) begins to

dim or a cordless tool begins to run slowly. (See Figure D.)

3. When the Battery (1A) requires re-charging, a 3 to 5 hour charge allows the tool

to operate at full power. Do not re-charge the Battery longer than 5 hours, as

damage to the Battery and/or Flashlight or cordless tool will occur.

(See Figure D.)

Tabla de contenidos

Otros manuales de Perforar de Drill Master

Drill Master

Drill Master 68239 Manual de usuario

Drill Master

Drill Master 66965 Manual de instalación

Drill Master

Drill Master 92383 Manual de usuario

Drill Master

Drill Master 92956 Manual de instalación

Drill Master

Drill Master DRILL MASTER 96526 Manual de instalación

Drill Master

Drill Master 69652 Instrucciones de montaje

Drill Master

Drill Master 91396 Manual de instalación

Drill Master

Drill Master 93440 Manual de usuario

Drill Master

Drill Master 45935 Manual de usuario

Drill Master

Drill Master 3670 Manual de instalación

Drill Master

Drill Master 4285 Manual de usuario

Drill Master

Drill Master 69652 Instrucciones de montaje

Drill Master

Drill Master DrillMaster 68287 Manual de usuario

Drill Master

Drill Master 94436 Manual de instalación

Drill Master

Drill Master 91176 Manual de usuario

Drill Master

Drill Master 3670 Manual de instalación

Drill Master

Drill Master HEAVY-DUTY 1/2" VSR DRILL 3273 Manual de instalación

Drill Master

Drill Master 95622 Manual de usuario

Drill Master

Drill Master 67025 Manual de usuario

Drill Master

Drill Master Drill Master 18V 3/8" 67024 Manual de instalación

Drill Master

Drill Master 90120 Manual de usuario

Drill Master

Drill Master 69947 Manual de usuario

Drill Master

Drill Master 40209 Manual de usuario

Manuales populares de Perforar de otras marcas

Makita

Makita BDF456 Manual de usuario

Black & Decker

Black & Decker LDX220 Manual de usuario

Hitachi

Hitachi DH 40MA Manual de usuario

Challenge

Challenge JO Manual de referencia técnica

Makita

Makita LXFD01 Manual de usuario

Festool

Festool T18+3 Manual de usuario

Milwaukee

Milwaukee M12 FPDX-202X Manual de usuario

EINHELL

EINHELL TE-RH 32 E Manual de usuario

Makita

Makita DHP484 Manual de usuario

Makita

Makita FD05 Manual de usuario

Bosch

Bosch PSB 530 RA Manual de usuario

Maximum

Maximum 054-1359-4 Manual de usuario

Makita

Makita HP332D Manual de usuario

Raider

Raider RDP-HD31H Manual de usuario

Bort

Bort BPM-1400x2 Manual de usuario

Black & Decker

Black & Decker 7266 Manual de usuario

KENT USA

KENT USA TRD1230 Manual de usuario

Bosch

Bosch GSB 19-2 RE Manual de usuario
