Draper MS560/3 Manual de usuario

■STOCK No.57491 ■PART No.MS560/3

•INSTRUCTIONS•

06/99

IMPORTANT: PLEASE READ THESE INSTRUCTIONS

THOROUGHLY BEFORE USE.

UNDERSTANDING HOW THIS MACHINE WORKS AND SETTING IT

CORRECTLY IS FUNDAMENTAL TO OBTAINING

A SATISFACTORY RESULT.

MITRE SAW

MITRE SAW TECHNICAL DATA

COMPONENT PARTS

1. Saw table.

2. Two plastic feet with screw

holes for bench mounting.

3. Saw frame assembly.

4. Two cut depth stops.

5. Guide rods.

6. Washer for pivot arm

(see STEP 1).

7. Pivot arm.

8. Angle indicator.

9. Four grub screws.

10. Hexagon key.

11. Rubber feet.

12. Material vice clamp.

13. Adjustable length stops.

✖✌

✗✌

✙✌

✘✌

✕✖✌

✕✔✌

Specification:

Max. cutting width clamped at 45º.............100mm

Max. cutting width clamped at 90º.............160mm

Max. cutting width unclamped at 90º.........110mm

Max. cutting height.....................................110mm

Blade lengths.............................................560mm

Blade widths 18, 24 TPI...............................40mm

Bow saw ...............................20mm

Table size ..................................76x348mm (WxL)

Max. reach of adjustable length stop....385mm

✕✌

✕✕✌ ✢✌

✕✗✌

✛✌

✚✌

✜✌

PRE-SET ANGLES

ASSEMBLY OF MITRE SAW

ASSEMBLY OF ACCESSORIES

The material vice clamp ✕✖✌ can be mounted on the left or right hand side of the saw

table front for holding workpieces securely.

The adjustable length stop ✕✗✌ can be mounted at either end of the saw table and set

for the required length of cut.

Replacement blades are available from your local Draper stockist;

18TPI - Stock No.57810, 24TPI - Stock No.57811, Bow Saw Blade - Stock No.57812.

STEP 1. STEP 2. STEP 3.

STEP 4. STEP 5. STEP 6.

Turn

5-1/8 turns

✚✌

When fitting blade, always

ensure teeth point forwards.

To get the best from your saw, you must make sure it is correctly set, ensuring the

following points are correct:

(a) The saw blade is tensioned sufficiently to avoid ‘whip’ which will cause the blade to

deviate from a true cut.

(b) The blade is ‘in line’ and central to the frame.

(d) The workpiece is square and true to the base casting.

(e) The correct type of blade is used.

SAFETY FIRST TO AVOID INJURY: Do not remove the blade guard whilst fitting the bow

saw blade to the frame. Refit the blade guard when work is complete and when

removing the blade from the frame.

After assembly has been carefully carried out, always test your mitre saw and the

angles with some scrap timber, to ensure the machine is assembled correctly and

cutting true.

DRAPER TOOLS LIMITED,

Hursley Road, Chandler's Ford,

Eastleigh, Hants. SO53 1YF. England.

Tel: (01703) 266355.

Fax: (01703) 260784.

©Published by Draper Tools Ltd.

No part of this publication may be reproduced,

stored in a retrieval system or transmitted in

any form or by any means, electronic, mechanical

photocopying, recording or otherwise without prior

permission in writing from Draper Tools Ltd.

SAW SETTING

IMPORTANT WARNING
