Dr Zero BM-217A Manual de usuario
Please read all instructions carefully before using
Diagram of name and position of main components
Please Disassemble the blade sets as below steps
Speed I
TOP Cover
Blade
Bowl
Blade supporter
Non-slip mat
Speed II
Motor unit
Left hand holding the bottom
blade, the other part of blade the
insert down near the base
Hold the bottom of the blade
shaft with your left hand and
turn it counter-clockwise
downwards with your right hand
Food Chopper
Model No : BM-217A
1 2
INSTRUCTIONS
18oz Garlic Minced
within 6Seconds
18oz Pumpkin Grinded
within 8Seconds
18oz onion Minced
within 8Seconds
18oz Carrot Chopped
within 15 Seconds
Motor doesn’t start or blade
assembly doesn’t rotate
①Check whether the bottom of pod is clean and ensure no food
blocks connection when placing it on the container.
②There is too much food in the container.
③The unit is overheated, Unplug and wait for about 15 minutes
before pod is securely placed on the lid.
④Check whether the plug is securely inserted into the electrical outlet.
1. Before use, clean the glass jar, blade and top cover.
2. Take off the main machine and top cover, place the meat in
clean place.
3. Place the blade on the blade supporter.
4. Please make sure that the blade is on the blade supporter
after put in the foods.
5. Place the top cover, and then the motor unit, and make sure
they are in correct position.
6. Insert the plug, and switch on the power.
7. Hold the motor unit with your hand, and press the button to
start running. Rlease the button to stop running.
8. After release the switch, please do not remove the motor unit
immediately, wait until the blade stops rotating and then cut
off the power, remove the motor unit.
9. Blades are very sharp, in order to avoid injury, please take out
the blade firstly, and then take out the foods.
CAUTION: To protect against bowl from heat deformation
and leak, do not put hot water or food which the temperature
is higher than 70℃.
Maybe you’ve chopped too much food at one time, or the pieces
are too big.Cut the food into smaller pieces. Chop smaller amounts
per batch.
The food has been over processed. Use brief pulses or process the
food for a shorter time. Let the chopping blade assembly stops
completely between pulses.
Food is unevenly chopped
Food is chopped too fine or
too watery
18oz Meat Minced
within 10 Seconds
18oz Nut Minced
within 8Seconds
For Sorft Food
For Hard Food
Problems Possible Reasons/Solutions
