Downee Sprint Gate Solar Series Manual
1
sprint
gate
solar
Install Manual
1.06.17
2
Video instructions are
on downee.com.au.
Page
Kit Parts 2
Purchase Separately 3
Motor 4
Battery Box 6
Solar Panel Post 6
Solar Panel 7
Gate Stops 7
Power Up 8
Programming 9
Connect Aerial 10
Connect Remotes 10
Set Solar Mode 11
Accessories 11
Solar Controller 12
Solar Gates In Winter 13
Solar Angles 13
trouble
shooting
1800 241 733
Call our Tech Team
1
3
2
7
4
6
5
kit parts
3
Post Cap not supplied. Grab
one to match the gate post
Solar Panel is mounted on.
Battery Box mounts not
supplied. Two pieces of
25mm steel angle will work.
S8-AT
G7-BBAT
HIGHLY RECOMMENDED
Automatic gates need
hinges able to handle the
motor’s forces. Made in
Australia for Sprint Gate.
purchase separately
24V
MOTOR
& KEY
REMOTES
SOLAR
PANEL
BOOSTER
AERIAL
SOLAR
PANEL
POST
SOLAR
CONTROLLER
MOTOR-TO-POST
BRACKET
ARM-TO-GATE
ROTATING BRACKET
12V
BATTERIES
BATTERY BOX
& KEY
1 2 3
456
7
kit parts
(pre-wired) (pre-wired) (pre-wired)
(pre-wired)
(pre-wired)
Bugs and insects in gate
motors will cause problems.
Use silicone to seal where
cables enter the base of motor.
4
EXISTING GATES
Check gates are in excellent operating condition. Gates & hinges in poor
condition will give you trouble and prematurely wear the motor.
TIPS • Can be mounted on left or right post.
• Best motor position is half-way up gate post.
motor
1
2
3
Pin all arms sections together.
Fit arm to motor.
Extend arm.
NOTE
Stay
Frame
Mount the motor where the arm meets the gate stay. Next best option is
the gate frame.
NOTE
Close gates.
Mark posts at base where
motor will be mounted.
5
4
5
Adjust post bracket to t gate post.
Mount post bracket as shown, with bottom edge on mark. (See previous page)
6Bolt motor to post bracket. Tighten arm on motor.
7
GATE THIS
SIDE >>>>
Arm
Play around to set the rotating bracket to the gate stay/frame.
Then attach it to arm pivot.
Pivot
6
battery box
1Mount an angle bracket to gate post,
with the solar panel.
2Attach other angle bracket to battery box brackets (above).
Sit box on bottom bracket and attach top bracket to post.
Open battery box to remove foam packing.
Fit fuse into fuse holder.
3
solar panel post
1
2
Drill a hole in centre of post cap and bolt it onto the panel post.
Place cap & panel post on gate post. It may be tight and need
some encouragement with a rubber mallet. A couple of self
tappers will hold cap in place.
Battery Box
Steel post cap not supplied in kit. Measure diameter of post
to match cap. Downee caps avail. to 150mm.
NOTE
Position bolt holes east-west for the solar panel to face north.
3
TIPS • Keep the solar panel box. You’ll need it a bit later.
• Not sure which direction north sits? Download a free
compass app onto your smart phone.
Panel Post
East-West
Battery Box
Gate Post
Angle
Mount brackets not supplied. Good old steel angle does the job.
NOTE
7
solar panel
Set solar panel angle for maximum
charge. More locations on page 13.
PANEL
ANGLE
90
0
80
70
60
50
40
30
20
10
Leave box on the panel. Bolt solar panel (facing north) to the panel post.
1
2
Unlock motor arm.
Close gate.
gate stops
1
2
3Adjust stops as needed, then tighten.
Key
Stop
Place a stop where arm will sit against it when
closed.
TIP If tree shade covers the solar panel between 9am – 3pm it can seriously
reduce the battery charge. Even if just for a short time.
Solar panel shouldn’t be covered by tree shade.
Panel can be placed in a full-sun position up to 30m* away from the gate.
*use low voltage cable (2-core + earth 2.5mm2).
Tek screw aerial to top of solar panel frame.
TIP We strongly recommend physical stops in open & closed positions.
They remove a lot of stresses from the motor. A piece of angle works
justneasaground-stop.
We strongly recommend the use of a physical stop on both the open
& close.
8
power up
1
4
2
3
Control
Board
Remove motor cover, and control board cover.
Remove existing black wires from
22VAC INPUT terminals. Pull them
through, out of the way.
Connect the brown-blue wires from
the battery into the 22VAC INPUT
terminals.
Control Board
22VAC
INPUT
5Cover solar panel, connect black-red power
cables to Solar Panel and Batteries. Motor’s
control board plus solar controller are now
active. Controller may need to be turned on.
Cable tie the power cables against post.
Thread battery cable and aerial coaxial cable through the hole.
Strip the ends of cables.
Seal hole with silicone sealer. This will avoid problems caused when insects
nest in the motor.
TIP
Motor bottom view
Punch a hole in the grommet on motor base.
Grommet
9
programming
Scroll up
Programming
Buttons
OK
Scroll down
Digital
Display
Control Board
Arm lock key
Position gate half-way between open
closed. Lock arm with key (shown)
1
2Scroll to shows on display.
Press middle button once. ashes.
4
3
5
6
Press & hold the middle button till stops ashing.
Gate will automatically open & close to search for gate stops.
Gate should nish in closed position.
8888p003
8888app
8888app
The symbol for ‘Gate Closed’ shows when it’s nished.
If ‘Gate Open’ symbol appears
scroll to & press OK. Change parameter to 8888
1
00
8888
p 3
06
8888----
8888- -
10
Scroll to & press OK
When shows, press any button on rst remote.
= remote connected.
Within 8 seconds...
When shows, press second remote.
= second remote connected.
Wait 10sec. for the symbol to conrm memory process is complete.
Aerial
Terminals
Control Board
connect remotes
1
2
connect aerial
1
2
3
8888p005
8888le
a
8888
000
8888
00 1
8888
____
8888le
a
Thread coaxial cable through grommet in motor base.
Motor bottom view
Grommet
Strip black outer cable approx. 50mm.
Separate inner & outer wires.
Twist outer wire.
Strip end o clear insulation.
Trim inner and outer cable to same length.
4Completely seal the grommet with silicone sealant.
Connect both ends of coaxial in aerial terminals.
