ENGINEERING OPERATION

MAINTENANCE MANUAL

PR260

Bolted Metal Pump

WIL-11710-E-02 2

PR260 Bolted Metal

PSG reserves the right to modify the information and illustrations in this document without prior

notice. The product described in this document is furnished under a license agreement or

nondisclosure agreement. No part of this document may be reproduced, stored in a retrieval

system, or transmitted in any form or any means electronic or mechanical, including

photocopying and recording, without the written permission of PSG, a Dover Company, except

as described by the terms of those agreements.

This is a non-contractual document.

Trademarks

PSG and the PSG logo are registered trademarks of PSG. Wilden®is a registered trademark of

PSG California LLC. Pro-Flo®SHIFT and Pro-Flo®are registered trademarks of PSG California

LLC. Wil-Flex®is a trademark of PSG California LLC. Saniflex™ is a trademark of PSG

California LLC.

All trademarks, names, logos and service marks (collectively “trademarks”) in this document are

registered and unregistered trademarks of their respective owners. Nothing contained in this

document should be construed as granting any license or right to use any trademark without the

prior written permission of the trademark owner.

Warranty

Each and every product manufactured by Wilden is built to meet the highest standards of

quality. Every pump is functionally tested to ensure integrity of operation. Wilden warrants that

pumps, accessories and parts manufactured or supplied by it to be free from defects in material

and workmanship for a period of five (5) years from date of installation or six (6) years from date

of manufacture, whichever comes first.

For more information, and to register your Wilden pump for warranty, please visit

https://www.psgdover.com/wilden/support/warranty-registration.

Certifications

WIL-11710-E-02 3

PR260 Bolted Metal

CONTENTS

SECTION 1: Precautions –Read First!....................................................................................4

SECTION 2: Wilden Pump Designation System......................................................................5

SECTION 3: How It Works ........................................................................................................6

SECTION 4: Dimensional Drawings.........................................................................................7

SECTION 5: Performance.........................................................................................................8

PR260 Metal Rubber-Fitted ...................................................................................9

PR260 Metal TPE-Fitted........................................................................................9

PR260 Metal Full-Stroke PTFE-Fitted..................................................................10

PR260 Metal Reduced-Stroke PTFE-Fitted..........................................................10

Suction Lift Capability ..........................................................................................11

SECTION 6: Suggested Installation, Operation, Maintenance, and Troubleshooting........12

SECTION 7: Disassembly/Reassembly..................................................................................15

Pump Disassembly..............................................................................................15

Air Valve Disassembly.........................................................................................18

Reassembly Hints and Tips .................................................................................21

SECTION 8: Exploded View and Parts List ...........................................................................22

SECTION 9: Elastomer Options .............................................................................................25

WIL-11710-E-02 4

PR260 Bolted Metal

SECTION 1

WARNING: Always wear safety glasses when operating

a pump to avoid eye injury. If diaphragm rupture occurs,

material being pumped may be forced out of the air

exhaust.

CAUTION: Do not apply compressed air to the exhaust

port –pump will not function.

CAUTION: Do not over-lubricate air supply–excess

lubrication will reduce pump performance. Pump is pre-

lubed.

TEMPERATURE LIMITS:

Acetal

-29° C to82°C

-20° F to180° F

Buna-N

-12° C to82°C

10° F to 180° F

Geolast®

-40° C to82°C

-40° F to180° F

Neoprene

-18° C to93°C

0° F to 200° F

Nordel EPDM

-51° C to 138° C

-60° F to 280° F

Nylon

-18° C to93°C

0° F to 200° F

PFA

-7° C to 107° C

45° F to 225° F

Polypropylene

0° C to79°C

32° F to 175° F

Polyurethane

-12° C to66°C

10° F to150° F

PVDF

-12° C to 107° C

10° F to225° F

Saniflex

-29° C to 104° C

-20° F to220° F

SIPD PTFE with EPDM-backed

4° C to137° C

40° F to 280° F

SIPD PTFE with Neoprene-backed

4° C to93° C

40° F to200° F

PTFE*

4° C to104° C

40° F to220° F

FKM

-40° C to 177° C

-40° F to350° F

Wil-Flex

-40° C to 107° C

-40° F to225° F

*4° C to 149° C (40° F to 300° F) - 13 mm (1/2") and 25 mm (1") models

only.

NOTE: Not all materials are available for all models. See “Wilden

Pump Designation System”for material options for your pump.

CAUTION: When choosing pump materials, be sure to

check the temperature limits for all wetted components.

Example: FKM has a maximum limit of 177° C (350° F),

but polypropylene has a maximum limit of only 79° C

(175° F).

CAUTION: Pump surfaces may exceed 80° C (176° F),

contact will result in burns, scalds, and other injuries.

Surface temperature is dependent on the temperature of

the process fluid.

CAUTION: Maximum temperature limits are based on

mechanical stress only. Certain chemicals will reduce

maximum safe operating temperatures significantly.

Consult the Chemical Resistance Guide for chemical

compatibility and temperature limits.

CAUTION: All Wilden pumps are capable of passing

solids. Use a strainer on the pump intake to ensure that

the pump's rated solids capacity is not exceeded.

CAUTION: Do not exceed 8.6 bar (125 psig) air supply

pressure.

CAUTION: Do not exceed 82° C (180° F) air inlet

temperature for all models.

CAUTION: The process fluid and cleaning fluids must be

compatible chemically with all wetted pump components.

CAUTION: Before attempting any maintenance or repair,

disconnect the compressed air line to the pump and allow

all air pressure to bleed from the pump. Disconnect all

intake, discharge, and air lines. Drain the pump by turning

it upside down and allowing any fluid to flow into a

suitable container. Be aware of any hazardous effects of

contact with your process fluid.

CAUTION: Thoroughly flush pumps before installing

them into process lines. Clean and/or sanitize FDA- and

USDA- approved pumps before using them.

CAUTION: Before attaching the air line to the pump, blow

out the air line for 10 to 20 seconds to make sure all

pipeline debris is clear. Use an in-line air filter. A 5µ

(micron) air filter is recommended.

CAUTION: Pro-Flo R pumps can be used in submersible

applications when using the Pro-Flo R submersible

option.

CAUTION: Before installation, tighten all hardware.

NOTE: Materials of construction and elastomer material

may influence suction lift parameters. Please refer to

“Performance”for specifics.

NOTE: When installing PTFE diaphragms, it is important

to tighten outer pistons simultaneously (turning in

opposite directions) to ensure tight fit. (See “Maximum

Torque Specifications”).

NOTE: Some PTFE-fitted pumps come standard from the

factory with expanded PTFE gaskets installed in the

diaphragm bead of the liquid chamber. PTFE gaskets

cannot be re-used.

NOTE: In the event of a power failure, close the shut-off

valve if you do not want the pump to restart when the

power returns.

NOTE: The Safety Supplement document is a part of the

manual. Please refer to the Safety Supplement document

for a complete list of safety considerations including

considerations for safe operation and maintenance of

pumps marked for ATEX environments before starting the

pump.

PRECAUTIONS –READ FIRST!

WIL-11710-E-02 5

PR260 Bolted Metal

SECTION 2

MATERIAL CODES

MODEL

XPR260 = PRO-FLO®R ATEX

THREADED PORTS

PR260 = PRO-FLO®R

THREADED PORTS

WETTED PATH

A = ALUMINUM

S = STAINLESS STEEL

OUTER PISTON

A = ALUMINUM

S = STAINLESS STEEL

CENTER SECTION

AA = ALUMINUM

AIR VALVE

A = ALUMINUM

DIAPHRAGMS

BNS = BUNA-N (RED DOT)

NES = NEOPRENE (GREEN DOT)

TWS = FULL-STROKE PTFE

W/WIL-FLEX™ BACK-UP

VTS = FKM (WHITE DOT)

WFS= WIL-FLEX™ [SANTOPRENE®

(THREE BLACK DOTS)]

TNU = PTFE w/NEOPRENE

BACKUP

VALVE BALLS

BN = BUNA-N (RED DOT)

NE = NEOPRENE (GREEN DOT)

TF = PTFE (WHITE)

VT = FKM (WHITE DOT)

WF = WIL-FLEX™ [SANTOPRENE®

(THREE BLACK DOTS)]

VALVE SEATS

A = ALUMINUM

S = STAINLESS STEEL

VT = FKM (WHITE DOT)

WF = WIL-FLEX™ [SANTOPRENE®

(THREE BLACK DOTS)]

VALVE SEAT O-RINGS

BN = BUNA-N (RED DOT)

NE = NEOPRENE (GREEN DOT)

TF = PTFE (WHITE)

VT = FKM (WHITE DOT)

WF = WIL-FLEX™ [SANTOPRENE®

(THREE BLACK DOTS)]

SPECIALTY CODES

0014 BSPT

0677 25 mm (1") NPT center-ported inlet and discharge manifold (only for Aluminum)

0678 25 mm (1") BSPT center-ported inlet and discharge manifold (only for Aluminum)

NOTE: Most elastomeric materials use colored dots for identification

NOTE: Not all models are available with all material options

PR260 METAL

LEGEND

XPR

260

25 mm (1") Pump

Maximum Flow Rate:

182 lpm (48 gpm)

O-RINGS

MODEL

VALVE SEATS

SPECIALTY

VALVE BALLS

CODE

DIAPHRAGMS

AIR VALVE

CENTER SECTION

OUTER PISTON

WETTED PATHS

WILDEN PUMP DESIGNATION SYSTEM

(if applicable)

WIL-11710-E-02 6

PR260 Bolted Metal

SECTION 3

The Wilden diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show flow pattern through the pump

upon its initial stroke. It is assumed the pump has no fluid in it prior to its initial stroke.

FIGURE 1 The air valve directs pressurized air to

the back side of diaphragm A. The compressed

air is applied directly to the liquid column

separated by elastomeric diaphragms. The

diaphragm acts as a separation membrane

between the compressed air and liquid; a

balanced load removes mechanical stress from

the diaphragm. The compressed air moves the

diaphragm away from the center of the pump.

The opposite diaphragm is pulled in by the shaft

connected to the pressurized diaphragm.

Diaphragm B is on its suction stroke; air behind

the diaphragm has been forced out to

atmosphere through the exhaust port of the

pump. The movement of diaphragm B toward the

center of the pump creates a vacuum within

chamber B. Atmospheric pressure forces fluid

into the inlet manifold forcing the inlet valve ball

off its seat. Liquid is free to move past the inlet

valve ball and fill the liquid chamber (see shaded

area).

FIGURE 2 When the pressurized diaphragm,

diaphragm A, reaches the limit of its discharge

stroke, the air valve redirects pressurized air to

the back side of diaphragm B. The pressurized

air forces diaphragm B away from the center

while pulling diaphragm A to the center.

Diaphragm B is now on its discharge stroke.

Diaphragm B forces the inlet valve ball onto its

seat due to the hydraulic forces developed in the

liquid chamber and manifold of the pump. These

same hydraulic forces lift the discharge valve ball

off its seat, while the opposite discharge valve

ball is forced onto its seat, forcing fluid to flow

through the pump discharge. The movement of

diaphragm A toward the center of the pump

creates a vacuum within liquid chamber A.

Atmospheric pressure forces fluid into the inlet

manifold of the pump. The inlet valve ball is

forced off its seat allowing the fluid being pumped

to fill the liquid chamber.

FIGURE 3 At completion of the stroke, the air

valve again redirects air to the back side of

diaphragm A, which starts diaphragm B on its

exhaust stroke. As the pump reaches its original

starting point, each diaphragm has gone through

one exhaust and one discharge stroke. This

constitutes one complete pumping cycle. The

pump may take several cycles to completely

prime depending on the conditions of the

application.

The Pro-Flo®R air distribution system incorporates two

moving parts: the air valve spool and the pilot spool. The heart of

the system is the air valve spool and air valve. This valve design

incorporates an unbalanced spool. The smaller end of the spool

is pressurized continuously, while the large end is alternately

pressurized then exhausted to move the spool. The spool directs

pressurized air to one air chamber while exhausting the other.

The air causes the main shaft/diaphragm assembly to shift to

one side —discharging liquid on that side and pulling liquid in

on the other side. When the shaft reaches the end of its stroke,

the inner piston actuates the pilot spool, which pressurizes and

exhausts the large end of the air valve spool. The repositioning

of the air valve spool routes the air to the other air chamber.

HOW IT WORKS –AIR-OPERATED DOUBLE-DIAPHRAGM PUMP

HOW IT WORKS –AIR DISTRIBUTION SYSTEM

WIL-11710-E-02 7

PR260 Bolted Metal

SECTION 4

PR260 METAL

DIMENSIONS

ITEM

METRIC

(mm)

STANDARD

(inch)

270

10.6

1.4

183

7.2

323

12.7

347

13.7

1.9

335

13.2

2.8

140

5.5

177

165

6.5

132

5.2

104

4.1

127

5.0

0.4

TJPR260-01 REV. A

PR260 METAL –CENTER-PORTED

DIMENSIONS

ITEM

METRIC

(mm)

STANDARD

(inch)

331

13.1

1.4

183

7.2

324

12.8

348

13.7

1.2

335

13.2

2.8

140

5.5

178

7.0

165

6.5

132

5.2

104

4.1

127

5.0

0.4

TJPR260-02 REV. A

DIMENSIONAL DRAWING

WIL-11710-E-02 8

PR260 Bolted Metal

PR260 STAINLESS STEEL

DIMENSIONS

ITEM

METRIC

(mm)

STANDARD

(inch)

246

9.7

1.4

183

7.2

323

12.7

347

13.7

210

8.3

123

4.8

335

13.2

2.8

140

5.5

177

165

6.5

132

5.2

105

4.1

127

0.5

TJPR260-03 REV. A

DIMENSIONAL DRAWING

WIL-11710-E-02 9

PR260 Bolted Metal

SECTION 5

PR260 METAL

RUBBER-FITTED

Ship Weight…………..Aluminum 10 kg (22 lb)

316 Stainless Steel 15 kg (33 lb)

Air Inlet……………………………………….1/2"

Inlet...………………………………...25 mm (1")

Outlet………………………………...25 mm (1")

Suction Lift………..…………..6.9 m Dry (22.7′)

9.0 m Wet (29.5′)

Disp. per Stroke1……………....0.3 L (0.08 gal)

Max. Flow Rate……...……180 lpm (47.5 gpm)

Max. Size Solids…………………3.2 mm (1/8")

1Displacement per stroke was calculated at 4.8

bar (70 psig) air inlet pressure against a 2.1 bar

(30 psig) head pressure.

Example: To pump 72.7 lpm (19.2 gpm)

against a discharge pressure head of 3.4 bar

(50 psig) requires 4.1bar (60 psig) and

32.3Nm3/h (19 scfm) air consumption.

(See dot on chart.)

Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps

should be specified so that daily operation parameters will fall in the center of the pump's performance curve.

Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PR260 METAL

TPE-FITTED

Ship Weight…………..Aluminum 10 kg (22 lb)

316 Stainless Steel 15 kg (33 lb)

Air Inlet……………………………………….1/2"

Inlet...………………………………...25 mm (1")

Outlet………………………………...25 mm (1")

Suction Lift………..…………..4.2 m Dry (13.7′)

9.0 m Wet (29.5′)

Disp. per Stroke1……………....0.3 L (0.08 gal)

Max. Flow Rate…………..…182 lpm (48 gpm)

Max. Size Solids…………………3.2 mm (1/8")

1Displacement per stroke was calculated at 4.8

bar (70 psig) air inlet pressure against a 2.1 bar

(30 psig) head pressure.

Example: To pump 75 lpm (19.8 gpm)

against a discharge pressure head of 2.1 bar

(30 psig) requires 2.8bar (40 psig) and

24Nm3/h (14.3 scfm) air consumption.

(See dot on chart.)

Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps

should be specified so that daily operation parameters will fall in the center of the pump's performance curve.

Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PERFORMANCE

WIL-11710-E-02 10

PR260 Bolted Metal

PR260 METAL

FULL-STROKE

PTFE-FITTED

Ship Weight…………..Aluminum 10 kg (22 lb)

316 Stainless Steel 15 kg (33 lb)

Air Inlet……………………………………….1/2"

Inlet...………………………………...25 mm (1")

Outlet………………………………...25 mm (1")

Suction Lift………….…………..4.9 m Dry (16′)

9.3 m Wet (30.6′)

Disp. per Stroke1……………....0.3 L (0.08 gal)

Max. Flow Rate………..…172 lpm (45.5 gpm)

Max. Size Solids…………………3.2 mm (1/8")

1Displacement per stroke was calculated at 4.8

bar (70 psig) air inlet pressure against a 2.1 bar

(30 psig) head pressure.

Example: To pump 60 lpm (15.8 gpm)

against a discharge pressure head of 3.4 bar

(50 psig) requires 4.1bar (60 psig) and 28.9

Nm3/h (17 scfm) air consumption.

(See dot on chart.)

Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps

should be specified so that daily operation parameters will fall in the center of the pump's performance curve.

Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PR260 METAL

REDUCED-STROKE

PTFE-FITTED

Ship Weight…………..Aluminum 10 kg (22 lb)

316 Stainless Steel 15 kg (33 lb)

Air Inlet……………………………………….1/2"

Inlet...………………………………...25 mm (1")

Outlet………………………………...25 mm (1")

Suction Lift………….………..2.8 m Dry (9.2′)

9.0 m Wet (29.5′)

Disp. per Stroke1……………....0.3 L (0.08 gal)

Max. Flow Rate………..…161 lpm (42.5 gpm)

Max. Size Solids…………………3.2 mm (1/8")

1Displacement per stroke was calculated at 4.8

bar (70 psig) air inlet pressure against a 2.1 bar

(30 psig) head pressure.

Example: To pump 70.4 lpm (18.6 gpm)

against a discharge pressure head of 2.8 bar

(40 psig) requires 4.1bar (60 psig) and 39

Nm3/h (23 scfm) air consumption.

(See dot on chart.)

Flow rates indicated on chart were determined by pumping water. For optimum life and performance, pumps

should be specified so that daily operation parameters will fall in the center of the pump's performance curve.

Caution: Do not exceed 8.6 bar (125 psig) air supply pressure.

PERFORMANCE

Tabla de contenidos

Otros manuales de Bomba de agua de Dover

Dover

Dover PSG Wilden PRO-FLO P2 Manual de instrucciones

Dover

Dover MOUVEX A20 Manual de usuario

Dover

Dover PSG ALL-FLO A300 Manual del propietario

Dover

Dover PSG Wilden SANIFLO H1500 HYGIENIC Series Manual de usuario

Dover

Dover HydroSystems Superdos 15 0.3 Manual de usuario

Dover

Dover PSG WILDEN PS4 Series Manual de instrucciones

Dover

Dover PSG ALL-FLO A150 Manual de instrucciones

Dover

Dover Blackmer LGL3021A Manual

Dover

Dover PSG WILDEN PR870 Manual de instrucciones

Dover

Dover PSG ALL-FLO IOM A100 Series Manual del propietario

Dover

Dover PSG ALL-FLO F150 Manual del propietario

Dover

Dover PSG WILDEN SANIFLO PS2 Series Manual de instrucciones

Dover

Dover PSG ALL-FLO C150 Manual del propietario

Dover

Dover PSG WILDEN PS810 Manual de instrucciones

Dover

Dover DOVER PSG WILDEN PRO-FLO XPS820 AAAAA Series Guía de instalación

Dover

Dover PSG ALL-FLO IOM A025 Series Manual del propietario

Dover

Dover PSG Blackmer LGL154A Manual

Dover

Dover BLACKMER CRLR1.25 Manual

Dover

Dover Wilden Original PV20 Manual de instrucciones

Dover

Dover Wilden Saniflo Hygienic Series Manual de usuario

Dover

Dover PSG ALL-FLO A050 Manual del propietario

Dover

Dover Wilden Advanced Series Manual de instrucciones

Dover

Dover PSG All-Flo A075-NAA-VVYV-A30 Manual del propietario

Dover

Dover PSG All-Flo A025-SQ Manual de usuario

Manuales populares de Bomba de agua de otras marcas

Neptun

Neptun NPHW 5500 Manual de usuario

Sensidyne

Sensidyne Gilian BDX-II Instrucciones de instalación y funcionamiento

Draper

Draper 47808 Manual de usuario

Trolla

Trolla 12820 Manual de usuario

Sunfab

Sunfab SVH Series Manual de usuario

WilTec

WilTec 50740 Manual de usuario

Fieldmann

Fieldmann FVC 5015 EK Manual de usuario

Everbilt

Everbilt EFSUB5-122HD Manual de usuario

Graco

Graco Husky 3300e Manual de usuario

esotec

esotec 101018 Manual de usuario

moyno

moyno 2000 CC Manual de usuario

Becker

Becker BASIC VASF 2.80/1-0.AC230 Manual de usuario

Sykes AmeriPumps

Sykes AmeriPumps GP100M Guía de solución de problemas

DUROMAX

DUROMAX XP WX Series Manual de usuario

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 Manual de usuario

Franklin Electric

Franklin Electric IPS Manual de usuario

Xylem

Xylem e-1532 Series Manual de usuario

Milton Roy

Milton Roy PRIMEROYAL Manual de usuario
