Dometic CDF-11 Manual de usuario

CDF11

Compressor bordbar

Operating manual

COOLING BOXES

BORDBAR

CDF11-O-AU.book Seite 1 Freitag, 7. Oktober 2016 12:45 12

CDF11-O-AU.book Seite 2 Freitag, 7. Oktober 2016 12:45 12

BordBar CDF11

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is passed on to

another person, this operating manual must be handed over to the user

along with it.

The manufacturer cannot be held liable for damage resulting from improper usage

or incorrect operation.

Contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

9 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

CDF11-O-AU.book Seite 3 Freitag, 7. Oktober 2016 12:45 12

Explanation of symbols BordBar CDF11

1 Explanation of symbols

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

CDF11-O-AU.book Seite 4 Freitag, 7. Oktober 2016 12:45 12

BordBar CDF11 Safety instructions

2 Safety instructions

2.1 General safety

!WARNING!

•Do not operate the device if it is visibly damaged.

•If this device's power cable is damaged, it must be replaced by the

manufacturer, customer service or a similarly qualified person in order

to prevent safety hazards.

•This device may only be repaired by qualified personnel. Improper

repairs can lead to considerable hazards.

•This device can be used by children aged 8 years or over, as well as by

persons with diminished physical, sensory or mental capacities or a

lack of experience and/or knowledge, providing they are supervised

or have been taught how to use the device safely and are aware of the

resulting risks.

•Cleaning and user maintenance must not be carried out by children

without supervision.

•Children must not play with the device.

•Children must be supervised to ensure that they do not play with the

device.

•Always keep and use the device out of the reach of children under the

age of 8 years.

•Do not store any explosive substances such as spray cans with a

flammable propellant in the device.

!CAUTION!

•Disconnect the device from the power supply

– before each cleaning and maintenance

– after every use

•Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

•Check that the voltage specification on the type plate corresponds to

that of the energy supply.

•Only connect the device to a DC plug socket in the vehicle (e. g.

cigarette lighter) with the DC cable.

CDF11-O-AU.book Seite 5 Freitag, 7. Oktober 2016 12:45 12

Safety instructions BordBar CDF11

•Only connect the device as follows:

– With the DC cable to a DC plug socket in the vehicle (e. g.

cigarette lighter)

– Or with the 230 V connection cable to the 230 V AC mains supply

•Connect the device with the 230 V connection cable to the 230 V

mains supply.

•Never pull the plug out of the socket by the cable.

•If the cooler is connected to the DC socket: Disconnect the cooler and

other power consuming devices from the battery before connecting

the quick charging device.

•If the cooler is connected to the DC socket: Disconnect the cooler or

switch it off when you turn off the engine. Otherwise you may dis-

charge the battery.

•The cooling device is not suitable for transporting caustic materials or

materials containing solvents.

•The cooling device contains inflammable cyclopentane in the

insulation. The gases in the insulation material require special disposal

procedures. Deliver the device at the end of its life-cycle to an appro-

priate recycling.

2.2 Operating the device safely

!CAUTION!

•Before starting the device, ensure that the power supply line and the

plug are dry.

ANOTICE!

•Do not use electrical devices inside the cooler unless they are

recommended by the manufacturer for the purpose.

•Do not place the device near naked flames or other heat sources

(heaters, direct sunlight, gas ovens etc.).

•Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the heat that

arises during operation does not build up. Make sure that the device

is sufficiently far away from walls and other objects so that the air can

circulate.

•Ensure that the ventilation openings are not covered.

•Do not fill the inner container with ice or fluid.

•Never immerse the device in water.

CDF11-O-AU.book Seite 6 Freitag, 7. Oktober 2016 12:45 12

BordBar CDF11 Intended use

•Protect the device and the cable against heat and moisture.

3 Intended use

The cooler CDF11 (ref. no. 9105303076) is suitable for cooling and freezing

foodstuffs.

The device has been designed for use with a 12/24 Vgon-board power supply

socket of a car (cigarette lighter) or caravan.

The appliance may also be used for camping use. The appliance shall not be

exposed to rain.

4Scopeofdelivery

•Cooling device

•Connection cable for 12/24 Vgconnection

•Carry strap

NOTICE!

If you wish to cool medicines, please check if the cooling capacity of the

device is suitable for the medicine in question.

NOTE

To operate the device using a 220 – 240 Vwmains supply, we

recommend using a rectifier (accessory).

CDF11-O-AU.book Seite 7 Freitag, 7. Oktober 2016 12:45 12

Technical description BordBar CDF11

5 Technical description

The cooler can chill products, keep them cool as well as freeze them. A

maintenance-free refrigerant circuit with compressor provides the cooling.

The cooler is suitable for mobile use.

When used in vehicles the cooler can be secured with the seat belt.

If an error occurs within the interior electronics, the cooling can be kept by using an

emergency switch.

5.1 Description of the device

EMERGENCY OVERRIDE

NORMAL USE

10 9

23 4567

CDF11-O-AU.book Seite 8 Freitag, 7. Oktober 2016 12:45 12

BordBar CDF11 Technical description

Item Description

1 Control panel

2Cupholder

3 Fixing position for seat belt

4 Interior LED light

5 Cooling compartment

6 Freezer compartment

7 Lock

8 Skid proof pad

9Handles

10 Carry strap

11 Connection socket

12 Emergency switch

CDF11-O-AU.book Seite 9 Freitag, 7. Oktober 2016 12:45 12

Technical description BordBar CDF11

5.2 Control panel

Item Description Explanation

1 On/Off button Switches the cooler on or off when the button is pressed for

between one and two seconds

2 POWER Status indication

LED lights up green Compressor is on; preset

temperature isn’t reached

yet

LED lights up orange Preset temperature is

reached

LED flashes orange Insufficient voltage

3 ERROR LED flashes red Device is switched on but

not ready for operation

4 SET Selects the input mode

•Set Temperature

•Set temperature unit (Celsius or Fahrenheit)

•Set battery monitor

5 Display Shows the temperature inside the cooling compartment

The first three digits of the four-digit display show the

temperature, the fourth digit shows the temperature unit (°C

or °F).

In case of an error the display shows the error message

“Err1” or “Err2”.

6 + Press once to increase the value

7 – Press once to decrease the value

POWER

FRIDGE FREEZER

ERROR

SET

12 34 5 6 7

CDF11-O-AU.book Seite 10 Freitag, 7. Oktober 2016 12:45 12
