TropiCool TC07 AC/DC

EN 13 Thermoelectric cooler

Installation and Operating Manual

Autogoods “130”

130.com.ua

TC07

12 Vg

Autogoods “130”

130.com.ua

TC07 Explanation of symbols

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is passed on to

another person,this operating manual must be handed overto the user

along with it.

The manufacturer cannot be held liable for damage resulting from

improper usage or incorrect operation.

Contents

1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

7 Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

1 Explanation of symbols

DANGER!

Safety instruction: Failure to observe this instruction will cause

fatal or serious injury.

WARNING!

Safety instruction: Failure to observe this instruction can cause

fatal or serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to

injury.

Autogoods “130”

130.com.ua

Safety instructions TC07

➤Action: This symbol indicates that action is required on your part. The

required action is described step-by-step.

✓This symbol describes the result of an action.

Fig. 15, page 3: This refers to an element in an illustration. In this case,

item 5 in figure 1 on page 3.

2 Safety instructions

2.1 General safety

DDANGER!

On boats: If the appliance is powered by the mains, ensure that

the power supply has a residual current circuit breaker.

!WARNING!

Do not operate the device if it is visibly damaged.

If this device's power cable is damaged, it must be replaced by

the manufacturer, customer service or a similarly qualified

person in order to prevent safety hazards.

This device may only be repaired by qualified personnel.

Improper repairs can lead to considerable hazards.

This device can be used by children aged 8 years or over, as

well as by persons with diminished physical, sensory or mental

capacities or a lack of experience and/or knowledge, providing

they are supervised or have been taught how to use the device

safely and are aware of the resulting risks.

Cleaning and user maintenance must not be carried out by

children without supervision.

Children must not play with the device.

NOTICE!

Failure to observe this instruction can cause material damage and

impair the function of the product.

NOTE

Supplementary information for operating the product.

Autogoods “130”

130.com.ua

TC07 Safety instructions

Children must be supervised to ensure that they do not play with

the device.

Always keep and use the device out of the reach of children

under the age of 8 years.

Do not store any explosive substances such as spray cans with

a flammable propellant in the device.

!CAUTION!

Disconnect the device from the mains

– before each cleaning and maintenance

– after every use

Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

Check that the voltage specification on the type plate

corresponds to that of the energy supply.

Only connect the device as follows:

– With the DC cable to a DC plug socket in the vehicle (e. g.

cigarette lighter)

– Or with the 230 V connection cable to the 230 V AC mains

supply

Never pull the plug out of the socket by the cable.

If the cooler is connected to the DC socket: Disconnect the

cooler and other power consuming devices from the battery

before connecting the quick charging device.

If the cooler is connected to the DC socket: Disconnect the

cooler or switch it off when you turn off the engine. Otherwise

you may discharge the battery.

The cooling device is not suitable for transporting caustic

materials or materials containing solvents.

2.2 Operating the device safely

DDANGER!

Do not touch exposed cables with your bare hands. This

especially applies when operating the device with an AC mains

power supply.

Autogoods “130”

130.com.ua

Scope of delivery TC07

!CAUTION!

Before starting the device, ensure that the power supply line

and the plug are dry.

ANOTICE!

Do not use electrical devices inside the cooler unless they are

recommended by the manufacturer for the purpose.

Do not place the device near naked flames or other heat

sources (heaters, direct sunlight, gas ovens etc.).

Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the

heat that arises during operation does not build up. Make sure

that the device is sufficiently far away from walls and other

objects so that the air can circulate.

Ensure that the ventilation openings are not covered.

Do not fill the inner container with ice or fluid.

Never immerse the device in water.

Protect the device and the cable against heat and moisture.

3 Scope of delivery

Quantity Description

1 Cooling device

1 Power adapter for 230 V AC mains

1 Connection cable for 230 V AC mains

1 Connection cable for cigarette lighter

Autogoods “130”

130.com.ua

TC07 Proper use

4 Proper use

The cooling device is suitable for cooling and warming foodstuffs.

The cooling device is intended to be used in household and similar

applications such as

staff kitchen areas in shops, offices and other working environments

farm houses

clients in hotels, motels and other residential type environments

bed and breakfast type environments

catering and similar non-retail applications

The device is also suitable for camping.

5 Technical description

The coolbox is suitable for mobile use. You can cool products to a maximum of

25 °C under the ambient temperature or warm them to a maximum of 65 °C.

Its cooling system is a non-wearing Peltier cooling, the heat is discharged by

a fan.

CAUTION! Health hazard!

Please check if the cooling capacity of the device is suitable for

storing the food or medicine you wish to cool.

Autogoods “130”

130.com.ua

Operation TC07

6 Operation

6.1 Energy saving tips

Choose a well ventilated installation location which is protected against

direct sunlight.

Allow warm food to cool down first before placing it in the device to keep

cool.

Do not open the cooling device more often than necessary.

Do not leave the cooler unit open for longer than necessary.

6.2 Switching on the cool box

➤Place the coolbox on a firm base.

Connecting to 230 Vw

➤Connect the 230 V connection cable to the power adapter.

➤Plug the other end of the 230 V connection cable into the socket at the

cool box.

➤Connect the power adapter to a socket.

✓The power adapter‘s LED glows green.

NOTE

Before starting your new cooling device for the first time, you

should clean it inside and outside with a damp cloth for hygienic

reasons (please also refer to the “Cleaning and care” on page 20).

NOTICE!

Ensure that the objects placed in the cool box are suitable for

cooling/warming to the selected temperature.

NOTE

The plug’s polarity cannot be reversed: it can only be inserted into

the socket in one direction (fig. 2A, page 3).

Autogoods “130”

130.com.ua

TC07 Operation

Connecting to 12 Vg

➤Plug one end of the 12 V connection cable into the socket of the cool box.

➤Connect the other end of the 12 V connection cable to the cigarette lighter

in your vehicle (fig. 3, page 3).

Switching on the cool box

➤Push the switch on the operating panel (fig. 2C, page 3) into

the “HEISS/HOT” position or the “KALT/COLD” position to switch the

coolbox on.

✓The cool box starts cooling/heating the interior.

Switching between cooling and heating

➤If you wish to switch between cooling and heating, push the switch

on the operating panel (fig. 2C, page 3) into the “HEISS/HOT”

or “KALT/COLD” position.

✓The red or green operating display lights up and the device begins

cooling/heating.

6.3 Switching on the cool box

➤If you wish to end the cooling/heating process, push the switch on the

operating panel (fig. 2C, page 3) into the “AUS/OFF” position.

➤If you wish to switch off the device, pull out the connecting cable.

6.4 Connecting to a cigarette lighter

Operating display Operating mode

Red (fig. 2B, page 3) Heating

Green (fig. 2D, page 3) Cooling

NOTE

If you connect the device to the cigarette lighter of your vehicle

(fig. 3, page 3), remember that the ignition must be turned on to

supply the device with power.

Autogoods “130”

130.com.ua

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Accesorios de Dometic

Dometic

Dometic PERFECTROOF PR2000 Manual de usuario

Dometic

Dometic CFF Manual de usuario

Dometic

Dometic DELIBOX DEL90H Manual de usuario

Dometic

Dometic 8270000.401 Series Manual de usuario

Dometic

Dometic 9500E Manual de usuario

Dometic

Dometic TROPICOOL TCX07 Manual de usuario

Dometic

Dometic COOLPRO TC 14 Manual de usuario

Dometic

Dometic 9500E Manual de usuario

Dometic

Dometic RTX1000 Manual de usuario

Dometic

Dometic A&E Manual de usuario

Dometic

Dometic CF 11 Manual de usuario

Dometic

Dometic RH 141LDG Manual de usuario

Dometic

Dometic CK40D Hybrid Manual de usuario

Dometic

Dometic CDF-11 Manual de usuario

Dometic

Dometic Cup Cooler Manual de usuario

Dometic

Dometic A&E WeatherPRO Manual de usuario

Dometic

Dometic CFX3 Series Manual de usuario

Dometic

Dometic A&E Horizon Manual

Dometic

Dometic LA-03 Manual de usuario

Dometic

Dometic Waeco CoolMatic FC40 Manual de usuario

Dometic

Dometic 9100 Manual de usuario

Dometic

Dometic CFX Series Manual de usuario

Dometic

Dometic PerfectWall PW1500 Manual de usuario

Dometic

Dometic RKE 400 Manual de usuario

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
