Thank you for purchasing the product

DOGtrace™ d–control EASY

from VNT electronics s.r.o., Czech Republic.

We would like to ask you for reading this manual carefully before using the unit

and keeping it for future use.

EC Declaration of Conformity

Guideline R&TTE 1999/5/CE

The manufacturer: VNT electronics s.r.o. declares that the below mentioned product:

Electronic training collar DOGtrace™ d–control EASY

complies to all Europe Council Guidelines, Under No. 1999/5/CE of 7. 4. 1999

and corresponds to the following standards:

ETSI EN 300 220

VNT electronics s.r.o. • Němčice 23 • 561 18 Němčice u České Třebové

Phone: +420 461 310 762 • Czech Republic • www.dogtrace.com

CAUTION:

The person with a personal instrument to support heart activity (pacemaker, deﬁbrillator)

must respect the relevant precautionary measures. The d–control emits a certain stationary

magnetic ﬁeld (lower part of the remote controller and RF signals).

Frequency= 869.52 MHz, maximum transmitted power = 25 mW.

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Battery installation and replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Turning ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Programming (matching) of the remote controller and the receiver . . . . . . . . . . . . . . . . . . . . . . . . . 9

How to use the remote controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

How to check that your DOGtrace™ d–control works correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

For the best results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

We are starting with the training collar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Hints for using . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Introduction

Scope of delivery

Optional accessories

Do you need to have your dog under your instant control? Do you want to train it easily, quickly,

precisely, and eﬃciently? The electronic training system DOGtrace™ d–control, consisting of the

transmitter and the collar, will help you train your dog with eﬃciency that cannot be reached by any

other methods. The hand-held transmitter (similar to your TV remote controller) makes it possible to

give commands within a considerable distance. There are two kinds of command. The sound alerting

signal and four steadily preset electronic correction pulses. The electronic systems of the transmitter

and the collar employ the state-of-the-art technology on the basis of single-chip microprocessors

and wireless communications. Thanks to ergonomic design and small weight of the collar you can

use it also for breeds of dog whose growth is small.

}Collar (receiver) with the strap

}Electrodes

}2 pc CR2 3V lithium battery, CR2 3V neon test lamp

}Neon test discharge lamp

}Remote controller (transmitter)

}Service instructions and Certiﬁcate of Warranty

}Dummy collars }Spare batteries

}Varicoloured woven belts }Spare seals

}Spare electrodes }Spare screws

Product description

REMOTE CONTROLLER COLLAR WITH THE STRAP

REMOTE CONTROLLER }1– Buttons to select correction pulses 1–6,

2– Sound signal button, 3– ON/OFF power switch, 4– Indicator.

COLLAR WITH THE STRAP }1– Woven strap, 2– Electrodes, 3– Indicator, 4– Target.

Battery installation and replacement

INSTALLATION (REPLACEMENT) OF THE BATTERY IN THE RECEIVER (COLLAR)

}Remove 4 screws of the receiver housing cover plate with a cross-head screwdriver. Install the 3V

lithium CR2 battery. Mind the correct polarity indicated on the receiver PCB with “+“ symbol in the

battery compartment (see the photo).

}A beep indicating correct installation of battery will sound.

}If you do not hear the beep after installation of the battery, remove it immediately. Check the

polarity and try to install it again.

}Before putting the plate cover to its place make sure that the rubber seal is correctly seated in its

slot. Tighten adequately the 4 screws on the cover plate of the receiver.

Checking the battery state

Look at the indicator on the front panel of the receiver (collar) to check the state of battery:

}The battery is fully charged: When on-state, the LED ﬂashes slowly in green.

}The battery is ﬂat: When on-state, the LED ﬂashes red. Prepare a spare 3V lithium battery CR2 and

follow the section describing how to install the battery in the receiver.

Make sure that the receiver works correctly.

Battery polarity indication

INSTALLATION (REPLACEMENT) OF THE BATTERY IN THE REMOTE CONTROLLER

}Remove the screw on the rear side of the remote controller and remove the battery compartment

lid from the controller carefully. Install a new 3V CR 2 battery and mind the correct polarity

indicated on the battery compartment lid. Replace the battery compartment lid and tighten the

screw adequately.

As the battery discharges, the performance (RF range) of your remote controller gets shorter.

It is necessary to replace the battery. You will recognize the weak battery according to a very weak

tone when your transmitter is turned on or oﬀ. Prepare a spare 3V lithium battery CR2450 and follow

the previous section on Installation of the battery in the remote controller.

Make sure that the remote controller works correctly.

TIP You can remove the batteries

more easily if you use a small

screwdriver and insert it carefully

under the edge of the battery.

Battery compartment

Turning ON/OFF

TURNING THE REMOTE CONTROLLER ON/OFF

}Turning on: Press down for 1 second the black On/Oﬀ button on the remote controller.

Turning on is indicated by a sound signal and by a ﬂashing green LED.

}Turning oﬀ:Again, press down for 1 second the black On/Oﬀ button.

Switching oﬀ is indicated by a sound signal and the green LED stops ﬂashing.

TURNING THE RECEIVER (COLLAR) ON/OFF

The magnetic switching system located in the remote controller is used to turn the receiver (collar)

on and oﬀ.

}Turning on: Touch the lower part of the remote controller for 1 second to the target on the

receiver (refer to the Fig.). The receiver indicator will start ﬂashing green and this indicates that

the receiver is ready for use.

}Turning oﬀ:Again, touch the lower part of the

remote controller for 1 second to the target on the

receiver (see the Fig.). The LED indicator of the

receiver will shine red. The receiver is turned oﬀ.

To enhance the service life of the battery, it is necessary

to turn oﬀ the receiver always after training is ﬁnished.

If the receiver is not used for a longer period of time,

we recommend you to remove the battery from it.

The situation when the receiver is turned on/oﬀ

and the transmitter is being matched with the receiver

}CAUTION: To save the service life of the battery, the transmitter will be automatically

turned oﬀ after 120 minutes of inactivity.

Programming (matching) of the remote controller and the receiver

Every remote controller has its own RF operational code. Programming of the remote controller with

the receiver (collar) will be take place during the ﬁrst use of the DOGtrace™ d–control set or with

a new remote controller or a receiver (when former or latter is lost). This operation will enable you to

match your remote controller with the delivered receiver (collar).

}Turn on your transmitter.

}Touch the lower part of your remote controller to the target on your receiver (see the photo on

page 8). The green LED will be permanently lit and after some 6 seconds, it will switch to the

programming mode, indicated by permanent ﬂashing of the red LED.

}Now take your transmitter away and press down the sound signal button on your

remote controller. The codes will be matched in this step and your receiver will produce

a sound signal.

}IMPORTANT: Before programming is started (before using your receiver for the ﬁrst time

or before code rewriting) make sure that no one else uses his/her d–control or another

product made by DOGtrace in your neighbourhood – your receiver might randomly

receive the code from another remote controller and set itself to it. If this happens,

program your receiver once again, using your remote controller.

REPROGRAMMING OF YOUR RECEIVER

The receiver can be programmed repeatedly without restraint either using the same remote controller

or with another (see the section Programming (matching) of your remote controller and receiver).

TIP It is possible to program an unlimited number of receivers to one receiver, which is

possible to use for common training of several dogs. It is possible to record two transmit-

ters into one receiver, which the instructor can use, for instance, for a potential correction

of the dog training.

How to use the remote controller

The DOGtrace™ d–control EASY remote controller is designed for interaction with one receiver.

Button – sound signal

When you press down the sound signal button, you will be able to send the sound signal to your

receiver within a great distance. There is no time limit for this function: The buzzer will sound for as

long as you are holding the pressed down button and the green LED on your receiver will be

permanently lit.

Buttons to

By pressing down this button, you will send your dog an alert in the form of electronic pulses

transmitted by the two electrodes located in the receiver collar, being generated all the time you are

holding the pressed down button, however, restricted for 8 seconds at the most.

The transmission will be indicated by the red LED on your receiver that will be lit as long as you are

pressing down the buttons for electric pulses.

Level 1: very weak pulse }Level 2: weak pulse }Level 3: medium strong pulse }

Level 4: strong pulse }Level 5: very strong pulse }Level 6: the strongest pulse
