Dodge Avenger 2011 Manual de usuario

1/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

2011 Dodge Avenger

SPECIFICATIONS

NOTE: Information shown is correct at time of publication and is subject to change.

The information shown is preliminary and based on data available at the time of publication. All dimensions are in inches (millimeters)

unless otherwise noted. All dimensions are measured at curb weight with standard wheels and tires unless otherwise noted.

GENERAL INFORMATION

Body Style

Four-door sedan

Assembly Plant

Sterling Heights Assembly, Michigan

EPA Vehicle Class

Mid-size

Introduction date

December 2008

ENGINE: 2.4-LITER GASOLINE DOHC 16-VALVE DUAL VVT SMPI I-4

Availability

Standard on Avenger Express, Mainstreet and Lux models

Type and Description

Four cylinders in-line, tuned intake manifold with electronic active charge motion

control valves, dual counter-rotating balance shafts

Displacement

144 cu. in. (2,360 cu. cm.)

Bore x Stroke

3.46 x 3.82 (88 x 97)

Valve System

Chain-driven DOHC, 16 valves, electronically-controlled dual Variable-valve

Timing (VVT), direct-acting shimless mechanical bucket tappets

Fuel Injection

Sequential, multi-port, electronic, returnless

Construction

High-pressure die-cast aluminum block with dry iron liners, cast-aluminum

cylinder heads, cast-aluminum ladder frame, forged steel crankshaft

Compression Ratio

10.5:1

Power (SAE net, estimated)

173 bhp (129 kW) @ 6,000 rpm (71 bhp/liter)

Torque (SAE net, estimated)

166 lb.-ft. (225 Nm) @ 4,400 rpm

Max. Engine Speed

6,500 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2

Oil Capacity

4.5 qt. (4.23L) SAE 5W-20

Coolant Capacity

7.2 qt. (6.8L)

Emission Controls

Single catalytic converter, dual heated oxygen sensors and engine features(a) 0.9

g/mile (0.56 g/km)

Estimated EPA Fuel Economy (City/Hwy)

21 City/30 Highway (four-speed transmission)

20 City/31 Highway (six-speed transmission)

(a) Meets Federal Tier 2, Bin 5 emissions requirements and PZEV requirements in California, Massachusetts, New York,

Maine, Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV

emissions requirements.

2/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

ENGINE: 3.6-LITER GASOLINE DOHC 24-VALVE SMPI V-6

Availability

Optional on Avenger Express, Mainstreet and Lux models, Standard on Heat and

R/T

Type and Description

60-degree bank angle, liquid-cooled, three-plenum intake manifold with

electronically-controlled manifold tuning valve and short-runner valves

Displacement

3,605 cu. cm.

Bore x Stroke

3.78 x 3.28 (96 x 83 mm)

Valve System

DOHC, 24 valves, hydraulic, roller finger followers

Fuel Injection

Sequential, multi-port, electronic

Construction

High-pressure die-cast A380 aluminum block with iron liners and semi -

permanent mold A319 aluminum heads

Compression Ratio

10.2:1

Power (SAE net, estimated)

283 bhp (211 kW) @ 6,400 rpm

Torque (SAE net, estimated)

260 lb.-ft. (353 Nm) @ 4,400 rpm

Max. Engine Speed

6,800 rpm (electronically limited)

Fuel Requirement

Unleaded regular, 87 octane (R+M)/2 – acceptable

Oil Capacity

6 qts (5.7L) with dry filter SAE 5W-30

Coolant Capacity

10.3 pts (9.75L)

Emission Controls

Dual catalytic converter, four heated oxygen sensors, electronic EGR, and

internal engine features(d)

Estimated EPA Fuel Economy (City/Hwy)

19 City/29 Highway

(d) Meets Federal Tier 2, Bin 5 emission requirements and ULEV II requirements in California, Massachusetts, New York,

Maine, Vermont, Connecticut, Pennsylvania, Rhode Island, New Jersey, Oregon and Washington. Meets Euro IV

emissions requirements.

TRANSAXLE: 40TES AUTOMATIC FOUR-SPEED OVERDRIVE

Availability

Standard with Avenger Express model

Description

Four-speed overdrive, adaptive electronic control, electronically-modulated

converter clutch

Gear Ratios

1st

2.842

2nd

1.57

3rd

1.00

4th

0.69

Reverse

2.21

Final Drive Ratio

3.91 with 2.4L engine

Overall Top Gear

2.69 with 2.4L engine

3/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

TRANSAXLE: 62TE AUTOMATIC SIX-SPEED OVERDRIVE

Availability

Standard with Avenger Mainstreet, Heat, Lux and R/T

Description

Six-speed, adaptive electronic control or Auto Stick driver-interactive manual

control and electronically-modulated torque converter clutch

Gear Ratios

1st

4.127

2nd

2.842

3rd

2.283

4th

1.452

5th

1.00

6th

0.69

Reverse

3.214

Transfer Ratio

0.95

Final Drive Ratio

3.16 w/ 3.6L engine, 3.43 w/ 2.4L engine

Overall Top Gear

2.06 w/ 3.6L engine, 2.24 w/ 2.4L engine

DRIVETRAIN

Front-wheel Drive

Availability

Standard with all engines

DIMENSIONS AND CAPACITIES

Wheelbase

108.9 (2765.0)

Track, Front

61.7 (1567.0)

Track, Rear

62.7 (1593.8)

Overall Length

192.6 (4892.0)

Overall Width

72.8 (1849.6)

Overall Height

58.4 (1483.4)

TBD

Fuel Tank Capacity, gal. (L)

16.9 (64.0)

Towing Capabilities, lbs. (kg)

2.4L Auto. Trans.

1000 (450)

3.6L Auto. Trans.

1000 (450)

(e) Maximum frontal area of trailer or boat: 22 square feet 3.6L engine and 11 square feet 2.4L engine.

Curb Weight, lbs. (kg)

2.4L I-4 Engine

Avenger Express 3,394 (1540)

3.6L V-6 Engine

Avenger Heat 3,603 (1634)

4/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

ACCOMMODATIONS

Seating Capacity - F/R

2/3

EPA Total Interior Passenger Volume, cu.

ft. (cu. m.)

100.2 (2.837)

Front

Head Room w/o Sunroof

40.0 (1017.3)

Head Room w/Sunroof

37.9 (963.4)

Legroom

42.4 (1077.1)

Shoulder Room

56.3 (1431.1)

Hip Room

52.6 (1336.2)

Seat Travel

10.32 (260)

EPA Front Compartment Volume, cu. ft.

(cu. m.)

55.1 (1.56)

Rear

Head Room w/o Sunroof

38.3 (972.3)

Legroom

36.2 (919.2)

Shoulder Room

56.0 (1421.7)

Hip Room

52.8 (1341.3)

Knee Clearance

2.9 (74.1)

EPA Rear Compartment Volume, cu. ft.

(cu. m.)

45.1 (1.28)

Cargo

Trunk Lift-over Height

30.7 (779.8)

SAE Luggage Compartment Volume,

cu. ft. (cu. m.)

13.5 (0.382)

BODY/CHASSIS

Layout

Transverse front engine, front-wheel drive

Construction

Steel Unibody

SUSPENSION

Front

Independent MacPherson strut, coil spring over gas-charged shock absorbers,

stabilizer bar with isolated suspension cradle

Rear

Multi-link independent with coil springs, link-type stabilizer bar, gas-charged

shock absorbers and isolated rear suspension cradle

STEERING

Type

Power rack and pinion

Overall Ratio

16.65:1

Turning Diameter (curb-to-curb)

36.5 ft. (17-in. wheels), 37.7 ft. (18-in. wheels)

Steering Turns (lock-to-lock)

3.3 (17-in. wheels), 3.0 (18-in. wheels)

5/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

BRAKES

Availability

Standard on Avenger Express, Mainstreet, Heat, R/T and Lux models

Power-assist Type

8 x 9 (204 x 230) tandem-diaphragm vacuum

Front

Size and Type

11.5 x 1.0 (294 x 26) vented rotors with 2.2 (57.0) single-piston floating caliper

Swept Area (Total Front)

223.5 sq. in. (1442.1 sq. cm.)

Rear

Size and Type

10.3 x 0.4 (262 x 10) solid rotor with 1.4 (35.0) single-piston floating caliper

Swept Area (Total Rear)

138.6 sq. in. (894.6 sq. cm.)

Parking Brake Type

Drum-in-hat

Anti-lock Brake System (ABS)

Standard

Electronic Stability Control (ESC)

Standard

Traction Control

Standard

Brake Assist

Standard

WHEELS

Availability

Standard on Avenger Express model

Type and Material

Steel wheel with Painted wheel cover, Sparkle Silver

Size

17 x 6.5

Availability

Standard on Avenger Mainstreet model

Type and Material

Machined and Painted cast-aluminum, Sparkle Silver

Size

17 x 6.5

Availability

Available on Avenger Lux model

Type and Material

Chrome-clad cast-aluminum

Size

18 x 7.0

Availability

Available on Avenger Heat and R/T

Type and Material

Polished and Painted cast Aluminum, Sparkle Silver

Size

18 x 7.0

6/ DODGE AVENGER SPECIFICATIONS http://media.chrysler.com

SPECIFICATIONS

AVENGER

TIRES

Availability

Standard on Avenger Express and Mainstreet models

Size and Type

P225/55R17, All-season

Model

Michelin Primacy MXV4 Touring

Revs per Mile (km)

778 (1252.0)

Availability

Standard on Avenger Heat, R/T and Lux models

Size and Type

P225/50R18, All-season Touring

Model

Goodyear Eagle LS-2

Revs per Mile (km)

777 (1250.4)

Availability

Standard on Avenger Express and Mainstreet models

Size and Type

P225/55R17, All-season Touring

Model

Continental ProContact Touring

Revs per Mile (km)

779 (1262.7)
